Summary of Contents for ADOS-TECH IRVI Contour IR
- Page 1 Manual Infrared cameras Contour IR...
-
Page 2: Table Of Contents
Content Content ..................Safety requirements ..............About .................... Exposure and Sensitivity ............... Operation ..................The Maintenance instruction ............Spectral sensitivity ............... Power density ................Technical information ..............Warranty ..................www.ir-viewers.com sales@ir-viewers.com... -
Page 3: Safety Requirements
Safety requirements The customer is responsible for light source safety while • using a camera as a standalone device or integrated into system. The customer must consider protective measures if • necessary. While assembling or operating camera, do not stare at the •... -
Page 4: About
About The near infrared CONTOUR-IR camera is designed for observation, registration and recording radiation in near infrared zone in 400-1700 nm spectral region emitted by infrared sources such as GaAs IR LED, diode or solid-state lasers as well as for use in infrared microscopy, infrared luminescence, examination of documents, forensics, art restoration and etc. -
Page 5: Operation
Operation CAUTION! Do not use direct laser radiation on a sensor. CAUTION! Use the attenuators and beam splitters to decrease of laser radiation. On the panel of the camera (Fig. 1) are: 1. Socket for power input 12V, 5.0 х 2.1mm plug. 2. - Page 6 Figure 1. Contour IR camera www.ir-viewers.com sales@ir-viewers.com...
-
Page 7: Spectral Sensitivity
Spectral sensitivity Figure 2. Spectral sensitivity (Contour IR camera) www.ir-viewers.com sales@ir-viewers.com... -
Page 8: Power Density
Power density The approximate minimum of power density of radiation on an object at the signal-to-noise ratio =10 (20dB) on a 0,1m distance: Figure 3. Power density (Contour IR camera) www.ir-viewers.com sales@ir-viewers.com... -
Page 9: Technical Information
Technical information Spectral sensitivity 400-1700nm 1/3 inches, 6.0mm x Sensor size 4,96mm Max. resolution 570 TV lines Resolution at max. 135 TV lines Sensitivity Lens F1.4/26mm, CS-mount Field of view 10° Focusing range 0.2m (or 0.1m)* to inf Ratio signal-to-noise 48 dB Gamma 0.45... - Page 10 Standard kit includes: IR camera; • distance ring; • IR cut-off filter; • manual; • case. • Accessories available upon request; Iris diaphragm • Neutral density filter for lens 1X(3-5% @ 1064nm) • Neutral density filter for lens 2X(3-5% @ 1064nm) •...
-
Page 11: Warranty
Warranty Infrared viewing device CONTOUR-IR meets specifications of the manufacturer and declared operation. The warranty period of the device is 24 months from the date it was sold to the consumer. Claims not accepted, and warranty repair are not made, because of the improper use or incorrect service and maintenance of product instructions. - Page 12 ADOS-TECH, UAB Mokslininku st. 2A, LT-08412, Vilnius, Lithuania Phone: +370 5 270 6407 Fax: +370 5 210 0067 sales@ir-viewers.com www.ir-viewers.com...
