SITOP UPS1600 under STEP 7 V12
SITOP UPS1600 under STEP 7
V12
Getting Started
___________________
Introduction
___________________
Safety notes
___________________
Description
___________________
Assigning the IP address
Installing and configuring the
SITOP UPS1600 in STEP 7
V12
___________________
Parameterizing the SITOP
UPS1600
1
2
3
4
5
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SITOP UPS1600 under STEP 7 V12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SITOP UPS1600 under STEP 7 V12

Summary of Contents for Siemens SITOP UPS1600 under STEP 7 V12

  • Page 1 ___________________ SITOP UPS1600 under STEP 7 V12 Introduction ___________________ Safety notes ___________________ Description ___________________ Assigning the IP address Installing and configuring the SITOP UPS1600 under STEP 7 SITOP UPS1600 in STEP 7 ___________________ Parameterizing the SITOP UPS1600 Getting Started...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Parameterizing the SITOP UPS1600 ..................... 25 Buffering an S7 IO controller, including the I/O when the power fails ........25 Switching off the UPS when the power fails by a user program ..........29 SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 5: Introduction

    Operating instructions and manuals for SITOP are available in the Internet: Operating instructions/manuals (http://www.siemens.com/sitop/manuals) SITOP power supply homepage General news about our power supplies is available in the Internet at the SITOP home page (http://www.siemens.com/sitop). SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 6: Additional Documentation

    Introduction 1.3 Additional documentation Additional documentation Further information is available in the following documents: ● UPS1600 and UPS1100 manuals ● IO controller manual ● STEP 7 V12 manual SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 7: Safety Notes

    EN50272-2) must be observed for the storage, assembly and operation of the lead accumulators. It must be ensured that the battery location is suitably ventilated. Potential ignition sources must be separated by at least 50 cm. SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 9: Description

    After the UPS1600 has been saved in the hardware catalog of STEP 7 V12 by installing the hardware support package, it can be integrated into projects, parameterized and diagnosed. Languages German, English French, Italian, Spanish and Chinese being prepared. SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 11: Assigning The Ip Address

    SITOP UPS1600 interface is described using the Primary Setup Tool. General information The Primary Setup Tool is a Siemens product that is free of charge and which is used to identify and configure network-conform devices. You can download the Primary Setup Tool under (http://support.automation.siemens.com/WW/view/en/19440762).
  • Page 12 Assigning the IP address Procedure 1. Called the Primary Setup Tool. 2. In the Primary Setup Tool select the menu command "Settings > Set PG/PC Interface...". SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 13 3. In the dialog box "Set PG/PC Interface", select the "Access Path" tab. 4. From the interfaces listed, select the Ethernet interface with which SITOP UPS1600 is connected, and confirm with "OK". SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 14 The SITOP UPS1600 is displayed as "DC-UPS:" with its MAC address and IP address. 7. Open the menu of the SITOP UPS1600 in the tree view and select "Incl. Ethernet interface". 8. Select the "Assign IP parameters" checkbox. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 15 If required, select the checkbox "Use router" and enter the IP address of the router. 10. Select the SITOP UPS1600 in the tree view. The configuration can only be loaded to the device if the SITOP UPS1600 has been selected at the upper level. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 16 11. In the Primary Setup Tool, select the menu command "Module > Download", to load the configuration to the SITOP UPS1600. You have assigned an IP address to the SITOP UPS1600, and you can now communicate with the SITOP UPS1600. SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 17: Installing And Configuring The Sitop Ups1600 In Step 7 V12

    3. In the hardware catalog, navigate to the correct version of the UPS1600. 4. Under the task card "Hardware catalog" in the palette "Catalog" open the folder "Power Supplies > SITOP UPS > UPS1600" and click on the UPS1600. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 18 5. Drag and drop the UPS1600 into the work cell of the network view. The UPS1600 is visible in the work cell. 6. Save your project. The UPS1600 is integrated in the project. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 19 Ethernet input of the IO controller will lead to errors later on. The connection is graphically shown. 2. Double-click on the UPS1600 to display it in the device view in the work cell. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 20 3. Click in the work cell of the device view on the UPS1600. 4. In the inspector window click on the "Properties" and "General" tab. 5. Click on the symbol to open the "Profinet interface [X3]". SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 21 6. Select the "Ethernet address", enter the required IP address and the PROFINET device name of the UPS1600 into the appropriate entry fields. 7. Save your project. The UPS1600 is now assigned to the S7 IO controller and integrated in the project. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 22 5. Click on the symbol to open the "Device configuration" and select "Energy storage. 6. Check whether the "SITOP UPS 1100 battery" option field is activated. Activate it if it is deactivated. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 23 Installing and configuring the SITOP UPS1600 in STEP 7 V12 7. Select the appropriate entries in the drop-down lists "Module" and "Number of modules". 8. Save your project. The SITOP UPS1100 battery module is integrated. SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 25: Parameterizing The Sitop Ups1600

    1. Double-click in the network view on the UPS1600 to display it in the device view. 2. Click in the device view of the UPS1600 to select it. 3. In the inspector window click on the "Properties" and "General" tab. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 26 If the checkbox "Buffering allowed" is not selected, independent of the following entries, there is no buffering. 6. For "Connection threshold", enter the voltage value, which, when it is fallen below the UPS, starts to buffer. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 27 Parameterizing the SITOP UPS1600 6.1 Buffering an S7 IO controller, including the I/O when the power fails 7. Enter the buffer time in "Buffer time". 8. Enter "Additional buffer time after PC shutdown". SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 28 9. Under "Stop buffering voltage" enter the battery voltage value where buffering should be stopped – or accept the standard value of 18.50 Volt. 10. Deactivate the checkbox "Enable reset". 11. Save your project. 12. Load the parameters into the S7 IO controller. SITOP UPS1600 under STEP 7 V12 Getting Started,...

  • Page 29: Switching Off The Ups When The Power Fails By A User Program

    6.2 Switching off the UPS when the power fails by a user program Switching off the UPS when the power fails by a user program To switch off the UPS when the power fails, Siemens provides the FB160 function block in the Internet under address (http://support.automation.siemens.com/WW/view/en/78817848).
  • Page 30 Installing the "UPS1600 library TIA Portal V12 SP1" 1. Open STEP 7 V12 and change to the project view. 2. Open a global library under task card "Libraries". The dialog box "Open global library" is opened. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 31 3. Under "Search in" select the storage location of the code block package that has been downloaded, select library "UPS1600 library TIA Portal V12 SP1" and open this. 4. The library is loaded. The library is installed and displayed under the palette "Global libraries". SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 32 > UPS1600 function blocks (TIA V12)" and depending on the S7 IO controller being used, select the appropriate function block folder: – IO controller S7-300/400: "STEP 7 function blocks (S7-300/400)" – IO controller S7-1200/1500: "STEP 7 function blocks (S7-1200/1500)" SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 33 FB1600 is called within organization block OB1. Note Ensure that the update cycle of the organization block being used has a direct influence on the update time of the function block. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 34 "UPS1600 [FB160] in an empty network of block main [OB1] and drop it there. The "Call options" dialog box opens. 2. Under "Name", select the entry "UPS1600_iDB" and confirm the call options. SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 35 Variable in the symbol table UPS1600 parameters Information Address area in the following example UPS_Buffer_mode buffer mode Buffer mode/ %IB 257 normal mode UPS_Ready_for_buffering ready for buffering Ready for buffering / %IB 258 not ready SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 36 You can find additional information on the I/O address area of the UPS1600 in the UPS1600 Manual. Procedure 1. Under project navigation, in folder "PLC variables > UPS1600 Tag table", open the variable table "Tag table UPS1600". SITOP UPS1600 under STEP 7 V12 Getting Started,...
  • Page 37 – UPS_Buffer_mode – UPS_Ready_for_buffering – UPS_New_alarms_pending – UPS_battery_charge_level 3. Save the project and load the parameters into the S7 IO controller. When the power fails, the user program now switches off the UPS. SITOP UPS1600 under STEP 7 V12 Getting Started,...
