2.2.2 Propeller cage mounting

Begin mounting the propeller cage by inserting 6 carbon tubes into the frame. Care must be
taken as they are 3 different lengths. Please check the following table to know the position
of each carbon tube on your frame.
Delta
140 cm
frame
2x upper
carbon
52 cm
tubes
length
2x middle
carbon
51 cm
tubes
length
2x lower
carbon
52 cm
tubes
length
Next, after stretching out the cage's frame with the net, insert all 4 parts of the cage into
the carbon tubes. The next step is inserting the black C-clips that connect the cage directly
with the lower part of the frame. When all the elements of the cage are connected you
should tighten the netting by pulling the rope in the lower part of the security net. This is
designed to pass though the spring and pull back on itself. The last, but very important step,
is mounting three security Velcro bands, which prevent the cage from accidentally
unfastening. The velcro is there just to hold it closed you do not have to pull it very strongly.
After mounting the propeller cage you should once again check if it is correctly mounted
and protected.
It is recommendable to memorize the exact sequence of all activities.
19/04/2019
Delta Delta
150 cm 165 cm
frame XL Al. frame
55 cm 61 cm
55 cm 63 cm
59 cm 64 cm
Delta
165 cm
XL Ti. frame
62 cm
62,5 cm
64 cm
V2.0
Race/Split
Race v2
v1/v2
150 cm
140 cm
Ti. frame
Ti. frame
61 cm 66 cm
51 cm 56 cm
56 cm 61 cm
Page 6 of 24
