EnOcean USB 300 Manual

Usb gateway for enocean radio
Hide thumbs Also See for USB 300:
Table of Contents

Advertisement

Quick Links

See also: User Manual
USB 300 / USB 300C / USB 300U (OEM)
USB Gateway for EnOcean Radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB 300 and is the answer not in the manual?

Questions and answers

Related Manuals for EnOcean USB 300

Summary of Contents for EnOcean USB 300

  • Page 1 USB 300 / USB 300C / USB 300U (OEM) USB Gateway for EnOcean Radio...
  • Page 2 Local government regulations are to be observed. USB 300 and USB 300C are designed and produced as OEM products. They will be brought to market by local OEM manufacturers. They are not considered to be finished end products in terms of WEEE (electronic waste regulation) and CE.
  • Page 3 Content Introduction .................. 4 V1.3 April 2013 Page 3...
  • Page 4 USB 300 / USB 300C / USB 300U (OEM) User Manual 1 Introduction USB 300 is a small USB stick which connects PC’s or smart home servers to the world of EnOcean based radio products. EnOcean Alliance 3D-label available on request USB 300 is equipped with the TCM 310 transceiver module and the gateway controller software.
  • Page 5 Further information about supported commands and the software features can be found within the TCM 310 user manual: http://www.enocean.com/en/enocean_modules/tcm-310 USB 300 is available for 868 MHz, 315 MHz and 902 MHz: USB 300 (868MHz) has been CE certified and fulfils R&TTE EU directive on radio equipment...

  • Page 6: Technical Data & Environmental Conditions

    USB 300 / USB 300C / USB 300U (OEM) User Manual 2 Technical Data & Environmental Conditions Dimensions: 66 x 23 x 9mm (incl. transport cap 70 x 23 x 9mm) OEM label area: 39 x 12mm Weight: Operation temperature: 0°C...
  • Page 7 Housing: PCB: USB activity LED, positions depends on HW variant TCM 310 Power LED V1.3 April 2013 Page 7...

  • Page 8: Block Diagram And Protocol Layers

    USB 300 / USB 300C / USB 300U (OEM) User Manual Block Diagram and Protocol Layers USB 300 Host Sensor/ Actuator TCM 310 EnOcean USB<>UART UART EnOcean Interface Radio FTDI Gateway FTDI Virtual FT232R Controller COM Port Host Sensor/ Controller...

  • Page 9: Documentation Of Protocols And Enocean Profiles

    USB 300 uses EnOcean Serial Protocol 3 for control commands and data communication. A description of ESP 3 is available at: http://www.enocean.com/en/knowledge-base/ USB 300 is based on a TCM 310 radio module, specific features and commands are described at: http://www.enocean.com/en/enocean_modules/tcm-310/ The content of EnOcean radio telegrams is standardized by the EnOcean Alliance.
  • Page 10 User Manual 5 Additional Features of USB 300 USB 300 can be used as repeater of EnOcean telegrams; this will ex- pand the range of radio devices. Repeater command has to be sent after every power up. For details see ESP3 command description of CO_WR_REPEATER within the ESP3 description: USB 300 can filter EnOcean telegrams;...

  • Page 11: First Steps With Usb 300 And Dolphinview Basic

    First Steps with USB 300 and DolphinView Basic Register download and install DolphinView Basic: http://www.enocean.com/en/download/ Plug USB 300 into free USB port the PC. Start DolphinView Basic and connect to COM port Press self-powered switch or learn button of sensor, DolphinView Basic will display telegram V1.3...

  • Page 12: Restrictions And Hints

    USB 300 should not be exposed to rapid temperature changes shortly before or during operation. Condensation of moisture might damage the device. USB 300 is not intended to be used in rough environment with heavy vibrations or mechanical shocks. The USB front cap is used as handling protection during delivery.
  • Page 13 Microsoft Windows increases the COM port number for every installed USB 300 (FTDI virtual COM port device). If the number reaches 255, you have to reset the device driver and follow the instructions from the com- pany FTDI.

  • Page 14: Legal Issues And Approvals

    8 Legal issues and approvals 8.1 CE and R&TTE conformity (European Union) USB 300 (868Mhz) conforms to CE and to the R&TTE EU directive on radio equipment. The device conforms to the European and national requirements of electromagnetic compatibility. The conformity has been proven and the according documentation has been deposited at EnOcean.
  • Page 15 8.2 FCC (US) USB 300C (315Mhz) and USB 300U (902MHz) are based on the EnOcean STM 300C / STM 300U radio module. This hardware has a limited modular ap- proval according to FCC. The conformity has been proven and the according documentation has been deposited at EnOcean.
  • Page 16 User Manual 8.3 IC (Canada) USB 300C (315Mhz) and USB 300U (902MHz) are based on the EnOcean STM 300C / STM 300U radio module. This hardware has a limited modular ap- proval according to FCC. The conformity has been proven and the according documentation has been deposited at EnOcean.
  • Page 17 8.4 RoHS EnOcean certifies that to its knowledge, USB 300 / USB 300C / USB 300U, are RoHS compliant, conforming to the requirements of “Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003 on the restric- tion of the use of certain hazardous substances in electrical and electronic equipment.”...

This manual is also suitable for:

Usb 300cUsb 300u
