Install your TPS 440T and 2200T security
devices
This information provides detailed installation instructions for your Threat Protection System (TPS)
440T and 2200T security devices.
Before you begin
Before you begin, go to the TMC at https://tmc.tippingpoint.com, and see the documentation for your
product to:
— Review the product release notes for information about product updates.
— Review the detailed installation and safety documentation for your product.
Important:
The 440T and 2200T security devices may require a license update to ensure
sufficient inspection throughput when you connect to your network. For more information, see
"Step 9. Install your license
— Make sure the power capacity for your installation meets the documented requirements:
• 440T device: AC Voltage 100 to 240; Current 4 to 2 A; Frequency 47 to 63 Hz
• 2200T device: AC Voltage 100 to 240; Current 12 to 6 A; Frequency 47 to 63 Hz
Warning:
Before you turn on power for your product or connect to your network, ensure your
installation meets all power capacity, ventilation, and other safety guidelines. To avoid injury and
damage, you should always review and adhere to all guidelines described in the safety, specification, and
installation documentation. For more information, see the Read Me First document that was included in
your product shipment.
Publication Part Number DOCMT-1016
Edition: August 2017, Rev A1
package," on page 6.
*DOCMT-1016*
DOCMT-1016
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trend Micro TippingPoint TPS 440T
Summary of Contents for Trend Micro TippingPoint TPS 440T
-
Page 1: Before You Begin
Install your TPS 440T and 2200T security devices This information provides detailed installation instructions for your Threat Protection System (TPS) 440T and 2200T security devices. Before you begin Before you begin, go to the TMC at https://tmc.tippingpoint.com, and see the documentation for your product to: —... - Page 2 Refer to the following diagram of the chassis front panel when you install and configure the device. Figure 1. TippingPoint TPS 440T and 2200T security devices – front panel 1. 10 GbE SFP+ ports 5.
- Page 3 Step 2. Attach the device to the rack Unpack the rail kit that shipped with your security appliance and review the installation documentation on the TMC. Note: The TPS 440T and 2200T security devices have the following weight values: — 440T devices: 15.28 pounds (6.93 kilograms) —...
- Page 4 Step 5. Attach the cables Attach the cables so that you can configure the security device from the management port and console port. Connect the management port The management port connection provides Ethernet access to the device. Connect the management port to the network to enable remote management of the device.
- Page 5 • Green: Indicates the system is on. — System status • Flashing green: Indicates the system is booting up, and is not yet ready to inspect traffic. • Flashing green/yellow: Indicates the system is booting and BIOS is updating. • Solid green: Indicates the system is running in a healthy state. •...
- Page 6 Verify your product license provides sufficient inspection throughput. By default, a 440T or 2200T security device is unlicensed and provides reduced inspection throughput for testing and evaluation purposes only. Table 1: TippingPoint TPS 440T and 2200T security devices – unlicensed inspection throughput Security device Unlicensed inspection throughput...
-
Page 7: Where To Go Next
With network connections complete, you can configure network interface types appropriate to the surrounding network by using the ports you connected. See “Where to go next,” on page 7. Where to go next After you attach network connections, network traffic passes through the device using the default filter configuration. - Page 8 This document contains confidential information, trade secrets or both, which are the property of Trend Micro. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from Trend Micro or one of its subsidiaries.
