A3 Bookedge Scanner
Getting Started
Regulatory model: BT-0911S
Avision Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT-0911S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avision BT-0911S

Summary of Contents for Avision BT-0911S

  • Page 1 A3 Bookedge Scanner Getting Started Regulatory model: BT-0911S Avision Inc.
  • Page 2 Warranty The information contained in this document is subject to change without notice. Avision makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of fitness for a particular purpose. Avision shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Table Of Contents

    Table of Contents Introduction ..........1-1 Scanner Installation ........2-1 Unlocking your scanner ........ 2-1 Installing the Scanner Driver and Connecting the Cables ..........2-2 Completing Your First Scan ....... 3-1 Loading Your Paper ........3-1 Verifying Your Scanner Installation ....3-2 A Glance of the Scanner Properties Dialog Box ...

  • Page 5: Introduction

    1. Introduction Congratulations on your purchase of the Avision’s A3-sized bookedge scanner. Avision is one of the leading companies to make high quality color image scanner. Before you install and operate the new scanner, please take a few minutes to read through this manual.

  • Page 7: Scanner Installation

    2. Scanner Installation 2.1 Unlocking your scanner To protect the scanning unit from damage during transportation, a lock switch is designed at the back of the scanner to keep the scanning unit from moving. To unlock the scanner, move the lock switch down as shown in Fig.

  • Page 8: Installing The Scanner Driver And Connecting The Cables

    2.2 Installing the Scanner Driver and Connecting the Cables NOTE: 1). The Windows system CD may be required when installing on some PC’s. 2). To ensure your computer can identify the USB scanner, please install scanner driver first before connecting the scanner to your computer.
  • Page 9 2.2.2 Turning on the Power Press the Power Switch button on the front panel, the Power LED will be lit. To turn off the scanner, press the Power Switch button for about 3 seconds, the Power LED will be off. 2.2.3 Installing the Scanner Driver Place the supplied CD-ROM onto your CD-ROM drive.
  • Page 10 Contents on the installation graphic: Install Button Manager V2: To use the buttons  on the scanner, you need to install Button Manager V2. To ensure Button Manager V2 works properly, please FIRST install Button Manager V2 before installing the scanner driver. Install Scanner Driver: To communicate with ...
  • Page 11 2.2.4 Connecting to Computer Connect the square end of the USB cable to the USB port of your scanner. Connect the rectangle end to the USB port of your computer. In Windows XP, click the Next button to continue. When the XP certification screen appears, click Continue Anyway to complete the installation.

  • Page 13: Completing Your First Scan

    Completing Your First Scan 3.1 Loading Your Paper Open the document cover then place your original face down on the document glass as shown in Fig. 3-1. Make sure the top of your original near the document alignment mark. 1. Document cover 2.

  • Page 14: Verifying Your Scanner Installation

    Verifying Your Scanner Installation To verify if your scanner installation is correct, Avision provides you a useful test program called Avision Capture Tool. With this tool, you can perform simple scans and view the captured images. In addition, it helps you complete your scan at a rated speed.
  • Page 15 Actual Page Size Save File Path File Format Scan Setup Choose your desired file format from the File Format drop down list box. (Default is BMP, other choice includes TIFF, MTIFF, PDF, MPDF, GIF, and JPEG.) The supported file formats vary depending on your scanner model. Click the Setup button ( ) or choose Setup from the File menu to prompt the Scanner Properties dialog box.
  • Page 16 Click OK to quit the Scanner Properties dialog box. (To learn more details about the Scanner Properties dialog box, please see the subsequent chapter, Using the Scanner Properties Dialog Box.) Place your document face down on the document glass or face up in the auto document feeder.

  • Page 17: A Glance Of The Scanner Properties Dialog Box

    A Glance of the Scanner Properties Dialog Box 1. Tab Options Choice: Image, Compression, Color Dropout, Paper, Multi-Feed Detection, Preview, Options, Settings, Information. 2. Image Choose your image type and the side of Selection Box document you wish to scan. Options vary based on type of scanner.

  • Page 19: Isis Interface Operation

    4. ISIS Interface Operation * Please refer to the preceding chapter, Scanner Installation, to install ISIS scanner driver. You may start the supplied QuickScan software application to scan via the ISIS user interface. The ISIS driver operation method is similar to the TWAIN’s. Every function on the ISIS interface screen is briefly described as below: Mode: Select one of scan modes, including B&W, gray, color...

  • Page 21: Using The Buttons

    5. Using the Buttons 5.1 Installing Button Manager V2 Button Manager V2 provides you an easy way to scan your document and then link the scanned image to your designated software application. All this can be done by a simple touch of the button on the scanner.
  • Page 22 Left-click the Button Manager icon to prompt the following Button Panel. This indicates the scanner model The Function Icon (The number of function icons vary based on type of scanner.) The Button Icon The Button Panel...
  • Page 23 The Button Panel shows the first five scanning buttons. Right-click the button (function) you wish to check. The Button Properties window appears. Name of the Selected Button Button Name Image Mode Basic Scan Selection Parameters Folder and file name for the scanned image Scan To...

  • Page 24: Scanning From One Touch Of The Buttons

    Manager V2, please refer to the user’s manual in the supplied CD. You may also use Button Manager V2 on your desktop by starting Button Manager V2 from All Programs or double clicking the Avision Scanner Utility from the Control Panel.

  • Page 25: Maintenance

    6. Maintenance 6.1 Cleaning the Glass The procedures 1) Use a clean and lint-free cloth wet with isopropyl alcohol. (95%) 2) Open the document cover as shown in Figure 6-1. Wipe the document glass. 3) Close the document cover. Your scanner is now ready for use.

  • Page 27: Using And Caring The Optional Auto Document Feeder

    7. Using and Caring the Optional Auto Document Feeder 7.1 Installing the Auto Document Feeder Remove the document cover. Insert two hinges of the auto document feeder to the corresponding holes on the document glass as shown in below. Lift the paper chute to about 45 degrees. Pull the paper-chute plastic leg down to the grips on the document cover.

  • Page 28: Loading Your Paper

    7.2 Loading Your Paper 7.2.1 Notice on Using the ADF Before using the ADF, please make sure that your paper meets the following specifications:  Document(s) can range in size from 6” x 4” (152 x 100 mm) to 11.8” x 17” (300 x 432 mm). ...
