Page 1: User Manual
User Manual Please read through this user manual completely before use. www.mynt3d.com... - Page 2 Quick Tips • View our initial setup walkthrough video at: www.mynt3d.com/pages/tips • Use lower temperatures than filament manufacturers suggest for 3D printers: ABS: >190 C PLA: <190 C • If the feed motor begins to struggle stop operation and back out the filament.
- Page 3 WARNING BURN HAZARD. The ceramic nozzle of this device can become extremely hot. DO NOT touch the tip or any melted plastic or you may be severely burned. DO NOT allow the tip near or in contact with flammable materials. Inform others in the area that the unit is hot and should be handled with care.
- Page 4 Please take a moment to verify you received all the components 1. 3D Printing Pen 2. AC Adapter 3. USB Power Cable 4. Plastic screwdriver (for service door removal) 5. (3) Rolls of ABS Filament Features and Controls of your 3D Printing Pen...
-
Page 5: Operation Instructions
Operation Instructions 1. Connect the AC Adapter and USB Power Cable to a power outlet. Insert the plug into the power socket. 2. Adjust temperature (if desired) and press the feed button and release. Keep an eye on the temperature display and wait for the pen to heat to temperature. - Page 6 Replacement nozzles are available at mynt3d.com. • When changing from PLA to ABS filament, the nozzle may emit a small amount of smoke from the increased temperature. PLA is plant-based and does not release any toxic fumes when over-heated.
-
Page 7: Specifications
Specifications Discharging mode: hot melt extrusion Print Range: unlimited Feeding Speed: adjustable Print Material: ABS/PLA Material Diameter: 1.75mm Nozzle Diameter: 0.60mm Nozzle Temperature: 130-230°C Power Output: 10W Power Input: 5VDC 2A Power Adapter: 100-240VAC 50/60Hz Equipment Dimension: 175 x 20 x 17mm Equipment Weight: 40g RoHS Certifications:... - Page 8 Limited 1 Year Warranty We stand by our products and offer a 1 year limited warranty that covers defects in manufacture. For more information visit: www.mynt3d.com/pages/warranty Contact information: MYNT3D 4041 Soquel Dr Ste A-148 Soquel, CA 95073 support@mynt3d.com (800) 695-5994...
