Keypad Lock Product Guide
Item No.: PL728
Technical Data
Material
Zinc alloy housing and handle
with black coating
Mechanical, override lock
Rubber Keys
Fixing screws and cam
Input Voltage
DC3V
Battery
2 X AA alkaline batteries
Service life 60,000 locking cycles
≤100uA
Static Power
≤170mA
Dynamic Power
Use condition
Temperature: -15℃~65℃；
Humidity: 5%~95%
Features
Quick and easy to install and operate
Easy to set codes
8 digit master code, 6 digit sub-master code, 6 digit technician code, 4 digit user
code
Two user modes: Private use and Public use
LED in 2 colors for lock status (blue/red)
Mechanical override key for emergency opening, 2000 different codes available
www.qilocks.com
Button
Setting
sales@qilocks.com
+44 (0)20 8906 6881
Confirm
LED light
Handle
Advertisement
Table of Contents
Related Manuals for QiLocks PL728
Summary of Contents for QiLocks PL728
- Page 1 Keypad Lock Product Guide Item No.: PL728 Button Technical Data Material Zinc alloy housing and handle with black coating Mechanical, override lock Rubber Keys LED light Fixing screws and cam Input Voltage DC3V Setting Battery 2 X AA alkaline batteries...
- Page 2 Operating Instructions The lock has a 10 button keypad , a C button and an OK button. The lock has three code levels that allow you to perform the following actions: 1) Master code: Open the lock; Change the master code; Set/Change/Delete the sub-master and user code; Select between Private and Public functions, Activate/deactivate technician code 2) Sub-master code: Open the lock;...
- Page 3 Setup New locks operate with the default user and master codes. A new user and master code must be programmed to prevent the default codes from operating the lock and reducing lock security. Master Code Functions: 1) Open: Enter master code (The user code will be deleted when using master code when the lock is in public mode) 2) Programing Master Code Press C --01—OK—current master code –-OK--- new master code - -OK...
- Page 4 Sub-master code functions: 1) Open: Enter Sub-master code (The user code will be deleted when using sub master code when the lock is in public mode) 2) Change the sub-master Code C---02---OK –- current sub-master code --- OK --- new sub-master code --- OK 3) Set/Change the User Code (Private Use mode) C---00—OK-–sub-master code ---OK--- new user code --- OK 4) Delete User code (Private Use mode)
- Page 5 Additional Functions Occupied Status Indicator (Public Mode) – deactivated by default When activated the blue light will flash every 2 seconds to indicate the locker is in use Activate: C--- 33 - -OK- - Master code - OK Deactivate: C-- 44 - -OK- - Master code - -OK Password protection –...
