- Page 1 Workshop Service Manual MF 300 series tractors Beauvais June 2016 AGCO S.A.S. - 41 avenue Blaise Pascal - 60000 Beauvais - France - RC B562 104 539 ACT0027090 English © AGCO 2016...
- Page 2 Find manuals at https://best-manuals.com...
- Page 3 300 Series Tractor Workshop Manual CONTENTS Section No Description GENERAL SPECIFICATIONS SPLITTING THE TRACTOR ENGINE DATA CLUTCH GEARBOXES REAR AXLE POWER TAKE-OFF FRONT AXLE HYDRAULICS ELECTRICAL SYSTEM SERVICE TOOLS Find manuals at https://best-manuals.com...
- Page 4 Find manuals at https://best-manuals.com...
- Page 5 SECTION 1 Introduction and Safety INDEX I NTRODUCTION and S AFETY TRACTOR SPECIFICATIONS MISCELLANEOUS DATA SERVICING the TRACTOR Find manuals at https://best-manuals.com...
- Page 6 Find manuals at https://best-manuals.com...
- Page 7 Introduction and Safety in the Workshop Section 1 - Part A Table of Contents Operation No. Description Page No. Introduction ..........1 A- 2 Safety in the Workshop ........1 A- 4 1A-1 MF 300 series ACT0027090 Find manuals at https://best-manuals.com...
- Page 8 The tractor warranty may be invalidated by the fitting of or assembly, or a new part or assembly which does not other than genuine Massey Ferguson parts. All Massey involve additional operations or time. Ferguson replacements have the full backing of the Install -Install a part or component not previously fitted manufacturer's warranty.
- Page 9 NOTE: Service Bulletins and Amendment Sheets are issued to the Massey Ferguson Distributors and Dealers Where new pages are required to be positioned between only and are not for general circulation.
- Page 10 LIFE. Additional precautions may be necessary, depending on the type of repair and the conditions at the work site or in the workshop. Massey Ferguson has no direct control over the repair procedures, operation, inspection, lubrication or general maintenance. Therefore it is...
- Page 11 DO NOT go under a tractor supported by a chain hoist or jack. Hearing Protection • Loud noise may damage your hearing and the greater the exposure the worse the damage. If you think the noise is excessive, wear ear protection. Hand Protection 1A-5 MF 300 series ACT0027090...
- Page 12 Always use an earthed (grounded) 3 pin electrical cord. 1A-6 MF 300 series ACT0027090...
- Page 13 Tractor Splitting Kit/Stands or weights) has been added. Seek assistance and use (Use the Massey Ferguson MF.3012 Tractor Splitting suitable equipment to support the weight of the wheel Track, also available, MF.3013 Cab Stands). Should assembly.
- Page 14 Installation of a bearing can be classified in two ways: press fit on rotating parts such as shafts, and gears, and push fit into static locations such as reduction gear 1A-8 MF 300 series ACT0027090...
-
Page 15: Table Of Contents
Fuel Specifications ..........1 B-13 Fuel Handling, Storage and Specification ......1 B-14 MF 300 series 1B-1... -
Page 16: Engine
Tractor Specification Engine: All engines listed below are ......Perkins diesel to Massey Ferguson specification. Four stroke, water cooled, direct injection. See Section 3 for the full engine specification Engine - 3 cylinder: Tractor Models applicable: MF345, MF350 ........AD3.1 52 - naturally aspirated. -
Page 17: Transmissions
Engine and ground-speeds are engaged by a lever on the left of the centre housing. PTO Speeds ........540 rev/min. Shaft Diameter ........35 mm. No. of splines ........Engine to PTO shaft ratio 3. 3125:1. MF 300 series 1B-3 ACT0027090... -
Page 18: Steering
Maximum turning angle ......(Adjustable stops to give 35 , 40 and 50 turning angle) ° ° ° ° Turning circle - less brakes MF385........9, 4 m Maximum static load capacity: MF385........4904 kgf MF 300 series 1B-4 ACT0027090... - Page 19 Interchangeable Cat. 1 & 2 ends ..2145 kgf. Cat. 2 Fixed ends ..... . 2290 kgf. MF 300 series 1B-5...
-
Page 20: Front Axle - Two-Wheel Drive
Rim to disc ........240 Nm. Track Adjustments Front track - two-wheel drive ......1227-1880 mm. Front track - four-wheel drive ......1407-1908 mm. Rear track (Pressed steel wheels) ....1320-2134 mm. MF 300 series 1B-6 ACT0027090... - Page 21 1890 mm 1890 mm 1970 mm 1871 mm Weight 1650 kg 1940 kg 1900 kg 2010 kg 2295 kg 2760 kg Front tires 6.00-16 6.00-16 7.50-16 7.50-16 12.4-11-24 Rear tires 12.4/11-28 14.9/13-28 14.9/13-28 16.9/14-30 18.4/15-30 MF 300 series 1B-7 ACT0027090...
-
Page 22: Tractor Mounting Points - 2 Wheel Drive
7 . . . 4 holes 5/8 inch - 11 UNC - 3B x 32 mm deep. 8 ..6 holes 5/8 inch - 11 UNC - 2B x 35 mm deep. (these 6 holes (8) are on 240 - 4WO tractors only). MF 300 series 1B-8 ACT0027090... - Page 23 6 holes 5/8 inch - 11 UNC - 2B x 32 mm deep. 4 holes 5/8 inch - 11 UNC - 3B x 32 mm deep. 6 ..holes inch - 1 OUNC - 3B x 29 mm deep. 7 ..MF 300 series 1B-9 ACT0027090...
-
Page 24: Serial Numbers -Tractor
Please quote the serial number of your tractor in all correspondance with your dealer or agent. Fig. 1 Name plate with serial number - tractors MF Name plate with serial number - tractors MF 345 - MF 355 350 - MF 360 - MF 375 - MF 385 MF 300 series 1B-10 ACT0027090... - Page 25 C = Stand flow pump. Auxiliary pump. Plated drive. Plain relief valve D = Stand flow pump. Auxiliary pump. Plated drive. Black relief valve E = High flow pump. Centre shift gearbox. Shiftable F = High flow pump. Side shift gearbox. Shiftable PTO MF 300 series 18-11 ACT0027090...
-
Page 26: Four-Wheel Drive Front Axle
The last two letters of the number refer to the date of build. The first letter denotes the month: January. February. March. April. May. June. July. August. September. October. November. December The second letter denotes the year: 1991. 1992. 1993. 1994. 1995. 1996. 1997. 1998. 1999. 2000. MF 300 series 1B-12 ACT0027090... -
Page 27: Fuel Specifications
32 F The grade No 2 fuel, which will produce more work per gallon, is ° recommended for service when the air temperature is 32 F, or above. See chart for fuel requirements. MF 300 series 18-13 ACT0027090... -
Page 28: Fuel Handling, Storage And Specification
In a closed container such as a fuel tank they are more consult your nearest Massey Ferguson Dealer. explosive than pure gasoline. DO NOT use these blends. Additionally, dieselhol is not approved due to possible inadequate lubrication of the fuel injection system. - Page 29 Chemicals and Sealants ........1 C- 4 Conversion Tables ......... 1 C- 5 1C-1 MF 300 series ACT0027090...
- Page 30 Use these values when ALL of the following conditions exist: 1. Damage will not occur to the joined members of the assembly. 2. It is desirable to use this higher clamping force to ensure tightness. 3. Fastener thread is not lubricated prior to assembly. 1C-2 MF 300 series ACT0027090...
- Page 31 Use these values when ALL of the following conditions exist: 1. Damage will not occur to the joined members of the assembly. 2. It is desirable to use this higher clamping force to ensure tightness. 3. Fastener thread is not lubricated prior to assembly. 1C-3 MF 300 series ACT0027090...
- Page 32 Miscellaneous Data CHEMICALS and SEALANTS The following chemicals and sealants quoted in this Workshop Service Manual are available from Massey Ferguson Parts Departments. Description Quantity Part No. Hylomar ............1447 390 M1 100 g tube Jointing and sealing compound.
- Page 33 1.34 1 0 to °F ....1.8 X OC + 32 hp kW ..... 0.74 5 7 oF to oc ... . (°F - 32) + 1.8 1C-5 MF 300 series ACT0027090...
- Page 34 Miscellaneous Data Page left blank intentionally 1C-6 MF 300 series ACT0027090...
- Page 35 Alternative Lubricants ........1 D -13 1D-1 MF 300 series ACT0027090...
-
Page 36: General
41. Gear selection is 'normal' for the model. Adjustments Make the following checks and adjust if necessary: 42. Balance and operation of the brakes. 1D-2 MF 300 series ACT0027090... -
Page 37: D-02
Operator Instruction Book. 3. The use of all instruments and controls. 4. Running-in procedure. 5. The operation of the throttle lever and foot pedal, use of the engine speed indicator, travel and PTO speed chart. 1D-3 MF 300 series ACT0027090... -
Page 38: D-04
32. Complete the 1st Service record card. necessary. Cooling System 9. Check the coolant level and replenish if necessary. 10. Check the alternator/fan belt tension and adjust if necessary. Electrical System 11. Check the battery electrolyte level and replenish if necessary. 1D-4 MF 300 series ACT0027090... -
Page 39: 250 Hour Service
18. Check the toot brakes and adjust if necessary. 19. Check the parking brake and adjust it necessary. General 20. Lubricate all grease points. 21. Lightly oil the clutch linkage, throttle linkage both hand and toot. 1D-5 MF 300 series ACT0027090... -
Page 40: Tractor Storage
13. Refill the engine sump with an approved grade of oil. sprayed or brushed on. 14. Seal the crankcase breather, exhaust and air cleaner pipes with adhesive tape after running the engine. 15. Clean the dry air cleaner unit. 1D-6 MF 300 series ACT0027090... - Page 41 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
