- Page 1 Near Syracuse NY 315-687-7891 Visit for a test drive! MF1700 Series Compact Tractors Pocket Guide This pocket guide is formatted for optimal viewing on your tablet and/or mobile device. Updated: 03/2014...
- Page 2 1700E Series www.mabiebros.com 1700E Series...
-
Page 3: Model Overview
Model Overview www.mabiebros.com Model 1726E 1734E 1739E 24 (17.9) @ 34 (25.3) @ 38.5 (28.7) @ Engine HP (kW) 2600 RPM 2600 RPM 2800 RPM Gear: 20.4 (15.2) Gear: 29.0 (21.6) Gear: 32.8 (24.5) PTO HP (kW) HST: 19.2 (14.3) HST: 27.2 (20.3) HST: 30.9 (23.0) Engine Type... - Page 4 Engine www.mabiebros.com Common Shibaura Engine in All Models • Model N843T-F 3-cylinder engine • Manufactured by Shibaura (Japan) • 1.5 liter (91.5 cu in) displacement • Turbocharged • Indirect injection, individual unit injectors • Electronic engine management • Structural block. Side support rails included when loader is installed •...
- Page 5 Engine www.mabiebros.com EPA Tier 4i Emissions Compliant • Exhaust Gas Recirculation (EGR) • Diesel Oxidation Catalyst (DOC) • Diesel Particulate Filter (DPF) • No DOC/DPF in 1726E models • DPF Cleaning/Regeneration • Fully automated • Requires no operator input • No change in tractor operation (under normal regeneration process) •...
- Page 6 Transmission www.mabiebros.com Gear: 9x3 Constant Mesh • 3 ranges, non-synchronized, left side in-line hand lever • 3 gears + Reverse, non-synchronized, lever centered under steering wheel • Dry disc main clutch • Foot clutch pedal left side floor HST: 3-Range Hydrostatic •...
- Page 7 Rear Axle www.mabiebros.com Heavy Duty Cast Steel Rear Axle • Bull-gear reduction with flange • Internal wet disc brakes • Mechanically engaged • Individual LH and RH brake pedals • Parking brake via brake pedal lock • Mechanical rear differential lock •...
-
Page 8: Front Axle
Front Axle www.mabiebros.com Mechanical 4wd Front Axle • Solid cast steel construction • Bevel gear design • High ground clearance • High steering angle (52 degrees) • Hydrostatic power steering • Double-end hydraulic cylinder • Center driveline, open differential • 6-8 degrees of even axle oscillation •... -
Page 9: Power Take-Off
Power Take Off www.mabiebros.com Rear Power Take Off (PTO) • 540 RPM PTO standard • 6-spline 1 3/8” 540 shaft • Two types of PTO’s available • Transmission driven • Independent • Mechanically engaged via levers Transmission Driven Independent 540 PTO Speed 540 PTO Speed 2455 Engine RPM 2455 Engine RPM... - Page 10 Power Take Off www.mabiebros.com Transmission Driven PTO • Dependent on main transmission clutch • Press foot clutch – PTO and transmission disengages • Release foot clutch – PTO and transmission engages • Hand lever selects PTO gear • Main clutch must be pressed •...
-
Page 11: Operation
Power Take Off www.mabiebros.com Independent PTO • PTO driveline independent of main PTO Gear Engage Lever transmission clutch • No foot clutch required for operation • Hand lever selects PTO gear • Lever located on right side PTO Start/Stop Lever floor area •... - Page 12 Hydraulics www.mabiebros.com Open Center Hydraulic System • Two gear-type pumps • Steering and implement • 2130 PSI operating pressure • Up to 2 rear remote valves available • Field installed only • Available loader valves and joystick • Attach to loader mounts •...
-
Page 13: Point Hitch
3-Point Hitch www.mabiebros.com Rear 3-Point Hitch • ASAE Category I hitch • Mechanical control, right hand • Position control only • Screw-adjust stabilizers • Fixed ball ends • Single lift arm height adjustment • Adjustable top link • Length and position Lift Capacity @ Ball Ends @ 24”... -
Page 14: Operator's Area
Operator’s Area www.mabiebros.com Standard Platform Features • Left side step/handle for entry • Semi-flat platform, perforated steel foot deck for durability • Steel fenders • Folding ROPS with marker lights • Fixed Steering • Suspended vinyl seat with retractable seatbelt •... - Page 15 Operator’s Area www.mabiebros.com 1700E Series...
- Page 16 Operator’s Area www.mabiebros.com Analog/Digital Dash Fuel Fill Hand Throttle Lights and Turn Signals Pedestal Foot Pedals Fixed Steering Wheel PTO Gear Select Lever Steel Foot Deck Diff. Lock Pedal Range Lever Rear Remote Levers Grab Handle 3-pt Control Suspended Seat iPTO Start Lever Steel Fenders Toolbox...
- Page 17 Service www.mabiebros.com Service Items • 10 gallon fuel tank under platform – ground level fill Single piece raising steel hood • with simple pull latch • Easy access to: • Engine oil check • Engine air filter • Battery • Radiator cleaning •...
- Page 18 Loaders www.mabiebros.com Loader Features • L100 Front loader • Simple straight boom design • Quick attach main frame • Built-in parking stands • Joystick mounted to loader sub-frames • Quick-connect valves • Sub-frame rails for added strength • Can be factory installed 1700E Series...
- Page 19 Loaders www.mabiebros.com Loader Tools • Direct connection to bucket • Bucket level indicator • Grill guard • Pin type or skid steer quick attachment for tools • Tools available: • Buckets • Pallet forks • Accessories • Rear weight frame •...
- Page 20 Backhoes www.mabiebros.com CB10 Backhoe • CB10 backhoe fits all 1700E Series tractors • Sub-frame mounts to rear axle – Durability and long life • Field installed only • Quick attach design for removal • Separate, dedicated seat • Boom float control standard •...
-
Page 21: Warranty
Warranty www.mabiebros.com 5-year Factory Warranty • 2 years / 2,000 hour full coverage • 5 years / 2,000 hour powertrain coverage • Industry-leading coverage • Administered by AGCO • Not aftermarket • Same claim process as all other AGCO products 1700E Series... -
Page 22: Specifications
Specifications www.mabiebros.com Performance 1726E 1734E 1739E Rated Engine HP (kW) 24.0 (17.9) 34.0 (25.4) 38.5 (28.7) Rated Engine Speed 2600 RPM 2800 RPM 20.4 (15.2) gear, 29.0 (21.6) gear, 32.7 (24.4) gear, Rated PTO HP (kW) 19.2 (14.3) HST 27.2 (20.3) HST 30.8 (23.0) HST Rated Torque 68.8 lb ft @ 2600 RPM... - Page 23 Specifications www.mabiebros.com Engine Make IHI Shibaura Machinery EPA Compliance Tier 4 Model N843T-F Emissions Components Internal EGR, DPF Cylinders Diesel Particulate Filter Ceramic wall flow type Bore x Stroke 3.31” x 3.54” Regeneration Modes Active / Passive Displacement 1.5 L (91.3 in Regeneration Control Automatic Compression...
- Page 24 Specifications www.mabiebros.com Transmission Mechanical Transmission Hydrostatic Transmission (HST) Type Constant Mesh Type Variable swash plate 3 forward, 1 reverse; Speeds Infinite Gears all non-synchronized Ranges Ranges 3, non-synchronized Clutch Type Dry single disc Clutch Type Dry single disc Disc Diameter 8.6 in (225 mm) Disc Diameter 8.6 in (225 mm)
-
Page 25: Hydraulic System
Specifications www.mabiebros.com Axles Hydraulic System Rear Axle Type Cast Steel Flange System Type Open center, gear pump Reduction Bull gear System Pressure 2,132 psi (147 bar) Differential Lock Mechanical, foot pedal 1726E/1734E = 6.2 gpm Implement Flow gpm 1739E = 6.6 gpm Brakes Internal wet disc 1726E/1734E = 3.8 gpm... - Page 26 Specifications www.mabiebros.com Speed Chart (MPH) with Mechanical Transmission 1726E/1734E Mechanical Transmission 1739E Mechanical Transmission Tires R1 Ag. R3 Turf R4 Ind. R1 Ag. R3 Turf R4 Ind. Shift Position Front 7-16 27x8.50-15 27x8.50-15 7-16 27x8.50-15 27x8.50-15 Rear 11.2-24 38x14.00-20 15x19.5 11.2-24 38x14.00-20 15x19.5...
- Page 27 Specifications www.mabiebros.com Speed Chart (MPH) with Hydrostatic Transmission 1726E/1734E HST Transmission 1739E HST Transmission R1 Ag. R3 Turf R4 Ind. R1 Ag. R3 Turf R4 Ind. Shift Position 7-16 27x8.50-15 27x8.50-15 7-16 27x8.50-15 27x8.50-15 11.2-24 38x14.00-20 15x19.5 11.2-24 38x14.00-20 15x19.5 Range Forward Speed (MPH) @ Rated Engine RPM 3.72...
- Page 28 Specifications www.mabiebros.com Rear PTO Fluid Capacities PTO Speed 540 RPM only Engine Crankcase Oil 4.9 qts (4.6 L) PTO Shaft Design 1 3/8 inch, 6-spline Cooling System 5.3 qts (5 L) Engine @ 540 PTO Speed 2455 engine RPM Coolant Type 50/50 Mix PTO Gear Selection Mechanical, hand lever...
- Page 29 Specifications www.mabiebros.com Axle Weight Capacities and Ground Clearance 1726E / 1734E 1739E Front Axle Capacity 2,205 lb (1000 kg) 2,205 lb (1000 kg) Rear Axle Capacity 2,205 lb (1000 kg) 2,205 lb (1000 kg) Total Machine Capacity 4,409 lb (2000 kg) 4,409 lb (2000 kg) Tire Sizes (front/rear) 4wd R1 Ag Tires...
-
Page 30: Tractor Dimensions
Specifications www.mabiebros.com Tractor Dimensions 1726E 1734E 1739E Overall Length 116.5 in (2960 mm) 116.5 in (2960 mm) 116.5 in (2960 mm) Min. Width w/ R1 Tires 52.4 in (1330 mm) 52.4 in (1330 mm) 52.4 in (1330 mm) Min. Width w/ R3 Tires 58.1 in (1475 mm) 58.1 in (1475 mm) 58.1 in (1475 mm) - Page 31 Specifications Loader Capacities Loader Model L100 Lift Height @ Pivot 97 in Lift Capacity @ Pivot 1202 lbs Breakout Force @ Bucket Edge 1313 lbs Rated Hydraulic Pressure 2132 PSI Maximum Dump Angle 34 degrees Maximum Bucket Rollback Angle 13 degrees Tractor Compatibility 1726E / 1734E / 1739E Tool Attachment Method...
