PMC-DR50L/DR70L
SERVICE MANUAL
Ver 1.0 1999.09
MICROFILM
Photo : PMC-DR70L
TAPE
Model Name Using Similar Mechanism
Section
Tape Transport Mechanism Type
Model Name Using Similar Mechanism
CD
MD Mechanism Type
Section
Optical Pick-up Type
SPECIFICATIONS
PERSONAL COMPONENT SYSTEM
AEP Model
UK Model
E Model
PMC-DR50L/DR70L
Tourist Model
PMC-DR50L
NEW
MF-PMCDR50
NEW
KSM-213CCP
KSS-213C
– Continued on page 2 –
