Page 1: Quick Start Guide
tiny USB ISDN TA128 Quick Start Guide This product is designed for the ISDN with Basic Rate Interface... -
Page 2: Package Contents
For more detailed instructions on configuring and using the device, please refer to the on-line manual in the installation CD. Package Contents • One tiny USB ISDN TA128 with USB cable built-in • One tiny USB ISDN TA128 installation CD with drivers and utility software •... -
Page 3: For Windows 98
tiny USB ISDN TA128 Installing the tiny USB ISDN TA128 Connect your ISDN line to the ISDN S cable to the USB port and connect the other end to the PC. Refer to the following figure. For Windows 98: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. - Page 4 2. In the next window, select “Search for the best driver for your device” and click “Next >”. 3. Insert the installation CD into the CD-ROM drive and check “CD-ROM drive” in the next window. 4. Continue through the Wizard, clicking the “Next >” buttons.
-
Page 5: For Windows Me
tiny USB ISDN TA128 5. If you are prompted to restart the computer after Windows finishes installing the driver, press “Yes”. For Windows Me: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Select “Specify the location of the driver”... - Page 6 2. In next window, select “Search for the best driver for your device”. Insert the installation CD into the CD-ROM drive and check “Removable Media”. Click the “Next >” button. 3. Continue through the Wizard, clicking “Next >” at the following screens.
-
Page 7: For Windows 2000
tiny USB ISDN TA128 For Windows 2000: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Click “Next>”. 2. In next window, select “Search for a suitable driver for my device”. Click “Next>”. 3. - Page 8 Quick Start Guide 4. Click “Next>” to install the driver. When the following windows titled “Digital Signature Not Found” appear, press “Yes” to continue the installation.
-
Page 9: For Windows Xp
tiny USB ISDN TA128 5. Press “Finish” to end the installation. For Windows XP: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Select “Install the software automatically”. Insert the installation CD into the CD-ROM drive and click “Next >”. - Page 10 Quick Start Guide 3. Click “Continue Anyway” when the following “Hardware Installation” windows appear.
- Page 11 tiny USB ISDN TA128 4. Press “Finish” to end the installation. ISDN Utility and Diagnostic Program The ISDN Utility includes helpful programs for the tiny USB ISDN TA128, such as a diagnostic program, an uninstallation program, and an on-line manual. After Windows installs the driver of your tiny USB ISDN TA128, the ISDN Utility may be installed automatically.
- Page 12 4. Press “Loopback Test” to begin the diagnostic procedure. It will make a call from the B1 channel that returns through the B2 channel. The D and B channels will be tested for line integrity. Uninstalling the tiny USB ISDN TA128 If you decide to permanently remove the driver and utility of the tiny USB ISDN TA128 from your system, you must run the uninstallation program from the ISDN Utility program group as...
