4.4.3 UBX Binary Protocol

T he u-blox GPS Receivers
asynchron ous RS232 or USB
•
Compa ct. 8 Bit binary
•
Checksum protected,
•
M odu lar, using a 2-stag
Note UBX protocol of
optimized to communicate with u-center AE software to get the best performance and optimal
debugging.
®
The ANTARIS 4 receiver features a
serial ports.
1. The RTCM, NMEA or UBX protocol can be enabled or disabled for a given USART port.
2. Messages can be enabled or disabled for each enabled protocol on each port.
For further information please refer to ANTARIS
4.4.3.1 UBX Packet Structure
A basic UBX packet looks as follows:
Figure 70: UBX Protocol Framing
•
Every message starts
•
A 1 Byte Class Field follows.
•
A 1 Byte ID Field defines the message that is to follow
•
A 2 Byte Length Field is following. Length is defined as being the length of the payload, only.
include Sync Chars, Length Field, Class, ID or CRC fields. The number format of the length field is an
unsigned 16-Bit integer in Little Endian Format.
•
The Payload is a variable length field.
•
CK_A and CK_B is a 16 Bit checksum whose calculation is defined below.
