Operator's Manual
X-Tractor 1GC
Register your machine:
www.lincolnelectric.com/register
Authorized Service and Distributor Locator:
www.lincolnelectric.com/locator
Save for future reference
Date Purchased
Code: (ex: 10859)
Serial: (ex: U1060512345)
IM576-B
| Issue Date Mar-19
© Lincoln Global, Inc. All Rights Reserved.

Advertisement

Table of Contents
loading

Related Manuals for Lincoln Electric X-Tractor 1GC

Summary of Contents for Lincoln Electric X-Tractor 1GC

  • Page 1 Operator’s Manual X-Tractor 1GC Register your machine: www.lincolnelectric.com/register Authorized Service and Distributor Locator: www.lincolnelectric.com/locator Save for future reference Date Purchased Code: (ex: 10859) Serial: (ex: U1060512345) IM576-B | Issue Date Mar-19 © Lincoln Global, Inc. All Rights Reserved.
  • Page 2 THANK YOU FOR SELECTING A QUALITY PRODUCT BY KEEP YOUR HEAD OUT OF THE FUMES. DON’T get too close to the arc. LINCOLN ELEC TRIC. Use corrective lenses if necessary to stay a reasonable distance away from the arc. READ and obey the Safety Data PLEASE EXAMINE CARTON AND EQUIPMENT FOR Sheet (SDS) and the warning label DAMAGE IMMEDIATELY...

  • Page 3: Safety

    W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 2.d. All welders should use the following procedures in order to 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199.
  • Page 4 SAFETY ELECTRIC SHOCK ARC RAYS CAN BURN. CAN KILL. 3.a. The electrode and work (or ground) circuits are 4.a. Use a shield with the proper filter and cover plates to protect your electrically “hot” when the welder is on. Do eyes from sparks and the rays of the arc when welding or not touch these “hot”...
  • Page 5 SAFETY WELDING AND CUTTING CYLINDER MAY EXPLODE IF SPARKS CAN CAUSE DAMAGED. FIRE OR EXPLOSION. 7.a. Use only compressed gas cylinders containing the correct shielding gas for the process used 6.a. Remove fire hazards from the welding area. If and properly operating regulators designed for this is not possible, cover them to prevent the welding sparks the gas and pressure used.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS Page Safety ................................2-5 General Description ..............................7 Installation ..............................Section A Technical Specifications..........................A-1 Safety Precautions ............................A-2 Electrical Installation .............................A-2 Use with hose and suction devices........................A-2 Operation ..............................Section B Safety Instructions ............................B-1 Operating Instructions...........................B-1 Maintenance..............................Section C Routine Maintenance ............................C-1 Cleaning the Filter ..........................C-1 Emptying the Canister and Heavy Particle Trap ..................C-1 Replacing the filter ..........................C-2...

  • Page 7: General Description

    X-TRACTOR 1GC PRODUCT DESCRIPTION GENERAL DESCRIPTION The X-Tractor 1GC is a self contained system for the removal and filtration of welding fume particles and other point source particu- late. It is a high vacuum, low volume system with the capability to easily and comfortably clean the filter cartridge with compressed air.

  • Page 8: Installation

    X-TRACTOR 1GC INSTALLATION Technical Specifications- X-tractor 1GC INPUT Sales Spec Input Voltage Input Current Input Power 120V 1 Ph 50/60 Hz 1.9 kW K652-1 K652-2 230V 1Ph 50/60 Hz 1.9 kW VACUUM SPECIFICATIONS Air Flow / Pressure Rating 50 CFM @ 60” WG (85 m...

  • Page 9: Safety Precautions

    OD of the tube connections on both the suction GENERAL DESCRIPTION device and the X-Tractor. The X-Tractor 1GC uses a 2" (50mm) The X-Tractor 1GC is a self contained system for the removal OD connection and an SR-4550 adapter. (S20591-8) and filtration of welding fume particles and other point source particulate.

  • Page 10: Operation

    Read and understand this entire section before operating your X- OPERATING INSTRUCTIONS Tractor 1GC. The X-Tractor 1GC provides enough suction for one fume gun or small suction head. When in “Low” mode, only one blower oper- SAFETY INSTRUCTIONS ates, when in “High” mode, both blowers operate. When in the Do not attempt to use this equipment until you have thoroughly “Man”...

  • Page 11: Maintenance

    X-TRACTOR 1GC MAINTENANCE ROUTINE MAINTENANCE 1. Clean the filter. The Filter should be cleaned and the canister emptied on a regular 2. Open the quick-release fasteners on the four corners of the basis. Frequency of cleaning and emptying depends upon a num- case front by rotating the fasteners 1/4 turn.

  • Page 12: Replacing The Filter

    X-TRACTOR 1GC MAINTENANCE REPLACING THE FILTER 1. Clean the filter and empty the canister and heavy particle trap. The filter is a long life, polyester filter designed to be repeatedly 2. Before replacing the canister, loosen the bolts from the bottom cleaned by compressed air.

  • Page 13: Electrical Maintenance

    1. Slide replacement brush into brush housing and snap the 3/8" long should be replaced. There are two brushes required brass backing onto the housing. per motor; two motors per X-Tractor 1GC. E. Replacement of Rear Cover: A. Removal of Rear Cover: When all four brushes have been replaced, replace the rear 1.

  • Page 14: Trouble Shooting

    X-TRACTOR 1GC TROUBLE SHOOTING Observe all Safety Guidelines detailed throughout this manual PROBLEMS POSSIBLE RECOMMENDED (SYMPTOMS) CAUSE COURSE OF ACTION Contact your local Lincoln Authorized Field Service Facility. Poor Suction 1. Leakage 1. Check: Hose connections, Hose integrity 2. Filter too dirty 2.

  • Page 15: Wiring Diagram

    THYRISTOR PC BOARD (220V) SENSOR (120V) S22634 WIRING DIAGRAM FOR X-TRACTOR 1GC MANUFACTURED MAY, 1997 THRU APRIL 1999 (Machines with Low/High Switch and Circuit Breaker located under rear cover) POWER CABLE N.A. WIRE #7 CONNECTED TO AUTO PIN #1 FOR 220V MODEL HIGH N.B.
  • Page 16 DIAGRAMS X-TRACTOR 1GC WIRING DIAGRAM FOR X-TRACTOR 1GC MANUFACTURED AFTER APRIL 1999 (Machines with Low/High Switch and no Circuit Breaker under rear cover) N.A. WIRE #7 CONNECTED TO PIN #1 AT PC BOARD FOR 220V MODEL. POWER CABLE HIGH N.A. WIRE #7 CONNECTED TO PIN #3 AUTO AT PC BOARD FOR 120V MODEL.
  • Page 17 NOTES...
  • Page 18 WARNING Do not touch electrically live parts or Keep flammable materials away. Wear eye, ear and body protection. electrode with skin or wet clothing. Insulate yourself from work and AVISO DE ground. Spanish PRECAuCION No toque las partes o los electrodos Mantenga el material combustible Protéjase los ojos, los oídos y el bajo carga con la piel o ropa moja-...
  • Page 19 WARNING Keep your head out of fumes. Turn power off before servicing. Do not operate with panel open or Use ventilation or exhaust to guards off. remove fumes from breathing zone. AVISO DE Spanish PRECAuCION Los humos fuera de la zona de res- Desconectar el cable de ali- No operar con panel abierto o piración.
  • Page 20 Lincoln Electric for advice or information about their use of our products. We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice.
