- Page 1 Manual Contour IR Digital Infrared cameras...
-
Page 3: Table Of Contents
Content Content ..................Safety requirements ..............About .................... Operation ..................PC requirements ................Software set and features ............. Applications development by the customer ......... The Maintenance instruction ............Spectral sensitivity ..............Power density ................Technical information ..............Warranty ..................www.ir-viewers.com sales@ir-viewers.com... -
Page 4: Safety Requirements
Safety requirements The customer is responsible for light source safety while • using a camera as a standalone device or integrated into system. The customer must consider protective measures if • necessary. While assembling or operating camera, do not stare at the •... -
Page 5: About
About The near infrared CONTOUR IR Digital camera is designed for observation, registration and recording radiation in near infrared zone in 400-1700 nm spectral region emitted by infrared sources such as GaAs IR LED, diode or solid-state lasers as well as for use in infrared microscopy, infrared luminescence, examination of documents, forensics, art restoration and etc. - Page 6 1. Video output 2. Objective with IR cut-off filter 3. Tripod connection ¼ inch Figure 1. Contour IR Digital camera www.ir-viewers.com sales@ir-viewers.com...
-
Page 7: Pc Requirements
in properties of software (see “help” files), and also if it is required to change a format of the image (1280х1024 or 640х480) or refresh rate (7Hz, 15Hz, 30Hz and 60Hz). To get a direct values characteristic for photometric measurements, adjust scale-correction and switch ON Scale to 1 (scale=1). -
Page 8: Software Set And Features
Software set and features WDM driver suitable for Windows XP/7 (32, 64bit). • Use EVSCAP software for single picture capture and AMCAP • software for video recording. The Contour-IR digital camera is supplied with software • controlling following functions: exposure time, gain factor, gamma correction and etc. -
Page 9: The Maintenance Instruction
(https://www.microsoft.com/en-us/download/details.aspx? id=24826) It allows working with a large array of commercial and free-ware software, supports technology, such as Ulead Video Studio, Adobe Premier, AmCap, VirtualDub and etc. For personal applications development, the customer has to use Microsoft Windows SDK or SDK catalogue available in the supplied CD. -
Page 10: Spectral Sensitivity
Spectral sensitivity Figure 2. Spectral sensitivity (Contour IR digital camera) www.ir-viewers.com sales@ir-viewers.com... -
Page 11: Power Density
Power density The approximate minimum of power density of radiation on an object at the signal-to-noise ratio=10 (20dB) on a 0,15m distance: Figure 3. Power density (Contour IR digital camera) www.ir-viewers.com sales@ir-viewers.com... -
Page 12: Technical Information
Technical information Spectral sensitivity 400-1700nm Sensor size 1/3 inches, 6.0mm x 4,96mm Lens F1.4/26mm, CS-mount Field of view 10° Focusing range 0.15m (or 0,1m)* to inf Sensor CMOS 1/3” 1280 (h) x 960 (w) Size of pixel 3,75 x 3,75 µm Dynamic range 60 dB Relation signal to... - Page 13 * with the distance ring Standard kit includes: IR camera; • distance ring; • IR cut-off filter; • Software and drivers; • manual; • case. • Accessories available upon request; Iris diaphragm • Neutral density filter for lens 1X(3-5% @ 1064nm) •...
-
Page 14: Warranty
Warranty Infrared viewing device CONTOUR-IR Digital meets specifications of the manufacturer and declared operation. The warranty period of the device is 24 months from the date it was sold to the consumer. Claims not accepted, and warranty repair are not made, because of the improper use or incorrect service and maintenance of product instructions. - Page 16 ADOS-TECH, UAB Mokslininku st. 2A, LT-08412, Vilnius, Lithuania Phone: +370 5 270 6407 Fax: +370 5 210 0067 sales@ir-viewers.com www.ir-viewers.com...
