Please read these instructions completely before beginning installation
KIT CONTENTS
QTY DESCRIPTION
.
1
Electric Fan Assembly
4
Mounting Rods
4
Mounting Feet
4
1 x 1 Foam Pads
4
Mounting Clips
1
Thermostat Switch & Probe
1
Thermostat Bracket
1
1 1/2" x 1/2" Foam Pad
2
M4-0.7 Philips Head Bolts
This fan assembly is designed for both
To change airflow direction from the factory setting, you
or performance will be compromised. (See Diagram #1)
PRE INSTALLATION
-
Important: All Dyno-Cool Electric Fans come with a product label factory
installed on one end of the fan shroud. Before installation check the product
label to confirm airflow direction. Airflow direction will be shown with an arrow.
8", 10", 12" & 14" Fans
Factory setup for
PULLER
16" Fan
Factory setup for
PUSHER
Changing airflow direction
To change the airflow direction from the factory setting:
1. Remove the Nut or Clip that holds the electric fan blade onto the motor
shaft.
2. Carefully remove the fan blade from the motor shaft.
Note: This is an interference fit and requires some effort.
3. Flip the fan blade upside down and reinstall onto the motor shaft. Make
sure the roll pin on the motor shaft is aligned with the slot on the fan blade.
4. Reinstall nut or clip on motor shaft.
Important: For Puller applications use the referenced wire colors stated on the
Product Label. For Pusher applications the two wires
change airflow direction.
ELECTRIC FAN MOUNTING
1. Take the four supplied Mounting Feet and install them onto the Fan
Shroud in the desired locations around the perimeter of the shroud.
(See Diagram #2)
2. Position the Fan Assembly against the radiator or air conditioning
condenser.
3. Take the four Mounting Rods and carefully install them through the
Mounting Feet and then though
condenser. (See Diagram #2 & 3)
Caution: Do not use excessive force when installing Mounting Rods; damage
to the radiator or condenser tubes could occur.
4. Take the four 1 x 1 Foam Pads and remove the paper backing. Now install
them (sticky side toward the core) onto the Mounting Rods now protruding
through the radiator or air conditioning condenser. (See Diagram #3)
5. Take the four Mounting Clips supplied and install them onto the Mounting
Rods. The Mounting Clips can only be used one time, so make sure the
Fan Assembly is in the correct location. (See Diagram #3)
6. Secure Mounting Clips until 1 x 1 Foam Pads are slightly compressed.
7. Cut off any excess Mounting Rod.
Derale Performance, Los Angeles,
ELECTRIC FAN WITH THERMOSTAT KIT
QTY DESCRIPTION
.
2
#10 Sheet Metal Screws
1
Spool Extra Wire
1
#10 Blue Ring Terminal
1
5/16 Ring Terminal
1
Blue Wire Tap Connector
3
Blue Butt Connectors
2
Blue Female Connectors
4
4" Zip Ties
IMPORTANT
PUSHER
and
applications
applications
EITHER
the radiator or air conditioning
INSTALLATION INSTRUCTIONS
PART # 16308-16316
TOOLS NEEDED
Standard Screw Driver
Drill
5/32" Drill Bit
12V Test Light
Wire Stripper
Crimping Tool
Dyke Pliers
PULLER
applications.
MUST
follow the directions below
MUST
be reversed to
CA
323.266.3850
Diagram #1
Puller Fan
Engine
Diagram #2
Diagram #3
Mounting
Clips
Mounting
Feet
1 x 1
Foam
Pads
www.derale.com
Rev.05142018
Pusher Fan
Air Flow
Radiator
Mounting
Rods
16308-16314-InstructionSheet
