Recorded data
Reading frequency
1.4

Main and connection dimensions

Main dimensions
Dimensions of opto head
Cable length
Device Manual
2.4-Y optosonic u 3 radio net
Administrative data
Serial number, device-ID
▪
Current date and time
▪
Next target date
▪
Serial number of the connected ultego III
▪
Type ultego III
▪
Consumption data
Energy values (heat / cold) of the previous day
▪
Volume of the last day
▪
Energy values (heat / cold) of the last two target dates
▪
Volume of the last two target dates
▪
Date of the last two target dates
▪
14 month end values for energy (heat / cold)
▪
14 month end values for volumes
▪
Error information
Error status
▪
Date of the first error
▪
optosonic u error code
▪
ultego III error code
▪
Current downtime hours
▪
Downtime hours of the last two target dates
▪
Generally 12 - 52 times per year
H
0.5 m
H = 28 mm
W = 57 mm
L = 100 mm
H = 29 mm
D = 32 mm
