Summary of Contents for Clarke CSR310
- Page 1 SANDING ROLLER MODEL NO: CSR310 PART NO: 6500480 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0519-ISS 2...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Sanding Roller. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Power Tool Safety Warnings
POWER TOOL SAFETY WARNINGS WORK AREA 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. -
Page 4: Additional Safety Warnings For Sanders
5. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. 6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. -
Page 5: Explanation Of Symbols & Pictograms
2. Dust arising from sanding may endanger the health of the operator and possible bystanders. Wear a dust mask and ensure that persons entering the work area are also protected. 3. Remove all dust after sanding. 4. Take care when sanding lead based paint or when sanding wood or metal which may produce toxic dust, - do not let children or pregnant women enter the work area. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 7: Carton Contents
CARTON CONTENTS The following items should be supplied in the carton. If any parts are missing or damaged, please contact the Clarke dealer where you purchased the tool. • 1 x Electric Sanding Roller • 1 x Sanding Roller 45 x 60mm fitted with sanding sleeve 80G abrasive •... -
Page 8: Before Use
BEFORE USE WARNING: BEFORE FITTING ACCESSORIES MAKE SURE THAT THE TOOL IS SWITCHED OFF AND UNPLUGGED. FITTING THE SPARK DEFLECTOR ASSEMBLY 1. Slide the spark deflector along the grooves on the sanding arm. 2. Tighten the knurled screw. ADJUSTMENT 1. When the spark deflector is mounted it can be adjusted to one of four positions as required by the user. -
Page 9: Dust Extraction
Use the supplied reducer ring if necessary. 3. Use a suitable dust extraction device when toxic, carcinogenic or fine dust is produced. Any Clarke dust extractor would be suitable. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: Operation
OPERATION SWITCHING ON AND OFF • To switch the sander on, push the switch to position 1. • To switch the sander off, push the switch to position 0. VARIABLE SPEED CONTROL The variable speed control allows you to adapt the speed of the tool to the workpiece material. -
Page 11: Hints For Optimum Use
On other surfaces, start with a medium grit. In both cases, gradually change to a fine grit for a smooth finish. ACCESSORIES • An accessory kit (part no 6500482) is available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 12: Maintenance
• Only clean the motor housing using a clean damp cloth. Do not use any abrasive or solvent-based cleaner. • A damaged power cable should be replaced by your Clarke dealer or qualified electrician. • The bearings in this sander are sealed for life and require no maintenance. -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts List
PARTS LIST 33 Switch Actuating Rod Lock Screw 34 Switch Button Output Shaft 35 Self Locking Pushbutton Circlip for 24 dia hole 36 Housing Bearing 609-2RS 37 Screw ST4.1x19 Bevel Gear Oil Bearing Holder Protective Hood Knob 10 Shaft Lock Button 11 Shaft Lock Spring 12 Screw M4 x 6 13 Bevel Gear... -
Page 15: Part Diagram
PART DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
