Item No.: PL727
Technical Data
Dimensions
73.8X54X55.6mm
Material
ABS
Input Voltage
DC4.5V
Power Supply
3 X AA alkaline batteries
Service life 50,000 locking cycles
≤100uA
Static Power
≤170mA
Dynamic Power
Lower voltage alarm
Use condition
Temperature: -15℃~65℃；
Humidity: 5%~95%
Door thickness:
0.6-1.2mm(standard)
1.2-18mm (optional)
Features
Easy and quick installation and operation
Highly sensitive fingerprint optical sensor, 0.5s reaction time
LED in 2 colours for lock status (green ,red)
Application for metal ,wooden and plastic doors
www.qilocks.com
Fingerprint Lock Product Guide
Emergency
power supply
sales@qilocks.com
Bolt
Mounting hole
+44 (0)20 8906 6881
OLED
Screen
Function
Key
Fingerprint
Scanner
Advertisement
Table of Contents
Related Manuals for QiLocks PL727
Summary of Contents for QiLocks PL727
- Page 1 Fingerprint Lock Product Guide Item No.: PL727 Technical Data Dimensions 73.8X54X55.6mm Material Input Voltage DC4.5V OLED Power Supply 3 X AA alkaline batteries Screen Service life 50,000 locking cycles Function ≤100uA Static Power Bolt ≤170mA Dynamic Power Lower voltage alarm...
- Page 2 Note: this is the default function and is already pre-programmed in new lock. This is the most common function and is used where the same fingerprint will be repeatedly used. Press function key and reset pin at the same time ,select Private mode upon display prompt www.qilocks.com sales@qilocks.com +44 (0)20 8906 6881...
- Page 3 3. The setting will be exited automatically when no action is carried out,and lock in sleep mode Changing the Battery Remove the screw in the battery cover Take off the battery cover Take out the batteries Put in the new batteries and screw cover plate in place www.qilocks.com sales@qilocks.com +44 (0)20 8906 6881...
