Model
4005DDS
5 MHz DDS Function Generator
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4005DDS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BK Precision 4005DDS

  • Page 1 Model 4005DDS 5 MHz DDS Function Generator INSTRUCTION MANUAL...
  • Page 3: Safety Summary

    Safety Summary The following safety precautions apply to both operating and maintenance personnel and must be observed d uring all phases of operation, service, and repair of this instrument. Before applying power, follow the installation instructions and become familiar with the operating instructions for this instrument. GROUND THE INSTRUMEN To minimize shock hazard, the instrument chassis and cabinet must be connected to an electrical ground.
  • Page 4 DO NOT SUBSTITUTE PA RTS OR MODIFY THE IN STRUMENT Do not install substitute parts or perform any unauthorized modifications to this instrument. Return the instrument to B&K Precisio n for service and repair to ensure that safety features are maintained. WARNINGS AND CAUTION WARNING and CAUTION statements, such as the following examples, denote a hazard and appear throughout this manual.
  • Page 5 Compliance Statements Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This product is subject to Directive 2002/96/E C of the European Parliament and the Council of the European Union on waste electrical and electronic equipment (WEEE), and in jurisdictions adopting that Directive, is marked as being put on the market after August 13,...
  • Page 6: Table Of Contents

    Contents Safety Summary ......................1 Introduction ......................... 5 Installation ........................5 Initial Inspection ....................5 Input Power Requirements ................6 Controls and Indicators ..................7 Front Panel Description ................7 Rear Panel Description .................. 8 Operating Instructions .................... 9 Function Generator Output ................9 Duty Cycle Control ..................
  • Page 7: Introduction

    Introduction Description The B&K Precision model 4005DDS is a versatile 5 MHz DDS (direct digital synthesis) function generator with display up to 4 digits . The instrument gener ates sinusoidal, triangular, and square wavefor ms over the 1 Hz to 5 MHz range. The output voltage can be varied from 0 to 10 Vp -p into 50 ohms or to 20 Vp-p into open circuit.
  • Page 8: Input Power Requirements

    Retain the original packing in case subsequent repackaging for return is required. Use of the original packing is essential. After the mechanical inspection, verify the contents of the shipment . The items included with the instrument are: Power cord User manual BNC to BNC c able BNC to alligator clips If the contents are incomplete, or if the instrument does not pass the specification...
  • Page 9: Controls And Indicators

    Controls and Indicators Front Panel Description 1) POWER SWITCH Turns power on and off. 2) ATTENUATE KEY Attenuates the output signal by 20 dB. 3) FREQUENCY RANGE SELECTION BUTTON Selects output frequency range (Hz, KHz, or MHz). 4) DUTY CYCLE KEY Used to specify duty cycle of a square waveform.
  • Page 10: Rear Panel Description

    9) AMPLITUDE KNOB Controls the amplitude o f the signal at the MAIN OUTPUT. Pull knob to attenuate the signal by 20 dB. This can be combined with ATTENUATE KEY for total of 40 dB attenuation. 10) DC OFFSET Applies a DC offset to the main signal. Pull knob to turn on. Clockwise rotation from center cha nges the DC offset in a positive direction, while counterclockwise rotation from center changes the DC offset in a negative direction.
  • Page 11: Operating Instructions

    Operating Instructions Function Generator Output Before applying power to the unit, make sure that input voltage is correct and the ventilation holes are not blocked. Ensure the ventilation fan is working well. It is necessary to inspect the generated signal with an oscilloscope before connecting it to any electronic circuit.
  • Page 12: Duty Cycle Control

    Duty Cycle Control The DUTY CYCLE KEY can be used to alter the s ymmetry of a square waveform. time, effectively converting the instrument into a pulse generator. 1. Press the DUT Y CYCLE KEY and the display will blink. 2.
  • Page 13: Specifications

    Specifications 4005DDS Frequency Characteristics Waveforms Sine, Square, Triangle Range 1 Hz to 5 MHz Resolution 4 digits or 1 Hz Accuracy 0.02% ( 2 00 ppm)* Output will change less than 1 ppm within a 15 minute Frequency Stability interval and less tha n 2 ppm within a 24 hour interval .
  • Page 14 NOTE: All specifications apply to the unit after a temperature stabilization time of 15 minutes. Specifications and information are subject to change without notice. To ensure the most current version of this manual, please download the current version here: http://www.bkprecision.com/search/manual/4005DDS For current up-to-date product information, please visit www.bkprecision.com...
  • Page 15: Certification

    Certification CE Compliant CE Declaration of Conformity The function generator meets the requirements of 2006/95/EC Low Voltage Directive and 2004/108/EC Electromagnet ic Compatibility Directive. Low Voltage Directive EN61010 - 1:2001 Safety requirements for electrical equipment for measuremen control, and labo r atory use. EMC Directive EN 61000 - 6-2:2005 EN 61000 - 6-4:2007...
  • Page 16: Maintenance

    Maintenance Preventive Steps Please follow the s e preventive steps to ensure the prop er operation of your instrument. Never place heavy objects on the instrument. Never place a hot soldering iron on or near the instrument. Never insert wires, pins , or other metal object s into ventilation fan. Never move or pull the instrument with power c ord or output lead.
  • Page 17: Fuse Replacement

    Fuse Replacement If the fuse blows, the LED will not light and the instrument wil l not operate. Replace Table 1 - Fuse Table only with the correct value fuse. Refer to for fuse values. The fuse is located on the rear panel adjacent to the power cord receptacle. Remove the fuse holder assembly as follows: 1.
  • Page 18: Service Information

    Service Information Warranty Service: Please go to the support and service section on our website at www.bkprecision.com to obtain a n RMA #. Return the product in the original packaging with proof of purchase to the address below. Clearly state on the RMA the performance proble m and return any leads, probes, connectors , and accessories that you are using with the device.
  • Page 19: 10 Limited One -Year Warr A Nty

    10 Limited One -Year Warr a nty B&K Precision Corp. warrants to the original purchaser that its products and the component parts thereof will be free from defects in workmanship and materials, for a period of one year from date of purchase. B&K Precision Corp.
  • Page 20 (Page intentionally left blank)
  • Page 21 22820 Savi Ranch Parkway Yorba Linda, CA 92887 www.bkprecision.com © 2014 B&K Precision Corp. Printed in Taiwan v4.14.2014...
