Testing quartz watches with „EM06"
Connect watch adapter "EM06" with the jacks ( + ) ( - ) of the Compact
900, put quarz watch without Battery on the "EM06". Contact red bow
with plus (+) and black bow with ground (-) of the watch. It is also possible
to use only the test cable without EM06.
EM06
For the following menu, press button "EM06" in the main menu.
Choose then button for measuring consumption of electricity, rate
accuracy, stepper motor ohms or voltage.
Volt-
age
Batteriy
voltage
Stepper
Motor
ohms
Menu
Press this button to start diagram
Menu
Source voltage:
10.06.2009
1.55 V
18:37
Volt-
age
start
diagram
Volt-
age on
Motor
QM06
only
17
