7

OWA GENERAL DESCRIPTION

7.1 Intended Use

The OWA is a key component of the Honeywell Wireless Network for Secure Industrial Application (WNSIA). These
transmitters are available for various sensor types including Digital Inputs, Temperature, High Level Analog Inputs, Pressure
and Corrosion. The OWA uses a low-powered ISA100 2.4 GHz radio to communicate with Radio Infrastructure and Gateway
devices that are connected to a wired DCS network.

7.2 OWA Diagrams

Figure 1
shows unit-level drawings of the OWA.
8

PRODUCT SPECIFICATIONS

8.1 ISA100 Radio, 2.4 GHz

Warning! The OWA must be Professionally Installed in accordance with the requirements specified in this document. See
Section 10, for professional installation maximum TX power setting requirements. Only the specified TX power settings and
antenna as outlined in this document are valid for OWA installations.
Table 2 – Specifications of ISA100 Radio Module in OWA
Item
Wireless Standard
Data Rates and Modulation
Frequency Band
Module Transmit Power
Receive Sensitivity (typical)

8.2 OWA User Environment

Table 3 – User Environment Specifications for OWA
Item
Operating Temperature:
Storage Temperature:
Operating Humidity:
Other Environmental specifications and information may be found in the appropriate Instrument Specification available on the
Honeywell website.
OneWireless Adapter
Professional Installation Guide
FCC 15.247 / IEEE 802.15.4 Direct Sequence Spread Spectrum (DSSS), 2.4 GHz
Data Rate: 250 kbps
Modulation: Offset Quadrature Phase-Shift Keying (OQPSK – DSSS)
2,405 – 2,475 MHz
Maximum: 20 dBm
(Maximum transmit power will vary by channel)
-100 dBm
Specification
–40ºC to +85ºC (–40°F to +185°F)
–40ºC to +85ºC (–40°F to +185°F)
0 to 100% RH
Honeywell Documentation
XXXXXXXXX
Specification
Rev A2
2 November 2010
Page 11 of 20
