Base station status in the Direct Connect application:
»
Communication Complete
Base station display:
»
◊
c. Unplug the power cord and USB cable from the base station.
R B
EPLACE ATTERY IN
1. Complete the Bracelet Maintenance process.
a. Access the client's Equipment page.
b. Click the Maintenance link.
c. Select the Battery, Faceplate, and Exhaust Cap
Replaced check box.
d. Click the Complete Bracelet Maintenance button.
The bracelet re-initialization, which must be performed each
time the bracelet is removed, will begin the next time that
the bracelet communicates with SCRAM
Connect.
2. Remove the bracelet.
a. On the buckle, place the shear cutter tips into the two holes
where the tamper clips meet.
b. Press down fi rmly.
c. Squeeze the shear-cutter handles until the plastic center
breaks and the two pieces separate from the buckle cover.
d. Using the T10 screwdriver, loosen the two retaining screws.
e. Pull the strap back through the buckle, removing the
bracelet from the client's ankle.
3. Remove the old faceplate.
a. Insert the Faceplate Removal Tool into the slots on the right
side of the bracelet.
b. Press the tool in until the faceplate disengages.
c. Remove the faceplate.
Note: Discard the faceplate.
4. Remove the old battery.
a. Place your fi nger tip on the edge of the negative (fl at) side
of the battery.
b. Pull up on the battery, removing it from the bracelet.
Note: Discard the battery.
5. Install the new battery.
a. Look closely for the outline of a battery at the bottom of the
battery slot and insert the battery, starting with the positive
side being pushed against the bottom side of the battery slot
and pushing down on the negative (fl at) side, which faces up
towards the serial number.
A small, green
SCRAM CAM
22
Quick Reference Guide
Line 1 – STORAGE MODE
SCRAM CAM B
light on the bracelet will turn on for 5
RACELET
using Direct
NET
