IO -RO 8, IO -RO 8L
IO-RO8, IO-RO8L Technical Specifications
Max. current consumption
Typical power consumption
Status indicators
(RUN)
Outputs
Number of outputs
Output type
Type of relay: IO-RO8
Type of relay: IO-RO8L
Isolation
Status Indicators
(O0 to O7)
Output current
Maximum frequency
Contact protection
Outputs' power supply: IO-RO8
Nominal operating voltage
Operating voltage
Maximum current consumption
Outputs' power supply: IO-RO8L
Nominal operating voltage
Operating voltage
Maximum current consumption
Environmental
Operating temperature
Storage temperature
Relative Humidity (RH)
Dimensions (WxHxD)
Weight
Mounting
6
I / O E x p a n s i o n M o d u l e
50mA maximum from the adapter's 5VDC
0.13W@ 5VDC
Green LED:
—Lit when a communication link is established between module and OPLC.
—Blinks when the communication link fails.
8 relay
SPST-NO relay; 230VAC / 12/24VDC
Takamisawa JY-24H-K or NAIS (Matsushita) JQ1AP-24V
or OMRON G6B-1114P-24VDC
Fujitsu JY-12H-K or NAIS (Matsushita) JQ1AP-12V
or OMRON G6B-1114P-12VDC
By relay
Red LEDs—Lit when the corresponding output is active.
5A maximum (resistive load)
1A maximum (inductive load)
10Hz
External precautions required (see above: Increasing Contact Life Span)
24VDC
20.4 to 28.8VDC
75mA@24VDC
12VDC
10.2 to 15.6VDC
145mA@12VDC
IP20/NEMA1
0° to 50° C (32 to 122°F)
-20° to 60° C (-4 to 140°F)
5% to 95% (non-condensing)
80mm x 93mm x 60mm (3.15" x 3.66" x 2.362")
183g (6.45 oz.)
Either onto a 35mm DIN-rail or screw- mounted.
