Operation

Front Panel Display and Controls

ALARM LIGHT (Red)
SYSTEM FAULT
LIGHT (Yellow)
MONITOR ON
LIGHT (Green)
Flashes during
warm-up
SILENCE / ESC
Press this button:
• To temporarily silence the
audible alarm
• Return to the previous
screen without saving data
* Enter the Control/Setup Menu Mode by pressing
the LEFT and RIGHT arrow buttons at the same time.

Inspection

The SF-ExplorIR ™ unit has been thoroughly inspected and tested prior to shipment from the factory.
Nevertheless, it is recommended that the monitor be re-checked prior to use. Inspect the outside of the
enclosure to make sure there are no obvious signs of shipping damage. If damage is discovered, please
contact your supplier for assistance.
