Reichert 16251 Quick Start Manual

Phoroptor vrx & sightchek wireless dongle kit

Reichert

Phoroptor

VRx & SightChek

™

Wireless Dongle Kit 16251

For use with ClearChart

Reichert, Inc.

www.reichert.com • 3362 Walden Avenue, Suite 100, Depew, NY 14043 USA

Toll Free: 888-849-8955 • Tel: +1 716-686-4500 • Fax: +1 716-686-4545

16251-101 Rev. B (August 20, 2018)

Table of Contents

Need help?

Do you have a question about the 16251 and is the answer not in the manual?

Page 1 • 3362 Walden Avenue, Suite 100, Depew, NY 14043 USA Toll Free: 888-849-8955 • Tel: +1 716-686-4500 • Fax: +1 716-686-4545 16251-101 Rev. B (August 20, 2018) ©2018 AMETEK, Inc & Reichert, Inc. Bluetooth trademark is owned by Bluetooth SIG.
Page 2 Phoroptor VRx Digital Refraction System User’s Guide (16241-101) for complete installation, configuration, and compliance information. To obtain a copy of 16241-101, please contact Reichert, your Reichert authorized dealer, or you may download it from the Phoroptor VRx product page at www.reichert.com. Actual components may differ in appearance from those depicted here.
Page 3 Wireless Dongle Kit configuration options: Some Wireless Dongle Kits will connect directly to an instrument using only an Adapter Set configuration, while other Wireless Dongle Kits will connect to an instrument using only an Extension Cable configuration. In some instances a Wireless Dongle Kit can connect to an instrument using either configuration.
Page 4 Continue connecting ClearChart 2 to the Wireless Dongle by plugging in the Extension Cable into either the Right Angle Serial Adapter directly into the serial port (A) – depending on model. ClearChart 2 w/ serial port ClearChart 2 at bottom left corner w/ serial port at bottom center NOTE: Once the Extension Cable is connected, you can easily run the cable up to the top of the ClearChart 2 between the ClearChart 2 and the wall, in the space allowed by the...
