- Page 1 SRV PRO TV LIFT Model # : 32800 – 28” SRV PRO TV Lift 33900 – 39” SRV PRO TV Lift OWNER’S MANUAL...
- Page 2 SRV PRO TV Lift www.touchstonehomeproducts.com 800.215.1990 rev. 20190312...
-
Page 3: Table Of Contents
Hardware ................................... 6 Tools ..................................6 Dimensional Drawings ..............................7 32800 – SRV PRO 29” TV Lift ..........................7 33900 – SRV PRO 39” TV Lift ..........................8 Assembling and Installing Your SRV PRO TV Lift ....................9 Fasten Lift To Cabinet .............................. 9 Hooking Up Lift Components and Operating Lift .................... -
Page 4: About Your Touchstone Srv Pro Tv Lift
About Your Touchstone SRV PRO TV Lift Congratulations on the purchase of your Touchstone SRV PRO TV lift. Touchstone Home Products takes pride in the quality craftsmanship and smooth functionality of our TV lift mechanisms. Please take a few minutes to learn about the features of your TV lift to ensure you get the optimum use and performance from your new purchase. -
Page 5: Safety Information
Safety Information Mounting your flat screen TV to the Touchstone SRV PRO TV Lift is fast and easy. Operating your lift is very straightforward. However, to avoid the risk of personal injury and to ensure optimum performance of your TV lift mechanism, please pay particular attention to the warnings and safety notices throughout this manual. -
Page 6: Lift Components & Tv Installation Hardware
SRV PRO TV Lift Lift Components & TV Installation Hardware Components Lift Parts Number Part Number Part Name 32800, 33900 Lift Column 32809 Lift Base TV Mounting Plate 32810a TV Mounting Brackets 32810b Horizontal Flat Panel Brackets Flat Top Lift Mount... -
Page 7: Dimensional Drawings
SRV PRO TV Lift Dimensional Drawings 32800 – SRV PRO 29” TV Lift www.touchstonehomeproducts.com 800.215.1990 rev. 20190312... -
Page 8: 33900 - Srv Pro 39" Tv Lift
SRV PRO TV Lift 33900 – SRV PRO 39” TV Lift www.touchstonehomeproducts.com 800.215.1990 rev. 20190312... -
Page 9: Assembling And Installing Your Srv Pro Tv Lift
SRV PRO TV Lift Assembling and Installing Your SRV PRO TV Lift Fasten Lift To Cabinet The SRV PRO TV Lift has 8 mounting points (4 on the back of the lift and 4 on the floor). Use the 4 rear mounting points and the 4 floor mounting points to mount the lift in your cabinet. - Page 10 SRV PRO TV Lift Fasten Lift To Cabinet – cont. 3. Once the lift is placed in the cabinet and aligned with the center of the cabinet, fasten the lift to the back wall of the cabinet and the floor of the cabinet. 4.
-
Page 11: Hooking Up Lift Components And Operating Lift
SRV PRO TV Lift Hooking Up Lift Components and Operating Lift Once the TV Lift is installed in the cabinet, the individual lift components can be attached to the lift. The following components will be needed: - Lift Control Box - Power Supply - Wired Hand Set Control Parts Required:... -
Page 12: Hooking Up Control Box
SRV PRO TV Lift Hooking Up Control Box Instructions: 1. Attach one end of the Control Box-Lift Transit Cable to the lift cable that is connected to the lift. 2. Attach the other end of the Control Box-Lift Transit Cable to the control box in the port shown below. Lift Connection Port www.touchstonehomeproducts.com 800.215.1990... -
Page 13: Hooking Up Wired Handset Control
SRV PRO TV Lift Hooking Up Wired Handset Control Instructions: 1. Plug the wired handset control into appropriate port on the control box shown below. Hooking Up Power Supply Instructions: 1. Attach the power supply transit cable (A) to the power supply and plug the power supply cable (B) into the control box. -
Page 14: Operating The Lift
SRV PRO TV Lift Operating the Lift The SRV PRO TV Lift can be controlled through the provided wired handset controller or the wireless remote control. Wired Handset Control Lift Height: Shows the height of the lift in mm UP Button: PRESS and HOLD this button to raise the lift. Releasing this button will stop the lift. -
Page 15: Wireless Rf Control
SRV PRO TV Lift Operating the Lift – cont. Wireless RF Control Wireless RF Function Remote Button UP Button: PRESS the button once to raise the lift. The lift will raise all the way up unless the stop button is pressed. DOWN: PRESS the button once to lower the lift. -
Page 16: Advanced Automation Controls
Operating the Lift – cont. Advanced Automation Controls The Touchstone SRV PRO TV Lift control box comes equipped with additional input/output features that allow you to connect external devices, such as third-party automation systems that can be controlled by a universal remote control. - Page 17 Advanced Automation Controls RS232 Controls The Touchstone SRV PRO TV Lift can also be controlled by third-party automation systems via a RS232 serial connection. The input connector on the control box uses a standard RJ-25 connection, The pinout of the connector is illustrated below.
-
Page 18: Mounting And Installing The Tv
Please consult your TV manufacturer for the size of the mounting holes in the back of your TV and use the appropriate size screws. Touchstone Home Products assumes no liability for damage to a TV. - Page 19 SRV PRO TV Lift Attaching TV Mounting Brackets To Flat Panel TV- cont 3. Align TV mounting brackets so that brackets are centered on the back of the TV. Place the TV mounting bracket so that the round holes are toward the top of the TV, while the elongated holes are toward the bottom of the TV. 4.
-
Page 20: Assembling The Flat Panel Tv Mount
SRV PRO TV Lift Assembling The Flat Panel TV Mount Tools Required: - Phillips head screwdriver Parts Required: - 2 horizontal flat panel TV mounting brackets - 2 vertical rods - 4 mounting screws and washers Instructions: 1. Attach the 2 vertical flat panel bracket rods to the top horizontal flat panel bracket. The elongated holes in the horizontal bracket should be facing down. -
Page 21: Mounting Flat Panel Tv Mount To The Lift
SRV PRO TV Lift Mounting Flat Panel TV Mount To The Lift Tools Required: - Hex Wrench Parts Required: - Horizontal flat panel TV mount - TV Lift - 4 M8x20 bolts and nuts - 8 washers - 4 lock washers Instructions: 1. - Page 22 SRV PRO TV Lift Mounting Flat Panel TV Lift Mount – cont. 3. Using the 4 M8x20 bolts and nuts, mount the horizontal flat panel TV bracket to the lift. Use 1 washer between the nut and back of the lift mounting plate. Tighten bolts so bracket is secure to lift. Mounting Screw Installation Back of Lift 4.
-
Page 23: Installing Tv On Lift
SRV PRO TV Lift Installing TV on Lift 1. Using the wired handset control, press the UP button to move the lift to the highest position. 2. Hang TV on top crossbracket so that the top set of hooks on the TV bracket overlap the top bar of the flat panel TV mount. -
Page 24: Locking Tv To Flat Panel Tv Mount
SRV PRO TV Lift Locking TV to Flat Panel TV Mount Once the TV is mounted to the lift, the TV can be locked to the flat panel TV mount so that the TV does not slide from side to side. To lock the TV into place, tighten the 2 long screws on the bottom of each TV bracket. The screws will tighten so that they lock against the bottom crossbracket of the flat panel TV mount. -
Page 25: Installing C Bracket And Flat Top Lid Mount
SRV PRO TV Lift Installing C Bracket and Flat Top Lid Mount The SRV PRO TV Lift includes an adjustable bracket (C bracket) and flat top lid mount for mounting cabinet lids to the top of the lift. Once the TV is mounted on the TV, the C bracket and flat top lid mount can be installed. Parts Required: C Bracket Flat Top Lid Mount... - Page 26 Technical Support and Troubleshooting Should you have any problems with your Touchstone Home Products SRV PRO TV Lift, our technical support staff is here to help. Our technical support reps are available by phone at 1-800-215-1990 Monday to Friday, from 8:00am to 5:00pm EST.
-
Page 27: Warranty
SRV PRO TV Lift Warranty Touchstone Home Products warrants the SRV PRO TV Lift to be free from defects in material and workmanship for three (3) years from date of purchase. The warranty includes all parts, motorized components, electronics, and metal. -
Page 28: Www.touchstonehomeproducts.com 800.215.1990
SRV PRO TV Lift www.touchstonehomeproducts.com 800.215.1990 rev. 20190312...
