Operating instruction
Hydrolux® Leak locator
HLE 500
HLE 5000
Version 1.0
Produktbild wie in den Prospekten ohne Rahmen
Ansprechpartner Frau Badziura
Mess- und Ortungstechnik
Measuring and Locating Technologies
Elektrizitätsnetze
Power Networks
Kommunikationsnetze
Communication Networks
Rohrleitungsnetze
Water Networks
Leitungsortung
Line Locating
Edition: 02 (2005/02)
Advertisement
Table of Contents
Related Manuals for sebaKMT Hydrolux HLE 500
Summary of Contents for sebaKMT Hydrolux HLE 500
- Page 1 Operating instruction Hydrolux® Leak locator Produktbild wie in den Prospekten ohne Rahmen HLE 500 Ansprechpartner Frau Badziura HLE 5000 Version 1.0 Mess- und Ortungstechnik Measuring and Locating Technologies Elektrizitätsnetze Power Networks Kommunikationsnetze Communication Networks Rohrleitungsnetze Water Networks Leitungsortung Line Locating Edition: 02 (2005/02)
- Page 2 Operating instructions HLE 500/5000 MAN_HLE500_HLE5000_eng_02...
- Page 3 Quality Systems with the numbers EN 19677 and DQS 19677-01. How do you contact us? SebaKMT Mess- und Ortungstechnik GmbH Dr.-Herbert-Iann-Str. 6 96148 Baunach, Germany Telephone: +49 (0) 9544 680 Fax: +49 (0) 9544 2273 Email: sales@sebakmt.com Internet: www.sebakmt.com MAN_HLE500_HLE5000_eng_02...
- Page 4 Operating instructions HLE 500/5000 MAN_HLE500_HLE5000_eng_02...
-
Page 5: Table Of Contents
Operating instructions HLE 500/5000 Table of contents Description General Construction Technical data Delivery includes 1.4.1 5000/500 equipment 1.4.2 Selectable microphone sets 1.4.3 Optional accessories Getting to know the HLE 5000/500 HLE 5000/500 controls Connections at the side Battery chamber Automatic battery monitoring Illumination of the LCD display Microphones 2.6.1... - Page 6 Operating instructions HLE 500/5000 List of illustrations Fig 1 : HLE 5000/500 control panel ...........5 Fig 2 : Side view left and right with connections........6 Fig 3 : Base plate with locking screws..........7 Fig 4 : PAM U with sensor rod............9 Fig 5 : PAM U with magnet..............9 Fig 6 :...
-
Page 7: Description
Operating instructions HLE 500/5000 Description General The new HLE 5000/500 leak locator comprehensively deals with finding leaks in pipe networks for the supply of drinking water. The equipment can of course be used on other pipe systems, provided that the liquid comes out of the pipe under pressure and that the resulting noise carries to the surface of the ground. -
Page 8: Construction
Operating instructions HLE 500/5000 Construction The leak location equipment is in a splash-proof housing made of robust plastic. The few control buttons are so arranged that they can also be operated wearing gloves. The display is equipped with backlighting. That means that work is also possible under poor lighting conditions, or at night. -
Page 9: Delivery Includes
Operating instructions HLE 500/5000 Delivery includes 1.4.1 5000/500 equipment Leak location equipment with batteries HLE 5000 or HLE 500 Headphones KR 2 (extraneous noises filtered) Carrying strap Case Operating instructions BED HLE 5000 1.4.2 Selectable microphone sets Professional set consisting of: Piezo ground microphone PAM W-1 (with wind shield) -
Page 10: 1.4.3 Optional Accessories
Operating instructions HLE 500/5000 1.4.3 Optional accessories Radio module for wireless PAM 868 transmission between microphone and amplifier Sensor rod extension VST T-1 Special headphones (highly insulated from extraneous noise) Sliding adapter 42 mm AD S-42 Sliding adapter 20 mm AD S-20 Magnetic adapter MAN_HLE500_HLE5000_eng_02... -
Page 11: Getting To Know The Hle 5000/500
Operating instructions HLE 500/5000 Getting to know the HLE 5000/500 Before putting the equipment into operation, you should get to know all of the controls, the devices which can be connected and the power supply. HLE 5000/500 controls LCD display Volume with backlight control... -
Page 12: Battery Chamber
Fig 2 : Side view left and right with connections The sockets are only suitable for headphones and microphones from SebaKMT. Connecting other headphones or microphones can lead to equipment failure or damage to the HLE 5000/500. Battery chamber After opening the base flap (fig. -
Page 13: Automatic Battery Monitoring
Operating instructions HLE 500/5000 Locking screws Fig 3 : Base plate with locking screws Automatic battery monitoring When working with the leak detection equipment, the state of the batteries is monitored continuously. Should the battery voltage drop too far, this will be indicated by a flashing battery symbol in the top right of the display. -
Page 14: Pam
Operating instructions HLE 500/5000 2.6.1 PAM W-1 The PAM W-1 is an active piezo ground microphone roads hard ground coverings. The microphone is particularly well shielded from the wind, using a bell-shaped guard. The carrying pole can be removed with a quarter turn to the left. -
Page 15: 2.6.2 Pam U
Operating instructions HLE 500/5000 2.6.2 PAM U PAM U was developed primarily as a sensor rod or contact microphone, but can be used universally by exchanging the contact point for various adapters. Sensor rod variant: In this variant the PAM U is suitable for listening to valves, hydrants or even directly on a pipe. -
Page 16: Headphones
Operating instructions HLE 500/5000 Take care: When removing the microphone from a valve, always pull the body of the microphone and not the cable, otherwise you may damage the cable. 3-point foot variant: By screwing in a 3-point foot, the PAM U can also be used as a ground microphone on a hard surface. -
Page 17: Practical Work
Operating instructions HLE 500/5000 Practical work Now that you have got to know the HLE 5000/500 leak detector, you can start with the practical use. Headphones and microphone connection Before switching on the HLE 5000/500, connect both the headphones and the microphone. The reverse is true when switching off: Always switch the equipment off first and then remove the microphone and headphones. -
Page 18: Volume And Amplification
Operating instructions HLE 500/5000 Setting the headphone volume 0 – 4000 Hz Fig 8 : Opening menu after switch-on Amplification setting Volume and amplification The HLE 5000/500 is equipped with separate controls for volume and amplification. Thus, every user can make the best settings for their personal characteristics. -
Page 19: Setting The Gain
Operating instructions HLE 500/5000 3.3.2 Setting the gain The amplification of the microphone signal, the gain, is set via the two soft keys, bottom right (see fig. 10). The gain is shown via a horizontal bar. On top of this bar the gain values of 1 to 8 can be seen. -
Page 20: Filter Setting (Only Hle5000)
Operating instructions HLE 500/5000 Current value Minimum value 0 – 4000 Hz Fig 11 : Current and minimum value Filter setting (only HLE5000) Filter settings on the HLE 5000 are very easy. Use the soft key button in the main menu, to get in to the filter settings. -
Page 21: Filter Selection In Practice
Operating instructions HLE 500/5000 ® HYDROLUX 1800 – 4000 Hz Fig 13 : Adjusting the lower filter cut-off frequency The upper cut-off frequency is adjusted in a similar way, using the two soft key buttons to the right, underneath (see fig. 14). ®... -
Page 22: Filter Selection A (Ground Microphone Pam W-1, Pam U With 3-Point Foot)
Operating instructions HLE 500/5000 chosen. Should a measurement not be successful, then a broadband setting is to be recommended, to ensure that none of the leak sound is filtered away. 3.6.1 Filter selection A (Ground microphone PAM W-1, PAM U with 3-point foot) As a standard setting, a filter from 240 Hz - 540 Hz should be used. -
Page 23: Fig 16 : Histogram Measurement
Operating instructions HLE 500/5000 The individual histogram displays consist of a dual segment analysis (DSA), which show the current value and the minimum value. This DSA is shown in fig. 15. The narrow segment stands for the current value and the wide segment shows the minimum value, which is of particular significance when looking for burst pipes. -
Page 24: Long-Term Measurement (Hle 5000 Only)
Operating instructions HLE 500/5000 The histogram measurement as shown in fig. 16 shows very different current values. On the other hand the 5th DSA shows a clear maximum for the minimum values. The burst pipe is thus in the vicinity of the 5th measurement location. Additionally a small graphical symbol indicates the maximum measurement for easy recognition. -
Page 25: Location Of Pipes Using The Rsp-3 Or Pwg (Hle 5000 Only)
Operating instructions HLE 500/5000 3.10 Location of pipes using the RSP-3 or PWG (HLE 5000 only) To switch the HLE 5000 into this mode, after switching on, soft key 2 (underneath the impulse symbol ) should be pressed whilst the welcome image is displayed. The HLE 5000 is now in pipe location mode, shown by the impulse symbol at the top edge of the display. -
Page 26: Faults
Operating instructions HLE 500/5000 Faults Can't switch on Presumably the headphones are not plugged in or headphones are being used which do not belong to the system. Battery monitor does not react One or more batteries are incorrectly fitted. Open base flap and check the polarity of the batteries.
