Default Gateway - Image Sensing Systems RTMS G4 Installation, Operation, Maintenance, & Troubleshooting

At cabinet:
 Connect Ethernet cable to Ethernet switch
 Click internet access icon on tool bar to connect to server
 Right click, open network sharing center
 Change Adapter settings on left
 Click local area network
 Click Internet Protocol version 4( TCP/IPv4)
 Click Use the following IP address
 Enter your computers IP address
 Use Device Checklist to get info ( IP addresses, and Zones)
 Change third digit in IP address and Default gateway, to match zone
 Example:
 Click ok / Ready to access device for the zone needed
Open G4 Software:
Call TMC to take MVDS out of service (to allow TCP/IP connection)
 Click on communication
 Click pc serial, choose PC TCP/IP from drop down menu
 Enter IP address of terminal server, for the site (see device checklist)
 Enter remote port # (see device checklist) of problem detector
 Click OK
 Click single RTMS to access device
 Click on Normal. The Device is ready to calibrate
My IP address: (10.164.0.123)
Subnet mask:

Default Gateway:

(255.255.255.0) "Always use same"
(10.164.0.1)
