  • Page 1: Manual Radio Medium With Bluetooth

    Manual Radio Medium with Bluetooth Complete manual for the Scania Radio Medium This manual can be downloaded at www.scania.com/manuals...

  • Page 2: Overview

    Overview Left multi-function button Volume control, ON/OFF button Short press: Switch on Radio Medium While in operation: Turn off sound (Mute) Long press: Switch off Radio Medium Turn : Adjust volume Short press: Select memory bank or waveband Bluetooth active: answer the phone or make a call...
  • Page 3 (12) Select audio choice: radio, AUX or CD (when CD is inserted), MP3 (when MP3 CD is inserted) and USB (when USB device is connected). Long press: Bluetooth active: Open phone...

  • Page 4: Table Of Contents

    Activating or deactivating anti-theft protection (CODE) Entering the code Switching the Radio Medium on and off ..............10 Switching the Radio Medium on and off with the ON/OFF button Steering wheel buttons Switching the Radio Medium on or off with the ignition key...
  • Page 5 Selecting waveband/memory bank Tuning into stations Storing stations Retrieving stored stations Scanning stored stations (PRSTSCAN) Scanning receivable stations (SCAN) Programme type (PTY) Noise adapted treble reduction (HICUT) Activating/deactivating radio text (RDSTEXT) Traffic information priority ..................28 Activating/deactivating traffic announcement priority Setting volume regulation for traffic announcements Switching off traffic announcements CD mode ........................30 Starting CD mode...

  • Page 6: About The Manual

     Read carefully through the entire manual before using your Radio Medium.  Store the manual in a place that is easily accessible for all users.  If you pass on the Radio Medium to another person, make sure to also give them this manual.

  • Page 7: Cleaning Instructions

    Protect your hearing by always keeping the volume at a moderate level. When the truck is in motion:  Only use the Radio Medium when traffic situations permit! Stop at a suitable place if you plan to make extensive setting adjustments.

  • Page 8: Anti-Theft Protection

    This code ensures that the Radio Medium cannot be operated without the code if it has been removed from the vehicle. Whenever the Radio Medium has been disconnected from the battery, the code must be entered to operate the system again.

  • Page 9: Entering The Code

    Entering the code You will need to enter the code if the vehicle's battery master switch has been switched off or if the power to the Radio Medium has been severed in any other way.  Switch on the Radio Medium.

  • Page 10: Switching The Radio Medium On And Off

    Switching the Radio Medium on and off with the ON/OFF button  Press the ON/OFF button (1) to switch the Radio Medium on.  When you wish to switch the Radio Medium off, press and hold down the left multi-function button (1) for more than two seconds. Note To protect the vehicle's battery, the Radio Medium will automatically switch off after the ignition has been off for a preset period of time (see section "Setting auto...

  • Page 11: Setting Auto Shut-Off Timer

    Setting auto shut-off timer  Press the MENU button (6).  Press button (7) (may need to press several times) until "SLEEP" appears in the display (5).  Press button once to show "SLEEP" and then the current setting (5 to 60 minutes in 5-minute increments).

  • Page 12: Setting The Volume

    Setting the volume The volume of the Radio Medium can be set in increments from 0 (off) to 32 (max).  To increase system volume, turn the volume control (1) to the right.  To decrease system volume, turn the volume control (1) to the left.

  • Page 13: Using The Menu Button

    Using the MENU button Press the MENU button (6) to open the Radio Medium main menu. You can change Radio Medium settings in the menu. Use the up and down arrows on the rocker button to browse through the menu. Use the right and left arrows to select options.

  • Page 14: Radio Medium Menu Contents

    • ONVOLUME. Volume when switched on. • GALA. Noise and speed adapted volume control. • CODE. Anti-theft protection. • SLEEP. Amount of time the Radio Medium will remain active without power. • BEEPTONE. Beeptone, warning signal on or off. • PTY. Searches for stations with programme information.

  • Page 15: General Information About Bluetooth

    Bluetooth-enabled. Refer to the manufacturer’s manual for data about your phone equipment. The Bluetooth connection works with most mobile phones. www.scania.com/manuals contains a list of the models that have been tested and a description of how they work when they are connected to the radio.
  • Page 16 The radio now searches for the phone. A connection is displayed in the mobile phone called SCANIA BT. Select this. 3. A code is shown in the radio display which should be entered in your phone’s button kit. Follow the phone’s instructions.

  • Page 17: Make A Call From The Call List

    Note • When a mobile phone is connected to the radio, the radio automatically loads the phone book from the phone’s SIM card. You can obtain and use the phone book when you want to make a call, (Read the section Making a call). The phone book is available when all the data has been transferred from the mobile phone.

  • Page 18: Activating/Deactivating Sound Signal (Beeptone)

    • You can use the radio Bluetooth function without using the steering wheel buttons or the instrument cluster display. It is not, however, something that Scania recommends to drivers, since using it in such a way adversely affects road safety.

  • Page 19: Changing Sound Properties

    Changing sound properties Setting maximum start volume (ON VOLUME) When you turn on the Radio Medium, playback will start at the volume last selected. However, if you select a higher volume than the maximum start volume before you turn off the radio, the volume will automatically be limited to the pre-set maximum start volume the next time you turn on the radio.

  • Page 20: Setting Bass

    Setting BASS  Press button AUD (8).  Press button (7) (may need to press several times) until "BASS" appears in the display (5).  Press button (7) once, to display "BASS" and the current setting.  Press button (7) again, to set bass level from -7 to +7. ...

  • Page 21: Staging

    STAGING STAGING is used to artificially "change" the positioning of the speakers so that the driver or passenger seat seems to be positioned directly between the left and right speaker. This evens out the various distances between your location in the truck and the locations of the right and left speakers.
  • Page 22  Press button (7) (may need to press several times) until "STAG-LSP" appears in the display (5).  Press button (7) once, to display "STAG" and the current setting.  Press button (7) again, to select the desired setting.  Press button (7) to adjust additional settings in the menu, ...

  • Page 23: Radio

    Radio The radio is equipped with an RDS radio receiver. In addition to the programme itself, many FM radio stations also transmit signals containing information such as the station name and programme type (PTY). If the RDS station transmits its name, it will be shown directly in the display (5). Switching on the radio If you are listening to another audio source: ...

  • Page 24: Selecting Waveband/Memory Bank

    Selecting waveband/memory bank The radio can receive stations broadcast on FM, MW and LW bands. There are three memory banks available for FM (FM1, FM2 and FMT) and one each for MW and LW (AM broadcast) bands. Each memory bank can store up to six stations. To switch between wavebands and memory banks: ...

  • Page 25: Storing Stations

    Storing stations Storing stations manually  Select the desired memory bank and waveband.  Tune into the station.  Press one of the station buttons 1 - 6 (10) to assign the station to that button. Hold for more than two seconds. The beep signal will sound.

  • Page 26: Scanning Receivable Stations (Scan)

    Scanning receivable stations (SCAN) You can use the scan function to listen to all of the receivable stations in the area for approximately 10 seconds per station. Starting scan  Press and hold down the (7) button for more than two seconds. "SCAN"...

  • Page 27: Noise Adapted Treble Reduction (Hicut)

    Noise adapted treble reduction (HICUT) The HICUT function improves sound quality during poor radio reception. If interference occurs, HICUT will automatically reduce any static or noise. To activate/deactivate and adjust HICUT settings,  press the MENU button (6).  Press button (7) (may need to press several times) until "HICUT"...

  • Page 28: Traffic Information Priority

    Traffic information priority Activating/deactivating traffic announcement priority To activate or deactivate traffic information priority while in any audio source mode:  press button TA (9). Traffic announcement priority is activated when the TA symbol is shown in the display (5). As soon as the radio receives a traffic announcement, it will be played. "TRAFFIC"...

  • Page 29: Switching Off Traffic Announcements

    Switching off traffic announcements To switch off a traffic announcement in progress and return to the audio source you were listening to before,  press button TA (9). Traffic announcement priority is still activated.

  • Page 30: Cd Mode

     Keep CDs out of direct sunlight and store in a case/sleeve when not in use.  Do not affix any labels to CDs. Use a suitable felt pen to write on CDs.  Scania does not accept responsibility for damage to the CD player caused by unsuitable or damaged CDs.

  • Page 31: Fast Searching (Audible)

    To restart the current track from the beginning, press button (7) once. Fast searching (audible) To quickly search forwards or backwards,  press and hold down (7) until you reach the place you are looking for. Random track play (RND) ...

  • Page 32: Ejecting A Cd

    Playback will resume. Ejecting a CD Note It is possible to eject CDs even when the Radio Medium is switched off or while another audio source is activated.  Press button (3) to eject the CD. The CD is ejected. "CD EJECT" will appear briefly in the display.

  • Page 33: Listening To Mp3/Wma

    Listening to MP3/WMA You can also use this Radio Medium to listen to CD-Rs and CD-RWs containing MP3 and WMAmusic files. You can also connect a USB device (accessory) to a USB interface and play MP3/WMA files saved on the USB device.

  • Page 34: Starting Mp3 Mode

    If it is important for you that your files be in a certain order, use your burning software to save the files in the order that you would like them to play. The Radio Medium will play the files in the order that you have saved them on the storage device.

  • Page 35: Display Of Track Information (Cd Tags)

    Permanent display of track information will only be active until you cancel MP3 mode or select another track or another folder. Selecting folders To move upwards or downwards to another folder,  press button (7). Note!  The Radio Medium will ignore all folders that do not contain MP3 files.

  • Page 36: Selecting Tracks/Files

     The Radio Medium will handle all folders and sub-folders as if they were on the same levelYou can also open all sub-folders by repeatedly pressing button (7). Selecting tracks/files To move upwards or downwards to another track,  press button (7).
  • Page 37 Cancelling scan To cancel scanning,  briefly press button 4 (10). "SCAN OFF" will appear briefly in the display (5). The current track will continue to play.

  • Page 38: Repeating Single Tracks Or Entire Folders (Rpt)

    Repeating single tracks or entire folders (RPT) To repeat the current track,  press button 2 (10) (may need to press several times) until "RPT TRK" appears in the display (5). The RPT symbol will appear in the display (5). To repeat the current folder, ...

  • Page 39: Using External Audio Sources (Aux)

    Using external audio sources (AUX) If no USB interface is connected to the Radio Medium, you can connect another external audio source, such as a portable CD player, Mini-Disc player or MP3 player to the AUX input (Group C3 on the back of the Radio Medium).

  • Page 40: Restoring Factory Settings (Reset)

    Restoring factory settings (RESET) It is possible to restore the Radio Medium settings to factory settings.  Press the MENU button (6).  Press button (7) (may need to press several times) until "RESET" appears in the display (5).  Press button (7).

  • Page 41: Technical Specifications

    Technical Specifications Operating voltage +12 V Max. power consumption approx. 7.5 A Standby power consumption approx. 1 MA Output power 4 x 20 Watt at 14.4 V, THAD=10 % ≥ 4 Ω Input sensitivity 2 V / 600 Ω Wavebands 87.5 - 108 MHz 531 - 1602 kHz 153 - 279 kHz...
  • Page 42 Connector location Terminal Function 1 CAN_High 2 CAN_Low 3 n.c. 4 Ignition plint 15 5 Ignition_D (wake up) 6 n.c. 7 Battery (12 V) 8 Ground / MINUS 1 Tweeter Right Front (+) 2 Tweeter Right Front) (–) 3 Woofer Right Front (+) 4 Woofer Right Front (–) 5 Woofer Left Front (+) 6 Woofer Left Front (–)
