STIEBEL ELTRON DNM 3 Operation And Installation

STIEBEL ELTRON DNM 3 Operation And Installation

Hydraulically controlled, non-pressurised mini instantaneous water heater
Hide thumbs Also See for DNM 3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation & Operation, Operating and Installation Instruction
BEDIENUNG UND INSTALLATION
OPERATION AND INSTALLATION
UTILISATION ET INSTALLATION
BEDIENING EN INSTALLATIE
OBSŁUGA I INSTALACJA
OBSLUHA A INSTALACE
OBSLUHA A INŠTALÁCIA
OPERAREA ŞI INSTALAREA
ЭКСПЛУАТАЦИЯ И МОНТАЖ
Hydraulisch gesteuerter druckloser Mini-Durchlauferhitzer | Hydraulically controlled,
non-pressurised mini instantaneous water heater | Mini chauffe-eau instantané et à
écoulement libre à gestion hydraulique | Hydraulisch gestuurde drukloze mini-doorstromer
| Hydraulicznie sterowany bezciśnieniowy mini przepływowy ogrzewacz | Malý hydraulicky
řízený beztlakový průtokový ohřívač | Hydraulicky riadený mini prietokový ohrievač | Mini
încălzitor instant controlat electronic | Малогабаритный безнапорный проточный нагреватель с
гидравлическим управлением
» DNM 3
» DNM 4
» DNM 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DNM 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STIEBEL ELTRON DNM 3

Summary of Contents for STIEBEL ELTRON DNM 3

  • Page 1 | Hydraulicznie sterowany bezciśnieniowy mini przepływowy ogrzewacz | Malý hydraulicky řízený beztlakový průtokový ohřívač | Hydraulicky riadený mini prietokový ohrievač | Mini încălzitor instant controlat electronic | Малогабаритный безнапорный проточный нагреватель с гидравлическим управлением » DNM 3 » DNM 4 » DNM 6...

  • Page 2: Table Of Contents

    CONTENTS | SpECIaL INfORMaTION SpECIaL INfORMaTION SPECIAL INFORMATION OPERATION General information ��������������������������������������� 25 - The appliance may be used by children aged 3 Safety �������������������������������������������������������� 27 and older and persons with reduced physical, Appliance description ������������������������������������� 28 sensory or mental capabilities or a lack of ex- Settings �����������������������������������������������������...

  • Page 3: Operation

    oPerATIoN general information oPerATIoN - The power cable must only be replaced (for ex- ample if damaged) by a qualified contractor au- thorised by the manufacturer, using an original spare part. General information - Secure the appliance as described in chapter "In- The chapter "Operation"...
  • Page 4 oPerATIoN general information 1.1.2 Symbols, type of risk Other symbols in this documentation symbol Type of risk Note Injury Notes are bordered by horizontal lines above and below the text. General information is identified by the adjacent symbol. Electrocution f Read these texts carefully. Burns (burns, scalding) symbol...

  • Page 5: Safety

    oPerATIoN safety Safety WARNING Injury The appliance may be used by children aged 3 and older Intended use and persons with reduced physical, sensory or mental capabilities or a lack of experience and know-how, pro- The appliance is intended for domestic use. It can be used safely vided that they are supervised or they have been in- by untrained persons.

  • Page 6: Appliance Description

    oPerATIoN Appliance description Settings Material losses Ensure that the non-pressurised appliance is not exposed The appliance heating system switches on automatically as soon to any pressure as this could cause irreparable damage: as you open the DHW valve at the tap or activate the sensor of a f Only use the special aerator provided.

  • Page 7: Troubleshooting

    INsTALLATIoN Troubleshooting INsTALLATIoN f Check the taps regularly. Limescale deposits at the tap out- lets can be removed using commercially available descaling agents. f Have the electrical safety of the appliance regularly checked by a qualified contractor. Safety f Regularly descale or replace the special aerator (see chapter Only a qualified contractor should carry out installation, commis- "Appliance description / Accessories").

  • Page 8: Appliance Description

    INsTALLATIoN Appliance description Instructions, standards and regulations - SR 5: Part number 270582 for DHM 6 and DHM 7 Note * For use in thread M22/M24. Observe all applicable national and regional regulations and instructions. Non-pressurised taps - WEN Sensor tap for washbasins The specific electrical resistance of the water must not fall below - MAW Wall mounted tap for oversink installation that stated on the type plate.

  • Page 9: Installation

    INsTALLATIoN Installation 10.2 Installation options Note Fitting the special aerator supplied provides an optimum 10.2.1 Undersink installation, non-pressurised, with non- water jet. pressurised tap 10. Installation 10.1 Installation location Install the appliance in a room free from the risk of frost and near the draw-off tap.
  • Page 10 INsTALLATIoN Installation      f Using pliers, break out the knock-out for the power cable in the appliance cover. Correct the contours with a file if necessary. f Undo the cover fixing screws by two turns. f Use the appliance back panel as a drilling template. f Undo the snap fastener using a screwdriver.
  • Page 11 INsTALLATIoN Installation 10.2.2 Oversink installation, non-pressurised, with non-  pressurised tap   f Route the power cable through the cable entry in the back panel. f Hook in the appliance cover with the heater at the bottom. f Click the heater into place using the snap fastener. f Secure the appliance cover with the cover fixing screws.

  • Page 12: Commissioning

    INsTALLATIoN Commissioning 10.3 Making the electrical connection Material losses Observe the type plate. The specified voltage must match DANGER Electrocution the mains voltage. Carry out all electrical connection and installation work in accordance with relevant regulations. f Connect the power cable as shown in the wiring diagram (see chapter "Specification / Wiring diagram").

  • Page 13: Appliance Shutdown

    INsTALLATIoN Appliance shutdown 11.2 Appliance handover 13. Troubleshooting f Explain the appliance function to users and familiarise them Problem Cause remedy with its operation. The appliance will not The aerator in the tap is Clean and/or descale the f Make the user aware of potential dangers, especially the risk start despite the DHW scaled up or dirty.

  • Page 14: Specification

    INsTALLATIoN Specification f Close the shut-off valve in the cold water inlet line. Replacing the power cable for the DNM 6 f Open the draw-off valve. f When replacing the cable for the DNM 6, use a power cable with 4 mm² cross-section. f Undo the water connections on the appliance.
  • Page 15 X Flow rate in l/min Y Temperature increase in K 1 3.5 kW - 230 V 2 4.4 kW - 230 V 3 5.7 kW - 230 V Example DNM 3 with 3.5 kW Flow rate l/min Increasing the temperature Cold water supply temperature °C...
  • Page 16 An outlet temperature of 50 °C can be achieved with the For the specific electrical resistance and specific electrical lowest possible flow rate and the following cold water conductivity, see "Data table". inlet temperatures: - DNM 3 > 18 °C standard specifi- - DNM 4 > 21 °C cation 20 °C 25 °C...
  • Page 17 INsTALLATIoN Specification 15.6 Data table DNM 3 DNM 4 DNM 6 185411 185415 185418 Electrical data Rated voltage Rated output Rated current 13.3 14.5 15.2 15.8 16.7 18.2 19.1 21.6 23.6 24.7 25.8 MCB/fuse rating Frequency 50/60 50/60 50/60 50/60...
  • Page 18 INsTALLATIoN Specification DNM 3 DNM 4 DNM 6 Versions Oversink installation Undersink installation Open vented type IP rating IP25 IP25 IP25 Protection class Insulating block Plastic Plastic Plastic Heating system heat generator Bare wire Bare wire Bare wire Cover and back panel...

  • Page 19: Guarantee

    GUARANTEE | ENVIRONMENT AND RECYCLING Guarantee The guarantee conditions of our German companies do not apply to appliances acquired outside of Germany. In countries where our subsidiaries sell our products a guarantee can only be issued by those subsidiaries. Such guarantee is only grant- ed if the subsidiary has issued its own terms of guarantee.
  • Page 20 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de Kundendienst STIEBEL ELTRON GmbH & Co. KG Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.

This manual is also suitable for:

Dnm 4Dnm 6
