Flow-Alert
Flow Switch
User Manual
VAM-UM-00646-EN-04 (April 2017)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hedland Flow-Alert and is the answer not in the manual?

Questions and answers

Summary of Contents for Badger Meter Hedland Flow-Alert

  • Page 1 Flow-Alert Flow Switch User Manual VAM-UM-00646-EN-04 (April 2017)

  • Page 2: Table Of Contents

    Flow-Alert, Flow Switch CONTENTS Introduction                                                   3 Installation                                                    3 Installation Recommendations                                    4 Installation Instructions                                         5...

  • Page 3: Introduction

    Introduction INTRODUCTION The Flow-Alert flow meter combines the rugged proven technology of a direct reading, piston-type variable area flow meter, coupled with electrical contacts used to signal operators or PLCs at customer-defined flow rates This combination is sealed against industrial contamination by a NEMA 12 and 13 (IP52/54) rated enclosure (does not apply to strap versions) This product provides a local flow indication and automatically signals the operator or PLC if flow is too high or too low...

  • Page 4: Installation Recommendations

    Installation Installation Recommendations Hedland flow meters are designed for easy installation However, the following measures are recommended for reliable, trouble-free operation: • Piping should be accurately aligned and of correct length The high pressure body of the flow meter can withstand shock and flow/pressure pulsation Piping should be firmly supported by external mounting brackets, both upstream and downstream of the flow meter, to avoid any pipe flexing actions that could reduce flow meter life •...

  • Page 5: Installation Instructions

    Installation Installation Instructions 1 See Figure 1 Mount the flow meter so fluid is traveling in the direction of the flow arrow Figure 1: Flow direction arrows 2 See Figure 2 Select a mounting location that is suitable for viewing and product service To connect the flow meter into the piping system, place an open-ended wrench onto the flow meter wrench flats adjacent to the pipe connection being installed DO NOT wrench on the opposite end of the flow meter or leakage may result...

  • Page 6: Electrical Connections

    Electrical Connections ELECTRICAL CONNECTIONS All Flow-Alert flow meters are offered with either single or dual switches Consult local wiring codes before applying power Wiring through Conduit Some installations may require a rigid conduit for the wiring To access a conduit connection: •...

  • Page 7: Reed Switch Configurations

    Electrical Connections Reed Switch Configurations Most units are equipped with an enclosure and a 15 ft (457 m) length of 4-wire #25 AWG type, PVC jacketed cable with a 4-pin Hirschmann connector Certain 1/4 in or SAE 6 meters with lower flow ranges are equipped with a strap housing For safe operation of the reed switch, do not exceed the maximum wattage for that switch For example, the normally open (NO) reed switch has a maximum power rating of 10 Watts If the switch is to operate at 24V DC, the maximum current is the wattage divided by...

  • Page 8: Operation

    Operation OPERATION “Application Information” on page 12 for application information and fluid charts Microswitch Adjustment 1 Remove cover screws and front cover OTE: On flow meters equipped with dual microswitches, the side closest to the connector is the decreasing flow switch and the side opposite the connector is the increasing flow switch “Microswitch Cable Specifications”...

  • Page 9: Reed Switch Adjustment

    Operation Reed Switch Adjustment 1/4 inch Models with Strap Assembly 1 Loosen the screw securing the switch assembly (see Figure Arrow Pointers on Switch Band Screw Figure 7: Reed switch adjustment (1/4 in. models) 2 Slide the switch assembly until the arrow pointers on the switch band are aligned with the desired flow rate indicated on the scale 3 Tighten the screw 1/4…1-1/2 inch Models with Enclosure...

  • Page 10: Maintenance

    Maintenance 6 Install the front cover and gasket To properly seat the cover gasket, tighten the cover screws in a crisscross pattern “Figure 6: Cover screw tightening sequence” on page MAINTENANCE Quick Recoupling The piston type variable area flow meter is inherently less sensitive to shock and vibration than other variable area designs The unique magnetic coupling also eliminates the need for mechanical linkages that can wear or loosen over the functional life of the flow meter However, a pressure spike or extreme flow surge can cause the piston to move at such rapid...
  • Page 11 Maintenance 2 Remove wiring, as needed, used for the flow switch(es) OTE: For configurations with an aluminum enclosure, wiring inside the enclosure does not need to be disconnected, unless additional cleaning is required Microswitch-equipped configurations may need to have wiring disconnected from the system to facilitate complete removal from the line Reed switch configurations have a Hirshmann connector that can be disconnected from the enclosure 3 Remove the flow meter from the line Remove excess piping from the flow meter...

  • Page 12: Application Information

    Application Information APPLICATION INFORMATION Liquid Viscosity Effect (SUS/cSt) The design uses a precision machined, sharp-edged orifice and biasing calibration spring that assures operating stability and accuracy over the wide viscosity range, common to many fluids High flow models of each flow meter size provide good accuracy over a viscosity range of 40…500 SUS (42…109 cSt) (specific gravity) Density Effect...

  • Page 13: Conversion Chart

    Conversion Chart CONVERSION CHART The conversion chart provides a series of simplified mathematical formulas to adjust the graduated scale for changes in pressure (Table 5), temperature (Table 6), and/or specific gravity (Table OTE: Special scales can be made to accommodate other pressures, temperatures and specific gravity The conversion chart can also be used to adjust the multi-pressure flow scale to indicate flow rates in applications beyond the parameters stated on the scale...
  • Page 14 Conversion Chart Correction Factor Specific Fluid Gravity Water Acetic Acid (Air Free) 106 0909 0971 Acetone 079 1053 1125 Alcohol Butyl 083 1027 1098 (Butanol) Alcohol Ethyl 083 1027 1098 (Ethanol) Ammonia 089 0992 1060 Benzine 069 1127 1204 Carbon Disulfide 126 0834 0891...
  • Page 15 Conversion Chart External Internal Body Material Pressure Dust Guards Seals Correction Specific Factor of Fluid Gravity Standard Scale 100 1000 Argon (A) 138 1175 Carbon Dioxide 153 1237 Freon 11 492 2218 (CCI Freon 12 426 1060 (CCI Helium (HE) 014 0374 Hydrogen (H...

  • Page 16: Flow Vs Pressure Drop

    Conversion Chart Flow vs Pressure Drop Petroleum Fluids 0.20-2.0 1/4" 1/2" 1-15 0.10-1.0 1-10 .02-.20 .05-.50 0.2-2.0 0.5-5.0 0.1-1.0 2 2.5 FLOW, GPM FLOW, GPM 5-50 3/4"/ 1" 10-150 1-1/4" / 1-1/2" 4-40 10-100 3-30 0.5-5.0 10-75 2-20 5-50 1-10 0.2-2.0 3-30 0 1 2 3...
  • Page 17 Conversion Chart Phosphate Esters 0.20-2.0 1/4" 1/2" 1-15 0.10-1.0 1-10 .02-.20 .05-.50 0.2-2.0 0.5-5.0 0.1-1.0 2 2.5 FLOW, GPM FLOW, GPM 5-50 3/4"/ 1" 10-150 1-1/4" / 1-1/2" 4-40 10-100 3-30 0.5-5.0 10-75 2-20 5-50 1-10 0.2-2.0 3-30 0 1 2 3 FLOW, GPM FLOW, GPM 1-15...
  • Page 18 Conversion Chart A.P.I. Oil 1/2" 1-15 .20-2.0 1/4" .10-1.0 1-10 0.5-5.0 0.2-2.0 FLOW, GPM FLOW, GPM 1-1/4"/ 1-1/2" 3/4" / 1" 4-40 10-100 10-75 3-30 5-50 2-20 3-30 FLOW, GPM FLOW, GPM Figure 13: A.P.I. oil flow vs pressure drop Page 18 VAM-UM-00646-EN-04 April 2017...
  • Page 19 Conversion Chart Water-Based Fluids 1/2" 1/4" .20-2.0 1-15 .10 -1.0 1-10 0.5-5.0 0.2-2.0 0.1-1.0 .05-.50 0.2-2.0 FLOW, GPM FLOW, GPM 1-1/4"/ 1-1/2" 3/4" / 1" 5-50 10-150 4-40 10-100 3-30 10-75 0.5-5.0 2-20 1-10 5-50 3-30 0.2-2.0 FLOW, GPM FLOW, GPM 20-180 3"...
  • Page 20 Conversion Chart Water 1/2" 1/4" .20-2.0 1-15 .10 -1.0 1-10 0.5-5.0 0.2-2.0 0.1-1.0 .05-.50 0.2-2.0 FLOW, GPM FLOW, GPM 1-1/4"/ 1-1/2" 3/4" / 1" 5-50 10-150 4-40 10-100 3-30 10-75 0.5-5.0 2-20 1-10 5-50 3-30 0.2-2.0 FLOW, GPM FLOW, GPM Figure 15: Water flow vs pressure drop Page 20 VAM-UM-00646-EN-04...
  • Page 21 Conversion Chart Caustic and Corrosive Liquids 3-30 1/4" 1/2" 15-150 2-20 10-100 5-50 3-25 FLOW, SCFM FLOW, SCFM 3/4" / 1" 100-1000 1-1/4"/ 1-1/2" 10-100 25-250 15-150 80-800 3-25 60-600 5-50 40-400 20-200 1000 FLOW, SCFM FLOW, SCFM Figure 16: Caustic and corrosive liquids flow vs pressure drop April 2017 VAM-UM-00646-EN-04 Page 21...
  • Page 22 Conversion Chart Air/Compressed Gases 3-30 1/4" 1/2" 15-150 2-20 10-100 1-10 5-50 3-25 0.5-5 FLOW, SCFM FLOW, SCFM 3/4" / 1" 100-1000 1-1/4"/ 1-1/2" 10-100 25-250 80-800 15-150 3-25 60-600 5-50 40-400 20-200 1000 FLOW, SCFM FLOW, SCFM Figure 17: Air and compressed gasses flow vs pressure drop Page 22 VAM-UM-00646-EN-04 April 2017...
  • Page 23 Conversion Chart Air/Caustic and Corrosive Gases 3-30 1/4" 1/2" 15-150 2-20 10-100 5-50 3-25 FLOW, SCFM FLOW, SCFM 3/4" / 1" 100-1000 1-1/4"/ 1-1/2" 10-100 25-250 15-150 80-800 3-25 60-600 5-50 40-400 20-200 1000 FLOW, SCFM FLOW, SCFM Figure 18: Air/caustic and corrosive gasses flow vs pressure drop April 2017 VAM-UM-00646-EN-04 Page 23...

  • Page 24: Specifications

    Specifications SPECIFICATIONS NEMA 12 & 13 (equivalent to IP52 & 54) Enclosure Rating NOTE: Does not apply to 1/4 in flow meter with strap Temperature Range –20…240° F (–20…116° C) Pressure Rating Liquids (1/4…1-1/2 in) 3500 psi (241 bar) maximum with a 3:1 safety factor (Aluminum/Brass) Gases (1/4…1-1/2 in) 1000 psi (69 bar) maximum with a 10:1 safety factor...

  • Page 25: Dimensions

    Dimensions DIMENSIONS Reed Switch Configuration with Enclosure Figure 19: Reed switch configuration with enclosure Nominal Length Length Length Width Width Width Cable Depth Offset Hole Dia. Port Size in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in.

  • Page 26: Microswitch Configuration

    Dimensions Microswitch Configuration Figure 20: Microswitch configuration Nominal Length Length Length Width Width Width Cable Depth Offset Hole Dia. Port Size in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) 1/4 in.

  • Page 27: Reed Switch Configuration With Strap Assembly

    Dimensions Reed Switch Configuration with Strap Assembly Figure 21: Reed switch configuration with strap assembly Nominal Length Width Depth Offset Flats in. (mm) Port Size in. (mm) in. (mm) in. (mm) in. (mm) in. (mm) 1/4 in. 4.80 1.68 2.10 0.84 0.88 1.00...
  • Page 28 The Americas | Badger Meter | 4545 West Brown Deer Rd | PO Box 245036 | Milwaukee, WI 53224-9536 | 800-876-3837 | 414-355-0400 México | Badger Meter de las Americas, S.A. de C.V. | Pedro Luis Ogazón N°32 | Esq. Angelina N°24 | Colonia Guadalupe Inn | CP 01050 | México, DF | México | +52-55-5662-0882 Europe, Eastern Europe Branch Office (for Poland, Latvia, Lithuania, Estonia, Ukraine, Belarus) | Badger Meter Europe | ul.
