TCL
L1 Service Manual
Communication Ltd.
MOVETIME Track & Talk
Watch
SW10
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.
Rev.
Page
SW10 Level 1 Service Manual
1.4
1/19
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOVETIME Track & Talk watch and is the answer not in the manual?

Questions and answers

Related Manuals for Alcatel MOVETIME Track & Talk watch

Summary of Contents for Alcatel MOVETIME Track & Talk watch

  • Page 1 L1 Service Manual Communication Ltd. MOVETIME Track & Talk Watch SW10 Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior notice on the characteristics of described equipments. Rev. Page SW10 Level 1 Service Manual 1/19 All rights reserved.
  • Page 2 L1 Service Manual Communication Ltd. Preliminary draft Jane Chen Rev. Date Modification description Prepared By Checked By Approved By Rev. Page SW10 Level 1 Service Manual 2/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 3 L1 Service Manual Communication Ltd. Rev. Page SW10 Level 1 Service Manual 3/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 4: Table Of Contents

    L1 Service Manual Communication Ltd. Content 1. General ............................. 5 2. Portable Label ..........................6 2.1 Label zones ............................6 2.2 Commercial label samples: ......................7 2.3 L1 Spare Part List ........................... 7 2.4.1. Charging cable (for end user) ....................8 2.4.2.

  • Page 5: General

    L1 Service Manual Communication Ltd. 1. General MOVE TIME Track & Talk Watch – SW10 is a fashion accessory of smart phone. It pairs with phone devices supporting Android 4.3 or later versions, IOS7 or later versions. It is safe to wear it in the rain. Detail features MOVETIME Track &...

  • Page 6: Portable Label

    L1 Service Manual Communication Ltd. Sensor Accelerator 3D Calculate pace, motion monitoring Nano SIM connector Connectors Pogo Pins Charging input port 2. Portable Label 2.1 Label zones Printing Zone definition (TA74-3DS12044AAAA--------For General 23× 15mm) Rev. Page SW10 Level 1 Service Manual 6/19 All rights reserved.

  • Page 7: Commercial Label Samples

    L1 Service Manual Communication Ltd. 2.2 Commercial label samples: 2.3 L1 Spare Part List Please get the latest SPL in Forlog system. Rev. Page SW10 Level 1 Service Manual 7/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 8: Charging Cable (For End User)

    L1 Service Manual Communication Ltd. 2.4.1. Charging cable (for end user) (PN: CDB0000056C1) 2.4.2. Charging cable (for CC) (PN: CDA0000079CF) Rev. Page SW10 Level 1 Service Manual 8/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 9: Furnished Sim Card Cover And Screw

    L1 Service Manual Communication Ltd. 2.4.3. Furnished SIM Card Cover and screw 2.4.4. Screwdriver Rev. Page SW10 Level 1 Service Manual 9/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

  • Page 10: Maintenance Policy

    L1 Service Manual Communication Ltd. 3. MAINTENANCE POLICY 3.1 VISUAL MECHANICAL INSPECTION Mechanical warranty checked items:  Corrosion: corrosion on the USB connectors, SIM connectors, and other metal surfaces  Holes (diam > 1mm): Holes on any surface, including the furnished front casing, furnished back casing and USB model, etc.

  • Page 11: Software Download

    L1 Service Manual Communication Ltd. 4. Software download It is authorized to download software for the watch which needs to be updated. This downloading tool is called “MultiPortFlashDownloadProject”. Thus internet access is necessary. TS Website: https://css.tclmobile.cn/. 4.1 Equipments requested when download： ⑴...
  • Page 12 L1 Service Manual Communication Ltd. Step 3: Power on the watch and plug it to the PC. Check Whether the COM is the same as the USB port in your PC. If not, please change the COM Port in “Options”. Rev.
  • Page 13 L1 Service Manual Communication Ltd. Step 4: Click “File” to choose the DA file “MTK_AllInOne_DA.bin”. Rev. Page SW10 Level 1 Service Manual 13/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 14 L1 Service Manual Communication Ltd. Step 5: Click “Image Folder” to choose software file “build”. You could download the software file in CSS Rev. Page SW10 Level 1 Service Manual 14/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 15 L1 Service Manual Communication Ltd. Website. And then click Yes to confirm. Rev. Page SW10 Level 1 Service Manual 15/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 16 L1 Service Manual Communication Ltd. Step 6: Power off the watch and click “Sel All” and “Start All”, and then replug the watch to the PC. The tool will search the port of the watch. Step 7: The COM port is recognized and the CU of the watch is displayed. Rev.
  • Page 17 L1 Service Manual Communication Ltd. Step 8: Upgrading process. Step 9: Upgrading finish. Rev. Page SW10 Level 1 Service Manual 17/19 All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
  • Page 18 L1 Service Manual Communication Ltd. Note: If the COM port cannot be recognized as the picture below. Check whether the “backup” folder and “backup_and_restore_data” folder in the tool folder are all empty. If not, please delete all the files in these two folders. Rev.
  • Page 19 L1 Service Manual Communication Ltd. If you have any question or problem, please feel free to contact us (tct_gcc_techSupport@tcl.com) . Thanks for your cooperation. TCL Communication Ltd. Global Customer Service TS Dept. Jun. 3 , 2016 Rev. Page SW10 Level 1 Service Manual 19/19 All rights reserved.
