- Page 1 Digital Window Intercom OP-6505B User Guide 2018...
-
Page 3: Table Of Contents
Contents Summary…………………………………………………………………………………………….……. Safety precautions………………………………………………………………………………………… Product introduction……………………………………………………………………………………. Features………………………………………………………………………………………………….…… Hardware interface instruction……………………………………………………………….…… Packing list……………………………………………………………………………………….………….. Wiring………………………………………………………………….………………………….…….…….. Basic function……………………………………………………………………………………….……… Local intercom……………………………………………………………………………….………….…. Remote intercom………………………………………………………………………….……………… Scene mode adjustment…………………………………………………………….………………… Recording…………………………………………………..………………………………….…………….. Fault exclude………………………………………………………………………………………………… DCL20-65……………………………………………………………………..…………………………… Purpose………………………………………………………………………………………………………… Targeted audience……………………………………………………………………….…….………… Alert……………………………………………………………………………………………….….….…….. Icons………………………………………………………………………………..…………………..……… Icons et note………………………………………………………………………………………………… Attention, warning and danger icons……………………………………………..……………. Conversion tables…………………………………………………………………………………….…… Description………………………………………………………………………….………….….…………... -
Page 4: Safety Precautions
Summary Warning and Reminding This symbol means there are potential safe troubles, it may cause death or serious injury with incorrect operation. This symbol used to remind the user that this device attached the important operation and maintenance instructions. Setting and Installation •... -
Page 5: Product Introduction
Internal window intercom Internal window intercom Features • Adopt single DSP multi-channel language auto-control technology, avoiding squeaking and disturb to realize real digital full-duplex intercom. • Adopt full touchable transparent key design, keep intercom without disturb from key-click and keep it with the halo light on. •... -
Page 6: Hardware Interface Instruction
Hardware interface instruction Internal window intercom 【Front view】 ①Working indication light: red light is offline, green light is online ②Loudspeaker: amplify the local intercom audio. ③Recording key: make a recording when press the key at the first time, finish the recording by press again, the recording key will quickly red flashed in the recording process. -
Page 7: Packing List
①Power interface: connect with DC12/2A power. ②Communication interface：connect with the network HD recording host. ③Analog audio input interface: output analog audio, connect with DVR or camera. ④External window intercom interface. 【External window intercom】 ①Loudspeaker/MIC： Loudspeaker：amplify the local intercom audio； MIC：pick up the local intercom audio； ②Internal window intercom interface Packing list Window intercom system include following accessories, please check following parts, please... -
Page 8: Wiring
（1） Microphone pole 1 pcs （2） Power adapter 1 pcs （3） Wiring harness （3*100mm）3 pcs （4） Cable clamp (HC-100) 3 pcs （5） Wiring connector (3.81-2P) 1 pcs （6） Quick installation manual 1 pcs Wiring （1） Connect the one port of power adapter to the power interface of internal window intercom, the other port connect with power socket. -
Page 9: Basic Function
Basic function Local intercom After connected internal window intercom and external window intercom, then power-on. Press the intercom key of internal window intercom, it can digital full duplex HD intercom with external window intercom, press again to stop intercom. Remote intercom Used with HD recording host, under the online status, press remote intercom key to call the server pointed terminal. -
Page 10: Recording
Recording Analog recording Window internal intercom can output analog audio, and it is ok for connect with the DVR to make auto-recording. Network recording When the window intercom system is online, window intercom system will automatic deliver digital recording data during intercom to realize 24 hours recording. If press the recording key, it can trigger HD record host to make event recording ,when press again the record can be finished. -
Page 11: Dcl20-65
DCL20-65 Purpose The OP65-05B includes a DCL20 loop amplifier that makes reception accessible for people with hearing loss. The Installation and Operation Manual provides the information you need to install, configure, and use a DLC20-65 kit. The Installation and Operation Manual provides the necessary information for installing,configuring and using an DCL20-65. -
Page 12: Conversion Tables
It offers especially a perennial installation. Therange We are pleased to introduce our new brand Opus Technologies designed and manufactured in France. We propose innovative products offering maximum comfort for the users. -
Page 13: Contents
Contents This kit includes: A DLC20 amplifier A power supply A power cord A 1,80m loop cable Three 2-point connectors One 3-point connectors A set of 2 stickers « space adapted for hearing impaired ». DCL20-65 The DCL20-65 is an induction loop kit that can be used to equip counters or reception desks. -
Page 14: Installation
Installation Note: The wire supplied in the DLC20-65 kit ensures the quick installation of a magnetic loop system in a reception desk, counter or cash desk. In order to optimize the radiation of the magnetic field and to guarantee a better result he wire should be placed close to the customer. - Page 15 amplifier Loop1 Position the loop on the horizontal counter- top by positionning the cable closest to the Loop2 customer. Install the loop on the vertical countertop by Figure 2. positioning the cable closest to the customer. Set the loop using the binding clips supplied for this purpose. For better durability, it may be ap- propriate to install the loop in a plasticchute.
-
Page 16: Connections Andsettings
Connections andsettings Audio connection micro / Ligne / Mass Ligne / Mass Jack 3,5 To connect the supplied microphone with the kit, insert the 3.5 jack into the microphone input 1. Connecting to an intercom or specific source: Connect your source to input 2 of the DCL20. This input supports the following sources: line, low impedance and 100V with an adapter. -
Page 17: Explication
Loop and powerconnection AC / DCconnector 5 x 2,1 mm Connect the loop cable to the "Loop" input on the DCL20. Note: Loop input does not impose any . sense of connection Power supply: Connect the power supply from the kit to the "Power supply"input. Explication The wire forming the loop are connected to an audio amplifier. -
Page 18: Specifications
Specifications Inputs 2 (1 microphone Audio inputs or line input and 1 line input) Type Micro Jack 3.5, Phoenix terminal block Phantom 4,5V 1mA Power supply Characteristics 12V DC 1,5A Type Separate power box Voltage 230V 50/60 Hz Power 20W max Fuse Thermal Audio Processor... - Page 19 Notes:...
