- Page 1 Instruction Booklet IB-MO-10R July 2014 INSTRUCTIONS FOR TYPE MO-10 MULTI-REVOLUTION MOTOR OPERATING MECHANISM IMPORTANT Read the entire manual before installing and maintaining equipment. Make absolutely sure that applicable equipment is de-energized and properly grounded.
- Page 2 If the motor operator is set for Counter- Clockwise rotation to open, the CLOSED The MO-10 can be uncoupled from the vertical position will typically be on the left and the operating pipe and test operated without disturbing OPEN on the right facing the motor operator.
- Page 3 NOTICE: IT IS RECOMMENDED TO USE SILICON ON THE BACK OF THE ENCLOSURE WHERE IT MEETS THE STRUCTURE AFTER THE MO-10 HAS BEEN MOUNTED. THE FOUR Once successful switch operation is achieved SEALING WASHERS ATTACHED TO THE MOUNTING BOLTS ON THE BACK OF THE MO-10 SHOULD BE PLACED ON THE BOLT BETWEEN THE STRUCTURE AND THE CABINET PRIOR TO MOUNTING WITH THE NEOPRENE SIDE OF THE WASHER FACING THE CABINET.
- Page 4 Should further information be desired or should particular problems arise which are not covered sufficiently for the purchaser’s purposes, the matter should be referred to Pascor Atlantic, 254 Industry Drive, Bland, VA 24315. Phone Number: 276-688-3328, Fax: 276-688-2228 or 2229 www.pascoratlantic.com...
