Thank you for purchasing this Panasonic product.
Before operating this unit, please read these instructions completely.
Before using this product, please pay particular attention to the
"Safety precautions" section (Pages 2 to 7) for safe use.
Please ensure the date and name of store of purchase are stamped
in warranty card and keep it stored together with these operating
instructions in a safe place for future reference.
VN
ARAHE200490_EN.indd 1
ARAHE200490_EN.indd 1
Operating Instructions
Refrigerator (For Household Use)
Contents
Safety Precautions .....................................2
Installation ..................................................8
Parts Identifi cation ...................................10
To use all features ....................................11
Control Panel ......................................11
ECONAVI Operation .......................... 12
Quick Freezing .................................. 12
Food Stored ....................................... 13
Using Tips .......................................... 14
Refrigerator Compartment ................. 15
Prime Fresh ........................................ 15
Freezer Compartment ....................... 16
Cleaning ............................................ 17
Troubleshooting .......................................20
Specifi cations ...........................................20
Model No. NR-DZ600
ARAH1E200490
T1118-0
Printed in Thailand
11-2018
10/18/2561 BE 11:08
10/18/2561 BE 11:08
Advertisement
Table of Contents
Related Manuals for Panasonic ECONAVI NR-DZ600
Summary of Contents for Panasonic ECONAVI NR-DZ600
-
Page 1: Table Of Contents
Cleaning ..........17 Troubleshooting ........20 Specifi cations ...........20 Thank you for purchasing this Panasonic product. Before operating this unit, please read these instructions completely. Before using this product, please pay particular attention to the “Safety precautions” section (Pages 2 to 7) for safe use. -
Page 2: Introduction
Introduction Safety Precautions WARNING CAUTION This expression presumes This expression presumes possibility of a death or possibility of personal injury serious injury. or property damage. This sign means prohibited action This sign means required actions This sign means do not disassemble iso-butane Risk of fi... - Page 3 Introduction For power plug and cord... ● Do not let the cord get damaged. ● Do not insert or disconnect the power plug into/from the wall socket with wet hands. When recycling the product... ● Before taking the refrigerator to be recycled, please remove all the door gasket to prevent locking a child in it.
- Page 4 Introduction WARNING ● Do not use electrical appliances such as a deodorizer in the refrigerator. Leaked refrigerant may catch fi re from a spark of the electrical contacts and may cause an explosion. ● Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 5 Introduction When using... ● Do not let any children hang or ride on the refrigerator door, the unit may turn over and cause an accident. ● Do not apply water on the body or interior. Electrical insulation could deteriorate and may cause shocks or fire. ●...
- Page 6 Introduction CAUTION When storing food... ● Do not freeze glass bottles, that there is a risk of injury. (If the liquid in a glass bottle is frozen and broken, you may be injured.) ● Do not touch frozen foods or containers (especially metallic) with wet hands.
- Page 7 Introduction When moving or transporting the refrigerator... ● Do not transport refrigerators in a horizontal position. Laying a refrigerator horizontally may damage the piping. If any damage is noticed, do not touch the refrigerator, avoid using fi re and ventilate the room. ●...
-
Page 8: Installation
Installation Installation Before using for product. Is the refrigerator installed in the following locations? ●Locations subject to heat and direct sunlight (The cooling power will be reduced and electricity wasted.) ●Poorly ventilated locations with high humidity (Rust will be caused.) ●Locations where the surface is unstable and slanted On carpet, mats, or vinyl fl... - Page 9 Installation Requests and notices Do not peel the seal on the back. Otherwise, the cooling performance may deteriorate. If you have peeled it, then cut a cloth packing tape into a square and paste it Seal onto the refrigerator. Refrigerator doors should not be opened during the interior cooling process.
-
Page 10: Operation
Operation Parts Identifi cation NR-DZ600 A FREEZER COMPARTMENT B PRIME FRESH CASE C REFRIGERATOR COMPARTMENT 1 Shelf FC 2 FC Glass tray 3 Ice twister 4 Ice box 5 Door case FC 6 Case FC 7 LED lamp 8 Door PF 9 Prime fresh case 10 Egg shelf 11 Egg tray... -
Page 11: To Use All Features
Operation To use all features Control Panel Temperature setting and a guide of temperature The temperature can be adjusted for Min-Max levels. 1. Press the [Select] button to select Refrigerator Compartment, Prime Fresh Case, or Freezer Compartment. 2. Press the [Temp. Control] button to select from Max, Mid, or Min levels. The setting of [Prime Fresh] can be set to either “Chill”, “Min”, “Med”... -
Page 12: Econavi Operation
Operation To use all features ECONAVI Operation The refrigerator detects the opening and closing of the refrigerator door to automatically control operation to ensure maximum energy saving.* ECONAVI operates only when the temperature setting is “Med” for both the freezer and refrigerator compartments. -
Page 13: Food Stored
Operation Food Stored In order to preserve food quality for long time, please store it in the right place. When storing food... Freezer ●Foodstuff such as vegetable, fruits and fresh compartment food should be wrapped or pack in box before freezing and refrigerating. -
Page 14: Using Tips
Operation To use all features Using Tips Do not block the cold Basics of energy saving air outlet with food Save cool air! items! If cool air does not spread into Do not stuff food into every corner of the compartments. compartments, (Air outlet) That may... -
Page 15: Refrigerator Compartment
Operation Refrigerator Compartment The position of the tray can be changed (1) Lift up the back of the tray and pull it (2) Insert the tray in lower position, so big forward. Once the protrusions of the tray items can be stored on upper shelf. are unhooked from rails, tilt the tray and remove it. -
Page 16: Freezer Compartment
Introduction Operation Appendix To use all features Freezer Compartment Approx. -23 °C ~ -17 °C ● A lot of frozen food and cooked meal can be stored. Frozen food Frozen food Frozen food Frozen food Frozen food Frozen food Frozen food Frozen food Freezing case Three tips for freezing food and locking in the flavour... -
Page 17: Appendix
Appendix Cleaning, removing and re-installing Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the power outlet. Do not connect or disconnect the power plug with wet hands. When the plug is disconnected, leave it for 10 minutes before plugging again. If not, the compressor may not work. - Page 18 Introduction Appendix Cleaning, removing and re-installing Trays Once every 3 months Removing Protrusion Lift up the back of the tray and pull it forward. Once the protrusions of the tray are unhooked from the rails, tilt the tray and remove it. Rail ...
- Page 19 Appendix Case FC Once every 3 months Removing Attaching Pull out the case as far as possible. With With holding up door case FC, lift the back lifting up the front, pull it out at an angle of the case and install it along the rails with holding door case FC above the case.
-
Page 20: Troubleshooting
Rated Voltage (V) Refer to the rating label attached at the door or the Rated Frequency (Hz) back of the cabinet. Panasonic Corporation http://www.panasonic.com © Panasonic Appliances (Thailand) Co., Ltd. 2018 ARAHE200490_EN.indd 20 ARAHE200490_EN.indd 20 10/18/2561 BE 11:08 10/18/2561 BE 11:08...
