- Page 1 Mediant VoIP Media Gateway SIP Protocol Hardware Installation Manual Version 6.6 April 2012 Document #: LTRT-85609...
-
Page 3: Table Of Contents
Hardware Installation Manual Contents Table of Contents Introduction ......................7 Unpacking the Device ..................9 Physical Description ..................11 Front Panel Description ..................12 3.1.1 FXS Module ......................13 3.1.1.1 Port Description ..................13 3.1.1.2 LED Description ..................13 3.1.2 FXO Module ...................... - Page 4 Mediant 600 List of Figures Figure 3-1: Front Panel .......................... 12 Figure 3-2: FXS Module ......................... 13 Figure 3-3: FXO Module ........................14 Figure 3-4: BRI Module .......................... 15 Figure 3-5: TRUNKS Module ......................... 16 Figure 3-6: CPU Module ........................17 Figure 3-7: Rear Panel ..........................
- Page 5 Hardware Installation Manual Notices Notice This Installation Manual describes the hardware installation for AudioCodes Mediant 600 SIP Voice-over-IP (VoIP) gateway. Information contained in this document is believed to be accurate and reliable at the time of printing. However, due to ongoing product improvements and revisions, AudioCodes cannot guarantee accuracy of printed material after the Date Published nor can it accept responsibility for errors or omissions.
- Page 6 Mediant 600 Related Documentation Document Name Product Reference Manual SIP Release Notes Mediant 600 & Mediant 1000 SIP User's Manual General Notes Notes: Throughout this manual and unless otherwise specified, the term device refers to the Mediant 600 gateway. Warnings and Safety Information Note: The device is an indoor unit and therefore, must be installed only indoors.
-
Page 7: Introduction
Hardware Installation Manual 1. Introduction Introduction This document provides a hardware description of the Mediant 600 (hereafter referred to as device) and step-by-step procedures for cabling the device. Note: For information on configuring the device, refer to the device's User’s Manual. - Page 8 Mediant 600 Reader’s Notes Hardware Installation Manual Document #: LTRT-85609...
-
Page 9: Unpacking The Device
To unpack the device: Open the carton and remove packing materials. Remove Mediant 600 from the carton. Check that there is no equipment damage. Ensure that in addition to Mediant 600, the package contains the following items: • One AC power cable •... - Page 10 Mediant 600 Reader's Notes Hardware Installation Manual Document #: LTRT-85609...
-
Page 11: Physical Description
Hardware Installation Manual 3. Physical Description Physical Description The device is 1U high compact unit that can be installed in a 19-inch industrial rack. The device supports Basic Rate Interface (BRI), Primary Rate Interface (PRI) E1/T1, FXS interfaces, and FXO interfaces, and can be supplied in one of the following hardware configurations: ... -
Page 12: Front Panel Description
Mediant 600 Front Panel Description The device’s front panel is shown in the figure below and described in the subsequent table. Figure 3-1: Front Panel Note: The figure above is used only as an example. The number and type of interface modules depends on the ordered configuration. -
Page 13: Fxs Module
Hardware Installation Manual 3. Physical Description 3.1.1 FXS Module The FXS module provides the Foreign eXchange Subscriber (FXS) interfaces. Up to two FXS modules can be installed in the device. Each FXS module can provide up to four FXS interfaces and therefore, the device can support up to eight FXS interfaces. 3.1.1.1 Port Description Each FXS module provides up to four RJ-11 ports. -
Page 14: Fxo Module
Mediant 600 3.1.2 FXO Module The FXO module provides the Foreign eXchange Office (FXO) interfaces. Up to two FXO modules can be installed in the device. Each FXO module can provide up to four FXO interfaces and therefore, the device can support up to eight FXO interfaces. -
Page 15: Bri Module
Hardware Installation Manual 3. Physical Description 3.1.3 BRI Module The BRI module provides the Integrated Services Digital Network (ISDN), BRI interfaces. Up to two BRI modules can be installed in the device. Each BRI module can provide up to four BRI line interfaces and therefore, the device can support up to eight BRI interfaces. 3.1.3.1 Port Description Each BRI module provides up to four RJ-45 ports. -
Page 16: Trunks (E1/T1) Module
Mediant 600 3.1.4 TRUNKS (E1/T1) Module The device supports one or two digital PRI (E1/T1/J1) trunk spans, including fractional E1/T1. 3.1.4.1 Port Description The module is available in 1 or 2 span configurations, providing RJ-48c ports. The ports are labeled I and II. -
Page 17: Cpu Module
Hardware Installation Manual 3. Physical Description 3.1.5 CPU Module The CPU module is the central processing unit that provides various port interfaces. 3.1.5.1 Port Description The CPU module provides various port interfaces, as shown in the figure below and described in the subsequent table. Figure 3-6: CPU Module Table 3-6: CPU Module Port Description Item #... -
Page 18: Led Description
Mediant 600 3.1.5.2 LED Description The CPU module provides two LEDs for each of the Ethernet ports (located below the ports), as described in the table below: Table 3-7: CPU Module LEDs Description Color State Description Left LED Orange Blinking Activity. -
Page 19: Mounting The Device
Hardware Installation Manual 4. Mounting the Device Mounting the Device The device can be mounted in one of the following ways: On a desktop – see Section on page Installed in a standard 19-inch rack – see Section on page Desktop Mounting The device can be mounted on a desktop, by attaching the supplied four adhesive, anti-... -
Page 20: 19-Inch Rack Mounting
Mediant 600 19-Inch Rack Mounting The device can be installed in a standard 19-inch rack. Rack Mount Safety Instructions • Elevated Operating Ambient Temperature: If installed in a closed or multi- unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient temperature. -
Page 21: Cabling The Device
Hardware Installation Manual 5. Cabling the Device Cabling the Device This section describes how to cable the device: Connecting to earth or ground – see Section on page Connecting to the LAN – see Section on page Connecting to FXS interfaces –... -
Page 22: Connecting To The Ip Network
Mediant 600 Connecting to the IP Network The procedure below describes how to connect to the Ethernet (IP) network (e.g., switch). An RJ-45 cable connector with the following pinouts is used: Figure 5-1: RJ-45 Connector Pinouts for Ethernet Network ... -
Page 23: Connecting To Fxo Interfaces
Hardware Installation Manual 5. Cabling the Device Connecting to FXO Interfaces The procedure below describes how to connect the FXO port interfaces to telephone exchange analog lines or PBX extensions. Warnings: • To protect against electrical shock and fire, use a 26 AWG min wire to connect FXO ports to the PSTN. -
Page 24: Connecting The Analog Lifeline Phone
Mediant 600 Connecting the Analog Lifeline Phone The device supports an analog (FXS) Lifeline phone feature, whereby upon a power outage or IP network connectivity loss, IP calls are re-routed to the PSTN. The analog Lifeline is provided by Port I on an FXS module. This port connects to the POTS phone and the PSTN or PBX, using a splitter cable. -
Page 25: Connecting To Isdn Bri Lines
Hardware Installation Manual 5. Cabling the Device Connecting to ISDN BRI Lines The procedure below describes how to connect to BRI lines. Warning: To protect against electrical shock and fire, use a 26 AWG min wire to connect the BRI ports to the PSTN. Note: This section is applicable only if your device is installed with a BRI module. -
Page 26: Connecting Bri Interfaces For Pstn Fallback
Mediant 600 Connecting BRI Interfaces for PSTN Fallback The PSTN Fallback feature provides a BRI interface connection to the PSTN upon a power outage (i.e., Ethernet link failure). This allows a telephone or PBX connected to a BRI port to continue making calls through the PSTN network (instead of through the IP network). -
Page 27: Connecting To E1/T1 Trunks
Hardware Installation Manual 5. Cabling the Device Connecting to E1/T1 Trunks The procedure below describes how to connect to E1/T1 trunks. Warning: To protect against electrical shock and fire, use a 26 AWG min wire to connect T1 or E1 ports to the PSTN. Note: This section is applicable only if your device is installed with a TRUNKS module. -
Page 28: Connecting E1/T1 Trunks For Pstn Fallback
Mediant 600 Connecting E1/T1 Trunks for PSTN Fallback The device supports PSTN Fallback feature when provided with two E1/T1 PRI spans. The digital module's Port II serves as a dedicated Fallback port connected to the PSTN. In the event of a power failure (i.e., no Ethernet link), a relay connects ports I and II by the closing of a metallic switch inside the module, re-routing trunk traffic from the PBX to the PSTN (instead of from the PBX to the IP network). -
Page 29: Connecting To Dry Contact Relay Alarm System
Hardware Installation Manual 5. Cabling the Device 5.10 Connecting to Dry Contact Relay Alarm System The dry contact ports I and II located on the device's CPU module allows you to connect the device to an external audible or visual alarm system. The table below describes the operational status of these dry contact ports. -
Page 30: Connecting Rs-232 Serial Interface To A Computer
Mediant 600 To set up a dry contact system: Insert two wires into the mate’s spring-cage wire connectors in position 4 and 3 for the device's dry contact Port I, and two wires in position 2 and 1 (for the device's dry contact Port II), by performing the following: With a sharp, pointed object, press the position's corresponding orange button;... -
Page 31: Connecting To Power
Hardware Installation Manual 5. Cabling the Device 5.12 Connecting to Power The device receives its power from a standard AC electrical outlet. The connection is made using the supplied AC power cord. Warnings: • Units must be connected (by service personnel) to a socket-outlet with a protective earthing connection. - Page 32 Hardware Installation Manual www.audiocodes.com...
