- Page 1 Iontophoresis Delivery Unit CAUTION: Federal law (USA) restricts this device to use by or on the order of a physician. Order Number: 001-48 A/W 001-116 Rev B Read Before Use P/N 001-49 Rev B...
-
Page 2: Warnings And Precautions
INDICATIONS The ActivaDose® II Iontophoresis Delivery Unit is indicated for the administration of soluble salts or other drugs into the body for medical purposes as an alternative to hypodermic injection in situations when it is advisable to avoid the pain that may accompany needle insertion and drug injection, when it is advisable to minimize the infiltration of carrier fluids, or to avoid the damage caused by needle insertion when tissue is traumatized. -
Page 3: Theory Of Operation
Do not apply electrodes over or across the right and left temporal regions, or use the ActivaDose® II Iontophoresis Delivery Unit and electrodes for treatment of the orbital region. Doing so may cause transient visual disturbances. Patients with known sensitivity to electrical current should be treated with lower current settings than those recommended for general use. - Page 4 C. Turning the Dose Controller ON and OFF: The dose controller can be turned ON by depressing the On/Dose/Start knob OR turning it clockwise. The unit can be turned OFF by depressing the On/Dose/Start knob. Note: If a treatment is being performed and the unit is turned off, it will automatically ramp down prior to shut-off.
- Page 5 The battery compartment is at the rear of the unit. To open, gently press the door inward and slide it open. Polarity symbols (+) and (-) are marked on the inside of the compartment. If the battery is installed incorrectly, with the polarity reversed, the unit will not operate. Be sure the door is fully closed after installing the battery.
- Page 6 EXAMPLE: For a 40 mA-minute dose, the display shows: NOTES: Maximum possible dose is 80 mA-min. The unit beeps and the display flashes “LIMIT” if an attempt is made to exceed 80 mA-min. After a two-second delay, current can be set. Set Current: Read electrode instructions for recommended current.
- Page 7 D. Pause or Stop Treatment Manually: During treatment or current ramp up, turn the CURRENT knob counterclockwise to reduce current output to 0.0 mA, or press the CURRENT knob for automatic ramp down. The display will flash “PAUSE”, and the dose delivered prior to the pause is retained in memory.
-
Page 8: Specifications
IX. SPECIFICATIONS Electrical Shock Type BF Applied Part. Environmental Conditions Transport and store 50°F to 131°F (10°C to 55°C). Operate 41°F to 104°F (5°C to 40°C). Humidity less than 90%. Atmospheric pressure from sea level to 9,842 feet (3,000m) Ingress of Water Not protected against ingress of water. -
Page 9: Troubleshooting
X. TROUBLESHOOTING Display Shows Possible Cause Corrective Action “ELECTRODE REJECT” • Loose electrical connection • Turn CURRENT knob counter- at one or both electrodes. clockwise to “PAUSE” treat- and“REJ” indicator lights ment and silence beep. • One or both electrodes have pulled away from the skin. - Page 10 XI. SERVICE After following the troubleshooting procedures in section X, if a problem still exists, call ActivaTek at 801-969-0883. If you must return your ActivaDose® II Iontophoresis Delivery Unit for inspection or repair, place the unit, along with the twin lead connector(s), in its original carrying case. Be sure to include a copy of the Return Materials Authorization (RMA) you received after contact- ing customer service.
-
Page 11: Limited Warranty And Disclaimer
LIMITED WARRANTY AND DISCLAIMER ActivaDose® II Iontophoresis Delivery Unit with Twin Lead DISCLAIMER While in the opinion of ActivaTek, Inc. the use of the ActivaDose® II Ion- tophoresis Delivery Unit with Twin Lead has met with success in delivering certain medications into tissues, ActivaTek makes no warranties (i) to the Pur- chaser as to the effectiveness of the Product in the treatment of any disease or physiologic dysfunction, or (ii) to Prescribing Physicians that its use will be effective in the treatment of those patients to whom it is applied. - Page 12 ActivaTek Inc. 2734 South 3600 West, Unit F Salt Lake City, Utah 84119 USA Telephone: 801-969-0883 Toll Free & Fax: 1-800-680-5520 www.activatekinc.com...
