PF3100 MANUAL
REV: 1.0
with UI, BMS Controller, Network Expansion,
Modbus RS-485, Ion Pilot, and Thermocouple Cards

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PF3100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Profire Energy PF3100 Series

Summary of Contents for Profire Energy PF3100 Series

  • Page 1 PF3100 MANUAL REV: 1.0 with UI, BMS Controller, Network Expansion, Modbus RS-485, Ion Pilot, and Thermocouple Cards...
  • Page 2 IMPORTANT SAFETY INFORMATION Ambient Operating Temperature Range -40°C to +60°C GENERAL WARNINGS Installation & use must conform to the directions in this guide. System must be properly connected to earth-ground for effective operation of flame detection circuitry. Electrical devices connected to the controller must meet certain electrical standards and be within voltage limits. Replacement fuses must be ceramic and of correct rating.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction Modules Features Specifications Mounting Considerations Installation Warnings Wiring Pinouts Wiring PFRN Power and Communication Display User Interface Menu Map Operation Troubleshooting System Errors Resetting to Defaults...

  • Page 4: Introduction

    PF3100 MODULE FAMILY INTRODUCTION The PF3100 burner management system consists of individual building blocks called modules which can be mixed and matched to form a complete solution. Each module performs a specific function and is intended to be installed close to the device they are measuring or controlling. This simplifies wiring and reduces issues with noise and signal loss compared to centralized control systems.

  • Page 5: Features

    FEATURES • Can view the status of other modules through the PFRN network from the UI Module • Multiple UIs can show the same info on each screen • Able to mount the UI away from the burner • Simple indication of overall status through LEDs allowing end-users to check statuses from afar •...

  • Page 6: Mounting Considerations

    MOUNTING CONSIDERATIONS Orientation The UIX, CTX, and AUX enclosures should be mounted upright. The EPX and TLX enclosures can be mounted in whichever direction makes sense for the application. Location 1. The UI Module is typically mounted in an operator-safe, easily accessible area. The recommended mounting height is 1.5m (5ft) above where the operator will be standing for ease of use.

  • Page 7: Installation Warnings

    INSTALLATION WARNINGS Before installing the PF3100, please review the following list of warnings. Failure to observe the following may result in death, electrocution, property damage, product damage, and/or government fines. 1. For burners greater than 12.5 MMBtuh, additional modules may be required for use with the PF3100 system.

  • Page 8: Wiring

    WIRING Modules The wiring in this section of the document is required for all PF3100 installations. Skipping or performing any steps in this section incorrectly can result in the PF3100 not working properly. 6. Run appropriately zoned conduits between the modules. The UIX and CTX enclosures have pre-drilled conduit holes in two different sizes –...
  • Page 9 might be a result of vibration. The contact must be open continuously for 2 or 20 seconds (depending on the “Pressure/Level Delay” setting) before the system will shutdown. If “Level Restart” is enabled, the system will restart automatically when the Level Contact recloses.

  • Page 10: Pfrn Power And Communication

    PFRN POWER AND COMMUNICATION Below is a small sample network describing module communication through Profire’s propriety communication network, PFRN. NETWORK UI CARD MODBUS CARD EXPANSION CARD (Interface Class) (Network/Controller Class) (Network Class) BMS CARD BMS CARD BMS CARD BMS CARD (Controller Class) (Controller Class) (Controller Class)

  • Page 11: Display User Interface

    DISPLAY USER INTERFACE POWER LED START KEY Off: UI is not powered Used to start the system. On: UI is powered NUMBER PAD STATUS LED Used to key in changes in settings. Off: UI is not powered DELETE KEY Flashing Green: Startup sequence Green: System is running Used to delete the last character entered when Red: System is stopped...

  • Page 12: Menu Map

    MENU MAP The following sections include brief descriptions of each PF3100 menu, including the valid settings range and default setting. Any entries highlighted in gray are hidden in the menu by default. Settings: Temperature Setpoints This menu is used to adjust the Temperature Setpoints. MENU MAP BRIEF DESCRIPTION RANGE...
  • Page 13 420LELSetpoint 4-20mA Lower Explosive 4-20 mA 14 mA Limit Setpoint 420FuelPressureHighSetpoint 4-20mA Fuel Pressure High 4-20 mA 17 .33 mA Setpoint 420FuelPressureLowSetpoint 4-20mA Fuel Pressure Low 4-20 mA 5.6 mA Setpoint 420TankLevelHighSetpoint 4-20mA Tank Level High 4-20 mA 19.6 mA Setpoint 420TankLevelLowSetpoint 4-20mA Tank Level Low...
  • Page 14 420AuxOutMode 4-20mA Aux Output Mode: In List 0 = Disabled 1 = Proportional Valve Control 2 = Process Temperature Echo 3 = Aux Temperature Echo 4 = Fuel Gas Pressure Echo 5 = Tank Level Echo PilotOffEnable Pilot Off Enabled: In List 0 = Disabled 1 = Enabled...
  • Page 15 TankLevelInputMode Tank Level Input Mode: In List 0 = Disabled 1 = Dry Contact 2 = 4-20mA Input 420TankLevelMax The 4-20mA Tank Level 0-65535L 120L Maximum value which is the value that is associated with a 20mA loop current. 420TankLevelMin The 4-20mA Tank Level 0-65535L Minimum value which is...
  • Page 16 AuxTemp2ZeroCal Zero Calibration Factor -32768 to 32767 for TC2A_Check AuxTemp3SpanCal Span Calibration Factor -32768 to 32767 for TC2B AuxTemp3ZeroCal Zero Calibration Factor -32768 to 32767 for TC2B Settings: Ignition Module Field Calibration MENU MAP BRIEF DESCRIPTION RANGE DEFAULT SETTING CUSTOM SETTINGS FlameTemp1SpanCal Span Calibration Factor for -32768 to 32767...
  • Page 17 Role[n] 0 = No Assigned Role In List 1 = Independent Temperature 2 = Primary Temperature Source 3 = Secondary Temperature Source 4 = Temperature Sink 5-255 = Not Implemented MinControllersRunning The minimum number of 0-12 controllers that must be running in order for the appliance to keep running.

  • Page 18: Operation

    OPERATION STARTING THE SYSTEM From any screen on the UI, press the Start Key on the keypad. If there are alarms present, you will be notified. If no alarms are present, you will be prompted to confirm that you want to start. Press the OK key to confirm or the Back key to cancel.

  • Page 19: Troubleshooting

    TROUBLESHOOTING ETHERNET COMMUNICATIONS BLUE POWER LEDS NEXT TO THE ETHERNET PORTS OF THE MODULES ARE OFF 1. Verify that the Ethernet cable is plugged in on both ends. 2. Check that the port supplying power has a Blue LED illuminated indicating that it is currently supplying power.

  • Page 20: System Errors

    SYSTEM ERRORS The UI screen will display any shutdown messages, alarm codes, or warning messages that the system is currently experiencing. For each of these entries, an explanation will accompany the system error. Shutdown messages These indicate the reason that the system last shutdown. In the event of a safety shutdown (ESD), the system will shutdown in 1 second or less.
  • Page 21 www.profireenergy.com 1.855.PRO.FIRE © 2016 PROFIRE...

This manual is also suitable for:

Pf3100-00a/cPf3101-00a
