Image Sensing Systems RTMS G4 Installation, Operation, Maintenance, & Troubleshooting page 4

Next step is to calibrate the MVDS:
 Click on Wizard Setup, let run until all lanes are detected/ once all lanes are
detected Wizard will close automatically (add 1 minute if needed)
 Click Manual Settings
 Click Zones
 Number, and adjust lane direction as needed per screen instructions
 Click OK
 Click Exit once
 Click Speed Calibration / enter speed limit for location of mvds
 Click Start / let run until all lanes reach 100%/ Exit
 Exit & Click calibration. Enter speed limit for the area in each lane shown
(set inner lanes a few mhp faster than outer lanes)
 Click Start / let run till completed (add time if still needed)
 Exit & Click Statistics, check box to note calibrated speeds, then Exit
 Click Calibration again, choose Manual Settings, adjust lane speeds one at a
time using up and down arrows for lane change, and left and right arrows for
speed change
 Exit & Click Statistics again / check box to show traffic for current speeds,
if speeds look good, then exit, If not, repeat steps above.
 Click Manual Settings again
 Click Data, change from Normal to Polled status (allows Sunguide to read)
 Click Exit, then Exit Program, to complete process
