Working with the DIAG Function

SILENCE
– Sets the length of time the internal audible alarm is turned OFF
when the front panel SILENCE button is pressed. The factory default is 30
seconds. If the cause of the gas-alarm has not been cleared at the end of this
time period, the internal audible alarm will reactivate. Use the Keypad to
enter the desired time period, and then press ENTER to save that value and
return to the previous screen.
P-CHK
– The Pressure Check function displays the current manifold
pressure and the stored ambient pressure in psia, along with the difference
between these two pressures and the current fault code. Refer to the heading
Working with the P-CHK Function on Page 17.
CLOCK
– Sets the monitor's date and time. Use the Keypad to enter the
correct date and time, and then press ENTER to save those values and return
to the previous screen. Note that time is displayed in a 24 hour format, while
the date is displayed as mm/dd/yy.
2nd UNIT
– None Available
PRINT
PLOT
PC-DUMP
Rapid advances in computing technology and
availability of the new Spectros Instruments
cell phone application has these features as
no longer supported.
Refer to OPTIONAL ClearSite Web
Application.
12
SILENCE TIMEOUT
0030 sec
14.07 * AMB14.05
-0.02dif <1000>
SET DATE & TIME
07/11/05 15:30
SECONDARY UNITS
NONE
PRINT
2ndUNIT
PC
PLOT
PRINT
2ndUNIT
PC
PLOT
PRINT
2ndUNIT
PC
PLOT
