3.3

Display

2
4
3
1
1 Function status symbols
Symbols appear representing the functions that can be activated at this
time. See also Section 3.5. Also shown is the next due maintenance (see also
Section 6.2).
2 View ambient details
Key ambient details are shown (date, time, ambient temperature, voltage,
and frequency).
3 Main window
The main window presents all inputs and details in each of the menus.
4 Guide key symbols
This presents the functions that are activated at each of the blue guide
keys. The symbols shown vary depending on the menu selected (see also
Section 3.4).
11
