Omcan FP-CN-0178 Instruction Manual page 11

Model FP-CN-0178
Item No. Description
22290 Handle without Bar for HLC500
22291 Bracket for HLC500
22292 Plunger for HLC500
22293 Locknut for HLC500
22294 Axletree-1 for HLC500
22295 Principal Axis for HLC500
22296 Axletree-2 for HLC500
22297 Wheel for HLC500
22298 Box Body for HLC500
19475
Position Item No. Description
1 22299 Motor Board for HLC500
2 22300 Soleplate for HLC500
3 22301 Bolt for HLC500
4 22302 Pull Bar for HLC500
5 22303 Axis-1 for HLC500
6 22304 Kickstand for HLC500
7 22305 Link Bar for HLC500
8 22306 Bucket for HLC500
9 22307 Plate for HLC500
Parts Breakdown
Position Item No.
10 22308
11 22309
12 22310
13 22311
14 22312
15 22313
16 22314
17 66037
18 24203
11
Description Position
Motor for HLC500 19
Axis-2 for HLC500 20
Belt for HLC500 21
On/Off for HLC500 22
Electric Board for HLC500 23
Wire for HLC500 24
Foot for HLC500 25
Handlebar Complete for HLC500 26
Fastening Nut for HLC500
