- Page 1 User Guide Avigilon Remote Monitoring Workstation HD-RMWS4-4MN and HD-RMWS3-2MN...
- Page 2 The absence of the symbols ™ and ® in proximity to each trademark in this document or at all is not a disclaimer of ownership of the related trademark. Avigilon Corporation protects its innovations with patents issued in the United States of America and other jurisdictions worldwide (see avigilon.com/patents).
-
Page 3: Table Of Contents
Overview Front View Back View Installation Package Contents Connecting Cables Configuring Windows 10 Activating the Avigilon Control Center™ License Licensing the ACC™ 6 Software Automatic License Activation Manual License Activation Modifying Licenses Downgrading to the ACC 5 Software Troubleshooting Installation—Networking... - Page 4 Playing Back Recorded Video Adding Bookmarks to Recorded Video Advanced Features LED Indicators Power Status Indicator Hard Drive Activity Indicator...
-
Page 5: Introduction
The Avigilon Remote Monitoring Workstation is preloaded with Avigilon Control Center (ACC) Client software and is configured for exceptional performance and reliability. The Remote Monitoring Workstation can be easily integrated into any existing NVR products or Avigilon surveillance systems to add an additional monitoring station. -
Page 6: Back View
4. Microphone connector Accepts a line-in audio connector. 5. USB connectors Accepts USB connections to external devices. 6. Hard drive activity indicator Provides information about hard-drive activity. For more information, see Hard Drive Activity Indicator on page 17. Back View Figure 2: Rear view: (Left) 4 monitor remote monitoring workstation;... - Page 7 6. DVI connector Accepts a DVI-D connection to a display monitor. 7. 1 Gigabit Ethernet ports Accepts an Ethernet connection to the network. 8. Security cable connector Accepts a security cable to prevent theft. 9. Padlock ring Allows a padlock to secure the computer cover to the chasis. 10.
-
Page 8: Installation
Installation Package Contents Ensure the package contains the following: Avigilon 4 Monitor Remote Monitoring Workstation Power cable Keyboard and mouse 4 mDP to HDMI adapters Avigilon 2 Monitor Remote Monitoring Workstation Power cable Keyboard and mouse 1 DP to DVI adapter... -
Page 9: Configuring Windows 10
4. Set a password for the user name you entered on the previous screen. When you are ready, click Next. 5. The Avigilon End User License Agreement is displayed, Review the terms and click Accept. Proceed to activate the license for the Avigilon Control Center software on your Remote Monitoring Workstation. -
Page 10: Automatic License Activation
If it does not, allow the download to occur when you are prompted. 2. Copy the downloaded .lic file to a location that would be accessible to the ACC Client software. 3. Complete the product registration page to receive product updates from Avigilon, then click Register. Return to the ACC Client: 1. -
Page 11: Downgrading To The Acc 5 Software
ACC 5 Client ACC 5 Player ACC 5 Gateway 5. To activate your license, see the Avigilon Control Center Server User Guide for the ACC 5 software, available on http://avigilon.com. Troubleshooting Installation—Networking By default, the Remote Monitoring Workstation acquires an IP address on the network through DHCP. If you need to set up the workstation to use a static IP address or any specific network configuration, see the Windows Help and Support files for more information. -
Page 12: Configuring The Avigilon Control Center Software
Starting Up the Client Software Perform one of the following: In the Start menu, select All Programs or All Apps > Avigilon > Avigilon Control Center Client. Double-click desktop shortcut icon. From the Avigilon Control Center Admin Tool, click Launch Control Center Client. For more information, see the Avigilon Control Center Server User Guide. -
Page 13: Logging In
Logging In 1. Open the Site Login tab. The Site Login tab is automatically displayed if you are launching the Client software for the first time. To manually access the Site Login tab, do one of the following: From the top-right corner of the window, select >... -
Page 14: Navigating The Client
Once you log in, the ACC Client application window is populated with all the features that are available to you. NOTE: Some features are not available if the server does not have the required license, or if you do not have the required user permissions. Figure 3: The Avigilon Control Center Client application window Application Window Features Area Description System Explorer Displays all the elements in your surveillance system. -
Page 15: System Explorer Icons
A virtual folder. Used to group and organize items in the View tab. A server. Only visible from system administration tabs and dialogs. A fixed camera. A PTZ camera. An Avigilon Presence Detector™ sensor. An encoder. An Access Control Manager (ACM) appliance. Only visible when an ACM™ appliance is connected to a site. -
Page 16: Monitoring Video
Icon Description A web page. Monitoring Video Inside a View tab, you can monitor and control video from multiple cameras. Once you open a camera in a View tab, you can control the camera's live and recorded video stream. NOTE: Some features are not available if the server does not have the required license, or if you do not have the required user permissions. -
Page 17: Zooming And Panning In A Video
To switch all of the image panels in the View between live and recorded video, click either Live or Recorded on the toolbar. To switch individual image panels between live and recorded video, right-click the image panel and select either Live or Recorded. Image panels displaying recorded video have a green border. - Page 18 Figure 4: Playback controls on the Timeline. The colored bars on the Timeline show the camera's recording history: — shows the camera has recorded a motion event. — shows the camera has recorded video. — is a bookmark of a recorded event. White areas show that there is no recorded video.
-
Page 19: Adding Bookmarks To Recorded Video
To... Do this... to see years if recorded video exists. Center the Timeline Right-click the Timeline, and select Center on Marker. on the time marker Pan the Timeline Click and drag the time marker through the Timeline. Move the horizontal scroll bar under the Timeline. Right-click and drag the Timeline. - Page 20 NOTE: Some features are not available if the server does not have the required license, or if you do not have the required user permissions. PTZ controls If you have a PTZ camera, you can use the Pan, Tilt, Zoom (PTZ) controls to focus on specific areas in the video stream.
-
Page 21: Led Indicators
Hard drive is not being used. Flashing white Data is being read or written. Limited Warranty and Technical Support Avigilon warranty terms for this product are provided at avigilon.com/warranty. Warranty service and technical support can be obtained by contacting Avigilon Technical Support: avigilon.com/contact-us/. LED Indicators...
