Homing Bed Monsters Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

http://www.hominggame.com/
Hot-line:+86-20-29137067
E-mail: sales@hominggame.com
Owner's Manual
NOTICE
The Operator of this equipment is responsible for maintaining customer safety
at all time. Details set forth in this document must be followed at all times.
Homing Amusement & Game Machine Co.,Limited

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bed Monsters and is the answer not in the manual?

Questions and answers

gene erickson
May 15, 2025

Just installed limit switches. What changes are needed in the firmware? Homing - changes to firmware? Firmware changes for first-time machine use?

0

Subscribe to Our Youtube Channel

Related Manuals for Homing Bed Monsters

Summary of Contents for Homing Bed Monsters

  • Page 1 Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Owner’s Manual NOTICE The Operator of this equipment is responsible for maintaining customer safety at all time. Details set forth in this document must be followed at all times. Homing Amusement & Game Machine Co.,Limited...
  • Page 2 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 SAFETY WARNING In order to use this game safely, be sure to read this Operator’s Manual thoroughly before installation, adjustment or use of this game. Whenever the owner of this game or his authorized representative disassembles, install, adjusts, repairs or performs periodic maintenance on this game, the owner should ensure that the person performing the work has read the appropriate precautions and the relevant section of this manual prior starting work.
  • Page 3 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 Be careful of the identifier in the machine. It is the warning of HIGH VOLTAGE. It means high voltage can cause an electric shock, turn off power before serving. Be careful of the identifier in the machine.

  • Page 4: Table Of Contents

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 CONTENTS Specifications…………………………………….…………………………………………………..4 Package Contents…….…………………………………………………..………………..…..…..5 Major Components………………………………………………………………………………….6 Playing Instruction…………………………………………………………………………………7 Connecting the power cord and grounding……………………………………….8 Installation……….…………….…………………………………….………………………………..10 Movement………………………………………………………………………………………………..12 Game adjustment…………………………………………………………………………………..13 Maintenance and Troubleshooting……………………………………………………..18 I/O chart e company Owner’s manual - 3 -...

  • Page 5: Specifications

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 1. Specification 1 Rated power supply： AC220V±10% 50Hz or AC 110V±10% 60Hz; (Note: As the actual voltage, please refer the label of the machine.) 2 Dimensions： W730×W2161×H2060 (mm) 3 Weight：...

  • Page 6: Package Contents

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 2. Package Content Body Assembly: 1 unit ● Make sure that all the parts shown below are included in product package. ● If any parts are missing, contact your distributor. Accessories Component Specification...

  • Page 7: Major Components

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 3. Major Components 1.Big Monster； 2.Top Acrylic； 3.Side Acrylic； 4.Coin Acceptor； 5.Water Warning； 6.Coin Box Door; 7.Ticket Dispenser； 8.Target(3 Small Monsters); 9.Gun Assy; 10.PlayField(Target8 + 4). Owner’s manual - 6 -...

  • Page 8: Playing Instruction

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 4. Playing Instruction The Target panel Score Display Water Gun Owner’s manual - 7 -...

  • Page 9: Connecting The Power Cord And Grounding

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 5. Connecting the power cord and grounding 1. Insert the plug of power cord into the power socket of the machine. 2. Insert the power cord plug into a service outlet. This machine’s supply voltage is 110V 60Hz , or 220V 50Hz .
  • Page 10 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 Warning: ★ Do not put heavy items on power cord. ★ Do not touch the power plug with a wet hand. ★ Do not draw or twist the cord. ★...

  • Page 11: Installation

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 6. Installation This product is an indoor game machine. Do not install it outside. Even indoors, Avoid installing in places mentioned below so as not to cause a fire, electric shock, injury and or malfunctioning. Place subject to rain or water leakage, or places subject to high humidity in the proximity of an indoor swimming pool and or shower, etc.
  • Page 12 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 Playing zone: This machine requires space for playing the game (play zone) and for maintenance (maintenance zone) as shown below. Be sure to leave enough space when installing the machine. Game leveling Install this machine on a flat surface.

  • Page 13: Movement

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 7. Movement WARNING: Be careful not to damage the machine during transport. Do not give a shock to the molded parts. These parts are fragile. Be careful not to give a shock to the machine when bringing it down from a higher level. Unplug game before moving.
  • Page 14 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 8. Adjustment The mainboard: MB003a.PCB LED-OUT OUT41-48 7-SEG SW1 - DIP OUT 33-40 SW2 - DIP OUT 28-32 SW3 - DIP Service TEST OUT22-27 U26 Music-Eprom OUT15-21 OUT05-14 IN 1-40 Volume OUT01-04...
  • Page 15 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 stop at "4444xxxx/4444xxxx", (Test OUTPUT-1), the input which is on will be display at <1>1-2,<1>3-4,<2>1-2,<2>3-4 and the OUTPUT will ON when the INPUT is on; 5. Press the "SERVICE" button 1 time, 7_Seg display "t05" 3 seconds, stop at "555555xx/55555555", (Test OUTPUT-2), the output 1-48 will ON one by one;and display the output number at <1>1-2 6.
  • Page 16 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 The adjustment of game. 1. Credit Adjust it to setting how many coins per credit. There are 4 options for user to select. It is controlled by SW 11~ SW12. Content SW11 SW12...
  • Page 17 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 4. The default value of JP. Adjust it to setting the default value of JP. There are 4 options for user to select. It is controlled by SW21~SW22. Content SW21 SW22...
  • Page 18 http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 8. Mercy Ticket. Adjust it to setting the mercy ticket per credit. There are 8 options for user to select. It is controlled by SW31~SW33. Content SW31 SW32 SW33 Note Playing Time...

  • Page 19: Maintenance And Troubleshooting

    http://www.hominggame.com/ Hot-line:+86-20-29137067 E-mail: sales@hominggame.com Ocean Amusement Machine Co.,Ltd. Tel: +86-760-88661950; Fax: +86-760-88661960 9. Maintenance and Troubleshooting Safty check Check the points listed before operating the machine. These checks are necessary for safe machine operation. 1 Are the warning labels legible? 2 Is there sufficient play zone around the machine? WARNING Before performing work, be sure to turn power off.
  • Page 20 2． Fault of Ticket PCB 2． Check the PCB 1． Ticket stick 1． Clean the ticket jam. Can’t dispenser ticket 2． Out of tiket 2． Place tickets. Homing Amusement & Game Machine Co.,Limited www.hominggame.com E-mail: sales@hominggame.com skype: comminghui Owner’s manual - 19 -...
