Summary of Contents for Omega Altise OAGCH15
- Page 1 OPERATION, MAINTENANCE AND SAFETY INSTRUCTIONS Model - OAGCH15 and OAGCH25 Gas Convection Room Heater...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS The OMEGA ALTISE gas space heaters are an automatically operated, portable convection heater for use with Natural gas or Universal LPG. The heater is supplied with an approved flexible hose. Note: A label is attached to the rear of the heater stating the type of gas for which it has been manufactured and adjusted. - Page 3 ROOM VOLUME (NG or ULPG) MODEL OAGCH25 (25MJ/h) 62.5m OAGCH15(15MJ/h) 37.5m DO NOT spray aerosols near this heater while it is in use. Most aerosols contain butane gas which can be a fire hazard if used near this heater when it is in operation.
-
Page 4: On/Off Button
GENERAL HEATER LAYOUT Control Panel Gas Inlet Connector ON/OFF Button Temperature Sensor Handle Power Cord Remote control IR Receiver Air Filter Warm Air Outlet 1 1. Power Cord Storage Remote control IR Receiver CONTROL PANEL FUNCTIONS Economy Button On Timer Setting Button Off Timer Set Button Child Lock Function Current Room Temperature/Hour Display... -
Page 5: Remote Control Functions
Test Point Pressure (kPa) Boost Mode 0.97 1.05 Main Burner Injector (mm) 1.72 Main Burner Injector (mm) 1.66 ODS Injector (mm) ODS Injector (mm) 0.19 The OAGCH15 is recommended to heat a room area of 52m and the OAGCH25 up to 90m... -
Page 6: Installation Instructions
If the fault cannot be fixed or any doubts exist, contact your nearest OMEGA ALTISE service agent or contact OMEGA ALTISE on the telephone number on the rear page of this booklet. -
Page 7: Auto Mode
OPERATING INSTRUCTIONS TURNING ON THE HEATER After the gas and power have been connected and the heater turns to standby mode, press the ON/OFF button to turn on the heater. Press the ON/OFF button again to turn off the heater after use. The fan may keep cycling for 3 minutes until cooled down. -
Page 8: On Timer Function
OPERATING INSTRUCTIONS ON TIMER FUNCTION With the heater in standby mode, press the ON Timer button , the ON Timer indicator icon lights up, and timer indicator shows “00:00”, and the hour clock indicator will flash. Press buttons to set the hour portion of the clock. Each press of the “UP” or “DOWN” button will increase/decrease by 1 hour. The hour clock setting range is 0-23 hours. -
Page 9: Maintenance
MAINTENANCE The heater needs maintenance, and the following information will help you to keep it looking good and working efficiently. It is recommended that this appliance be inspected and serviced every year. Particular attention should be placed on inspection and cleaning of the rear air filter. This should be checked at least once a month. -
Page 10: Troubleshooting
TROUBLE SHOOTING Use the following chart to help determine whether a service call is required. However if you are unsure about the way your heater is operating, contact OMEGA ALTISE or your local service agent. -
Page 11: Error Codes
ERROR CODES Refer to the table below for probable cause and the suggested remedy... -
Page 12: General Specification
Operation: Integrated touch control/remote control Gas Supply Hose: 3/8” BSP Bayonet quick connect Safety Devices: Over heat, Anti-burn, Flame Failure, Oxygen depletion Sensor, Tilt-over switch. WEIGHTS AND MEASURES Model Packaging Size Appliance Dimensions (mm) Weight (kg) (mm) OAGCH15 530x262x550 1 1.3 OAGCH25 660x282x550 13.2... -
Page 13: Exploded View
EXPLODED VIEW... - Page 14 SERVICING Servicing shall only be carried out by an authorised person. OMEGA ALTISE recommends that this room heater be serviced every 24 months to ensure the heater continues to operate in a safe and optimum condition. This is part of general maintenance and any costs incurred are not covered by warranty.
-
Page 15: Wiring Diagram
WIRING DIAGRAM... - Page 16 IM Rev: 1.3...
