Front Panel
The buttons are located on the rear.
LED indicator
1 · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · Standby
F
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · Selects function
-/+
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · Adjusts volume
· · · · · · · · · · · · · · · · · · · · Connects wireless network.
· · · · Adds the additional Music Flow product to
your network. (In case that one or more Music Flow
product is connected.)
LED indicator: Shows connection status.
• White (Blinking): Waiting for network connection
• White (Staying on): Network connection is
completed.
• White (Dimmed): Standby mode with network
connection.
• Green (Staying on): The first group was set.
• Red (Staying on): Standby mode without network
connection.
Rear Panel
DC IN · · · · · · · · · · · · · · · · · · · · · Connect to AC Adapter.
USB (Service only) · · · · · · S/W download connector.
LAN · · · · · · · · · · · · · · · · · · · · · · · · · · · · · C onnect to router.
OPTICAL IN · · · · · · · · · · ·Connect to an optical device
HDMI IN · · · · · · · · C onnect to device with HDMI OUT.
HDMI OUT (TV ARC) · · · · · · · · · · · · · Connect to a TV.
LAN
Subwoofer Connection
Place the wireless subwoofer near the sound bar and
follow steps below.
a Connect the power cord of the sound bar and the
wireless subwoofer to the outlet.
b Turn on the sound bar. :
The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's green
LED turns on.
Subwoofer Connection Manually
If the subwoofer does not make sound, try to connect
manually.
a Press Pairing button on the rear of the wireless
subwoofer.
•
The green LED on the rear of wireless
subwoofer blinks quickly.
b Turn on the sound bar.
c Pairing is completed.
•
The green LED on the rear of wireless
subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m to prevent wireless
interference.
> 1 m
(3.3 ft)
