USER MANUAL
DIGITAL VIDEO DR-N4 / 8/16
Page: - 1 -
Page: - 1 -
Page: - 1 -
Digital video recorders DR-N4 / DR-N8
/ N16-DR
User Manual
DSE srl - ITALY - WWW.DSE.EU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR-N8 and is the answer not in the manual?

Questions and answers

Related Manuals for DSE DR-N8

Summary of Contents for DSE DR-N8

  • Page 1 USER MANUAL DIGITAL VIDEO DR-N4 / 8/16 Page: - 1 - Page: - 1 - Page: - 1 - Digital video recorders DR-N4 / DR-N8 / N16-DR User Manual DSE srl - ITALY - WWW.DSE.EU...

  • Page 2: Product Overview

    1.1 Product Features • Possibility of connecting 4 (DR-N4), 8 (DR-N8) or 16 (DR-N16) cameras in both color and B / W • 1 independent audio input for each camera •...

  • Page 3: Specifications

    Protocol Pelco P / D, Samsung, Panasonic etc. video Backup AVI format, MP4, H264 Supply 12VDC power supply provided Absorption 10-15W Temperature - 10 + 40 ° C Humidity 10% -90% RH Dimensions mm. 315x224x52 315x224x52 435x340x55 DSE srl - ITALY - WWW.DSE.EU...

  • Page 4: Front Controls

    In the DR-N8-N16 model and DR for space reasons some buttons control 2 channels: for example, the 1/11 button selects the camera 1 if pressed once and 11 when pressed two times consecutively.
  • Page 5 13 Front Tray (DR-N16 ONLY) Accesses the pull-out drawer for removable disk. 14 Button NO ALARM 14 Button NO ALARM Pressing this button will access the alarm source screen to silence any kind of alarm or buzzer. DSE srl - ITALY - WWW.DSE.EU...
  • Page 6 DVR allows you to use it. 3 (DR-N16 only) - auxiliary video output connector (CALL OUT) DSE srl - ITALY - WWW.DSE.EU...
  • Page 7 3 (DR-N4 only) - Audio output connector (AUDIO OUT) This RCA connector allows you to connect an external audio speakers to play the sound live or recorded. In DR-N8 / 16 models this output is also available, but is included in the audio cable supplied.

  • Page 8: Remote Control

    6 - Menu / ESC - Press to open the programming menu and to exit 6 - Menu / ESC - Press to open the programming menu and to exit 6 - Menu / ESC - Press to open the programming menu and to exit DSE srl - ITALY - WWW.DSE.EU...
  • Page 9 15 - Multivision Change the screen division. 16 - REC Start manual recording 16 - REC Start manual recording Any other buttons on the remote control other than those described have no application of these models. DSE srl - ITALY - WWW.DSE.EU...

  • Page 10: Installation

    SATA type 3.5 " Then install the hard disk as follows: 1. Turn off the appliance open the VCR by removing the 1. Turn off the appliance open the VCR by removing the DSE srl - ITALY - WWW.DSE.EU...
  • Page 11 This way you can hear the sound from the microphone inputs and during playback. • The connection to the VCR network takes place via the outlet of the rear RJ45 network. Before using the LAN connection set parameters DSE srl - ITALY - WWW.DSE.EU...
  • Page 12 A / B). The communication settings (protocol, speed, etc. of the bus) is operating in RS485 configuration menu of the DVR and must be consistent with the commands accepted by the cameras used. The DR series DVR support PelcoD protocol used by DSE speed dome cameras, and various other protocols from other manufacturers ..

  • Page 13: Language Selection

    Turn on your DVR Press the ON / OFF button and wait until the startup is completed • Press MENU Enter the corresponding administrator password. Factory ( Admin: Enter the corresponding administrator password. Factory ( Admin: 888888) DSE srl - ITALY - WWW.DSE.EU...
  • Page 14 WARNING - If the configuration menu does not appear on the screen to see the next paragraph. 3.4 Selection of the screen displaying the menu The DR-N4 video recorders and DR-N8 show the programming menu only on a video output or BNC or VGA, not both.
  • Page 15 You can enter up to 7 users: an administrator and six users with different levels of fully configurable access. To turn off your DVR, press the POWER button icon in the menu bar, enter the password to turn off, then bring back the ON / OFF switch to OFF. DSE srl - ITALY - WWW.DSE.EU...
  • Page 16 Pressing the ESC button on the keyboard or the right mouse button, or even the MENU button on the remote control, will appear at the lower screen bar system information, which is as follows: DSE srl - ITALY - WWW.DSE.EU...
  • Page 17 "motion detection" • the camera is recording triggered by an alarm • the camera is recording triggered by an alarm • the camera and manual recording • the camera and manual recording • 4.2 Toolbar DSE srl - ITALY - WWW.DSE.EU...
  • Page 18 (from 10 seconds to 60 seconds earlier) or quickly search images according to date and time. • DVR Shutdown • Multivision Management - Allows you to choose how many cameras simultaneously view: one, 4, 6, 9, 16 cameras DSE srl - ITALY - WWW.DSE.EU...
  • Page 19 Freeze - This option allows you to freeze the screen image during live viewing • PIP - Allows viewing of two cameras, a full screen and the other in a smaller window that you can move to your liking. DSE srl - ITALY - WWW.DSE.EU...

  • Page 20: Formatting The Hard Disk

    After that enter the section called MANAGEMENT menu, then click the HDD MANAGEMENT voice It will appear on a window screen that lists the hard disk installed in the DVR indicating the reference, the total capacity, available space and HDD status. capacity, available space and HDD status. DSE srl - ITALY - WWW.DSE.EU...

  • Page 21: Manual Record

    MANUAL RECORD - Click the MANUAL RECORDING button in the toolbar and in the next window, choose which cameras enable immediate recording. The recorded files in manual recording are defined REGISTRATION NORMAL. DSE srl - ITALY - WWW.DSE.EU...

  • Page 22: Automatic Registration

    PROGRAM REGISTRATION At the top it is shown the camera which is being programmed, if you want to edit it is necessary to cancel and select another one. And 'the ALL option available for DSE srl - ITALY - WWW.DSE.EU...
  • Page 23 To review the recorded footage choose the search button in the toolbar In the search window must stipulate the date the subject of research in the boxes at the top, then click the cameras of interest. With the left mouse button DSE srl - ITALY - WWW.DSE.EU...

  • Page 24: Playback Controls

    In playback, you can do it digital zoom of a detail drawing the interest frame with the mouse while holding down the left mouse button. 4.6 Backup to external USB devices 4.6 Backup to external USB devices DSE srl - ITALY - WWW.DSE.EU...
  • Page 25 Pressing the Backup button the DVR will automatically detect the backup drive connected to the USB port. E 'can select the video format in which to export movies. The following options are available: • H.264 RAW • MP4 • AVI DSE srl - ITALY - WWW.DSE.EU...
  • Page 26 The DVRs allow to control the speed dome cameras connected to the rear serial port. To do this you need to choose a single camera full screen and then press the PTZ button It opens the PTZ control panel that allows the following commands: DSE srl - ITALY - WWW.DSE.EU...
  • Page 27 The advanced functions panel allows you to control auxiliary functions if supported by the camera (wiper, lighting etc.), to set and recall PRESET, to set and start the automatic shift among multiple preset (CRUISE) to set up and start of the paths, or patterns , custom (TRACK). DSE srl - ITALY - WWW.DSE.EU...
  • Page 28 ▲ ▼ to select the sub-function to be changed. another and then the keys ▲ ▼ to select the sub-function to be changed. Below are the programming tree that summarizes all of the options contained in the windows. DSE srl - ITALY - WWW.DSE.EU...
  • Page 29 USER MANUAL DIGITAL VIDEO DR-N4 / 8/16 Page: - 29 - Page: - 29 - Page: - 29 - DSE srl - ITALY - WWW.DSE.EU...

  • Page 30: System Menu

    ADD USER • The DVR can handle up to 7 people (6 + administrator). Acting here to customize the name of the ADD USER • The DVR can handle up to 7 people (6 + administrator). Acting here to customize the name of the system users. DSE srl - ITALY - WWW.DSE.EU...
  • Page 31 MANAGING USERS ONLINE • Summarizes the users connected and the opportunity is to disconnect or reconnect the system. In this section, the content is important because of the bandwidth consumed by each remote connection. DSE srl - ITALY - WWW.DSE.EU...
  • Page 32 DVR. This section is accessible only by ADMIN code. All licenses are different depending on whether they run locally or remotely. CONFIGURATION PASSWORD • to change user passwords CONFIGURATION PASSWORD • to change user passwords CONFIGURATION PASSWORD • to change user passwords DSE srl - ITALY - WWW.DSE.EU...
  • Page 33 SPOT CONFIGURATION • This feature is only available on the DR-N16 model is used to establish the display SPOT CONFIGURATION • This feature is only available on the DR-N16 model is used to establish the display visible in sequence from the DSE srl - ITALY - WWW.DSE.EU...
  • Page 34 WAY MANAGEMENT RESOURCES (DR-N8 only) • This section allows to distribute the DVR resources in a WAY MANAGEMENT RESOURCES (DR-N8 only) • This section allows to distribute the DVR resources in a WAY MANAGEMENT RESOURCES (DR-N8 only) •...

  • Page 35: Recording Menu

    RECORDING RESOLUTION • to select which recording resolution to use. Three options available: CIF (352x288), HALF-D1 (704x288), D1 (704x576). A higher resolution is more occupied space on the hard disk and a maggiora occupied bandwidth network. DSE srl - ITALY - WWW.DSE.EU...
  • Page 36 Note that for each camera it is possible to set a sub different queues according to the importance thereof. 5.4 Video Menu The video menu is divided into SIMPLE CONFIGURATION and ADVANCED CONFIGURATION. EASY CONFIGURATION In include: DSE srl - ITALY - WWW.DSE.EU...
  • Page 37 The selection of masks is done very comfortably with the mouse by dragging the arrow while pressing the left button. Once you completed the selection of the detection mask click with the right mouse button or press the ESC key to exit. DSE srl - ITALY - WWW.DSE.EU...
  • Page 38 ALARM ZOOM OUT the system will display the full screen camera that has detected a movement (select the cameras that follow this rule); if you check ALARM OUT the output is enabled DSE srl - ITALY - WWW.DSE.EU...
  • Page 39 OFFSET ROOM • spontandola to adjust the image display left or right 5.5 NETWORK menu (NET) In .NET menu the user sets the parameters concerning the network connection for remote control of the DVR. DSE srl - ITALY - WWW.DSE.EU...
  • Page 40 If it can not get from your provider, all of the range DVR support DDNS service (Dynamic DNS) that allow you to constantly monitor the machine's IP address. These services, DSE srl - ITALY - WWW.DSE.EU...
  • Page 41 AUTOMATIC REGISTRATION • The DVR can be configured to automatically register on a software CMS (Central Monitoring Station), by entering the IP address of the SERVER, PORT SERVER and Interval in seconds to wait between an unsuccessful attempt and the following connection. DSE srl - ITALY - WWW.DSE.EU...
  • Page 42 MOBILE DOOR • used to set the network port to be used for connecting mobile phone or PDA. By default the port is set 705 0. is set 705 0. is set 705 0. DSE srl - ITALY - WWW.DSE.EU...
  • Page 43 Available only in the DR-N16 . It allows the use of a service . It allows the use of a service . It allows the use of a service . It allows the use of a service DSE srl - ITALY - WWW.DSE.EU...

  • Page 44: Alarm Menu

    (NO) and normally closed (NC). EVENT MANAGEMENT • click EVENT MANAGEMENT • click EVENT MANAGEMENT • click to access the Management Window events DSE srl - ITALY - WWW.DSE.EU...
  • Page 45 EXCEPT FOR ACTION • clicking It enters a screen to manage DVR behavior in case of exceptional events: HDD full, network disconnected and conflicting IP addresses. You 'can turn out, buzzer and also send email and FTP upload. DSE srl - ITALY - WWW.DSE.EU...
  • Page 46 ALL, ALARM, EXCEPTION (exceptional event eg. Video lack, failure, etc.), OPERATION (operator operations such as ignition, configurations, etc.). After choosing the event and set the time interval in which to search click Search to DSE srl - ITALY - WWW.DSE.EU...
  • Page 47 MAC ADDRESS • MAC address of DVR MAC ADDRESS • MAC address of DVR MAC ADDRESS • MAC address of DVR DVR ID • DVR name DVR ID • DVR name DVR ID • DVR name DSE srl - ITALY - WWW.DSE.EU...
  • Page 48 LOGOUT • to make the LOGOUT. Once the password LOGOUT will need to re-enter again to return to the LOGOUT • to make the LOGOUT. Once the password LOGOUT will need to re-enter again to return to the programming menu. DSE srl - ITALY - WWW.DSE.EU...
  • Page 49 The most complete remote access is made with the Internet Explorer browser. To connect to the DVR with Internet Explorer browser enter the IP address of the DVR in the address bar and press Enter to access the LOGIN DVR box. On first access, depending on your browser security settings you can DSE srl - ITALY - WWW.DSE.EU...
  • Page 50 The password to use the factory is Admin ( with a capital A) PW: 888888 Select AUTOMATION TO OPEN PREVIEW to immediately view the cameras, alternatively, once you click LOGIN OPEN ALL in the lower left to see all the cameras installed in the DVR. DSE srl - ITALY - WWW.DSE.EU...
  • Page 51 As an alternative to OPEN ALL command is You can start playing inidvidualmente cameras by double-clicking in this area. 6 Toolbar You can start playing inidvidualmente cameras by double-clicking in this area. 6 Toolbar DSE srl - ITALY - WWW.DSE.EU...

  • Page 52: Alarm Notification

    The Internet Explorer interface allows you to configure the DVR remotely. Press PARAMETERS top left. The Internet Explorer interface allows you to configure the DVR remotely. Press PARAMETERS top left. The Internet Explorer interface allows you to configure the DVR remotely. Press PARAMETERS top left. DSE srl - ITALY - WWW.DSE.EU...
  • Page 53 Once you made all the changes you send the programming to the DVR by pressing SAVE PARAMETERS. It 'also available RESTORE DEFAULT button to reset the factory settings 6.5 Remote Play recordings The Explorer interface allows you to search and play the recorded files remotely by pressing the PLAYBACK button DSE srl - ITALY - WWW.DSE.EU...
  • Page 54 / 8x 1 / 16x) 7 CONTRAST + 8 CONTRAST - 9 BRIGHT '+ 10 BRIGHTNESS '- 11 AUDIO / 8x 1 / 16x) 7 CONTRAST + 8 CONTRAST - 9 BRIGHT '+ 10 BRIGHTNESS '- 11 AUDIO ON / OFF DSE srl - ITALY - WWW.DSE.EU...
  • Page 55 IE TAB V2 you need to install a free add-on called IE TAB V2 Go to the Firefox add-ons management and search in the search box: IE Tab DSE srl - ITALY - WWW.DSE.EU...
  • Page 56 ACCESS GOOGLE CHROME Although IE is the reference browser for remote connection to the DVR DR series it is also possible to use Chrome. E 'need to install the IE add-TAB seen as just for firefox. DSE srl - ITALY - WWW.DSE.EU...
  • Page 57 A DVR is connected rule to a local LAN that connects to the Internet via a Router. If we use for remote connection to an internal PC network, the DVR address (typically the 192.168.XXX.XXX type) is directly DSE srl - ITALY - WWW.DSE.EU...
  • Page 58 1 - Mapping router ports - In setting up the DVR to enable 1 - Mapping router ports - In setting up the DVR to enable 1 - Mapping router ports - In setting up the DVR to enable DSE srl - ITALY - WWW.DSE.EU...
  • Page 59 3 - Go to the website WWW.IPREMOTEVIEW.COM and enter the ID of your DVR in the box 3 - Go to the website WWW.IPREMOTEVIEW.COM and enter the ID of your DVR in the box DSE srl - ITALY - WWW.DSE.EU...
  • Page 60 Internet and without DDNS serivizi. The service supports only Internet Explorer browser. For the proper functioning of the connection you can be required to enter the site IPREMOTEVIEW.COM among the sites considered safe by Internet Explorer DSE srl - ITALY - WWW.DSE.EU...

  • Page 61: Windows Mobile

    If you have a PDA with Symbian OS found in the Kweye_JH_3rd_1222.sisx or Kweye_JH_5th1222.sisx file to the DVR Kit CD (depending on your phone) to be installed on your PDA following the instructions of the equipment. DSE srl - ITALY - WWW.DSE.EU...
  • Page 62 If you have an iPhone 3GS / 4/5 must connect to APPSTORE and install the free Kweye (single channel application) or KWeye + (multi-channel). If you have an iPad download the app KWeye + (multi-channel). DSE srl - ITALY - WWW.DSE.EU...
  • Page 63 Then press the + button to add a DVR to which you can connect. Enter your login credentials (default Admin / 888888), the machine's IP address and port to be used which by default is 7050. Finally specify the number of channels on the DVR. Click SAVE and then BACK. Click to start monitoring screen DSE srl - ITALY - WWW.DSE.EU...
  • Page 64 Choose DEVICE LIST and then the + button add the DVR as soon as the visa application KWeye. Below the installed application on iPhone DSE srl - ITALY - WWW.DSE.EU...
  • Page 65 There are two types of access KWeye +: by address or DDNS (ADDRESS) or by using the ID of the DVR (ID). In Access with IP address or DDNS are inserted as already seen for the KWeye address, port, log-in and the number of channels. DSE srl - ITALY - WWW.DSE.EU...
  • Page 66 In the case of access with ID it fits the unique ID of the equipment that reads the menu to the DVR MANAGEMENT / NEXT PAGE page and can also be found on a label on the back. DSE srl - ITALY - WWW.DSE.EU...
  • Page 67 Page: - 67 - Page: - 67 - E 'can store multiple DVRs and cameras to choose which one they see on the screen. And 'you can display up to 9 cameras simultaneously from different DVR. DSE srl - ITALY - WWW.DSE.EU...
  • Page 68 The REC indication appears in the upper right of the image when recording is active. Access to the recorded video clip management DSE srl - ITALY - WWW.DSE.EU...
  • Page 69 If you have a BlackBerry PDA you have to copy on a PC and Kweye.cod Kweye.alx Software in CD supplied with the DVR. To be able to install applications on BlackBerry requires that your PC is running BlackBerry Desktop Manager. Open the Desktop Manager: Click APPLICATION LOADER Choose ADD / REMOVE APPLICATIONS clicking START DSE srl - ITALY - WWW.DSE.EU...
  • Page 70 Now Desktop Manager will display the new KWEye application and you can start the installation. Start the program from Click to open the settings window. Enter your login credentials (default Admin / 888888), the machine's IP address and port to be used which by default is 7050. DSE srl - ITALY - WWW.DSE.EU...
  • Page 71 The control buttons are: Play and Stop Full screen hides the menu buttons Take a picture and saves it in memory Accesses settings Application Information Opens the channel selection window. Commands Move - Zoom - DSE srl - ITALY - WWW.DSE.EU...
  • Page 72 Once you installed the program KWeye the icon appears between programs Launch the application and follow the instructions for iPhone / iPad The KWeye + Android version allows multi-image of up to 4 channels. DSE srl - ITALY - WWW.DSE.EU...
  • Page 73 The following is a list of certified compatible with hard disk video recorders DR series. item Model Number Size (GB) Drive WD5001ABYS, WD5000AADS SATA WD5000AVVS, WD5000AVDS SATA WD7500AACS SATA WD10EADS, WD10EVDS, WD10EALS 1000 SATA DSE srl - ITALY - WWW.DSE.EU...
  • Page 74 The DR video recorders allow you to connect to the USB port of USB burner for backing up movies. Here are some cerificati compatible models. * Sony DRX-S70U-R * HUGE USB Slim Portable Optical Drive * LG GE20LU10 * Lite On eSAU108 * Buffalo DVSM-P58U2 / B DSE srl - ITALY - WWW.DSE.EU...

This manual is also suitable for:

Dr-n4N16-dr
