Summary of Contents for DTS MASTER 1016
- Page 1 LIGHT CONTROLLER M A S T E R 1 0 1 6 Via Fagnano Selve, 12/14 (loc.La Cella)-47843 MISANO ADRIATICO (RN)-ITALY e-mail:dts@dts-show.com indirizzo internet: http://www.dts-show.com...
- Page 2 DTS . DTS si riserva il diritto di apportare senza preavviso senza cambiamenti e modifiche estetiche , funzionali o di design a ciascun proprio prodotto.
- Page 3 C O L L E G A M E N T O C O N S E G N A L E D M X 5 1 2 P e r l a c o n n e s s i o n e u s a r e u n c a v o m i c r o f o n i c o b i l a n c i a t o d e l t i p o RF 60/12 2 x 0,25 mmq.
- Page 4 Fore safety measurements keep to the following instructions -Do not disassemble or modify the device -Avoid inflammable liquid , water, gas or metal objets from penetrating in the device. Avoid using the device in these following ways In places with extreme humidity In places with high vibrations, and things that can probably knock against it Do not expose it to temperatures higher than 40°...
-
Page 5: Using Instructions
It is possible to change the configuration of the channels assigning both the number of the channels and the position of the PAN channel and TILT channel. It can command the reset of the DTS projectors. USING INSTRUCTIONS When turned on the controller always testes the working of the internal memory and of all the led which can be seen on the controller and, if everything works properly it is arranged in RECORD e trigger AUTO modality. - Page 6 and the controller will be prepared in RECORD modality and trigger AUTO will be ready. Incongruent and incorrect programs will not be accepted and it will not be possible to advance to the next step of the procedure until the correct data is introduced.
-
Page 7: Record Mode
( the corresponding led will flash). Memorise it in the record keeping the ENTER key pressed until the relative led is lighted on. Repeat point 4 and 5 for all the games which are desired to be inserted in the record (as most as 16). - Page 8 indicate the programmed scenes in that game, of which the flashing one represents the working scene. If a not programmed scene is selected the relative led is lighted on and all the others are lighted of. To create/change the scenes of the selected game proceed as explained: Press the scene key to enter actually in the programming modality if it was not programmed, or modification if an already programmed game was selected (in this case the executing of the game gets blocked on the scene in course).
- Page 9 PAN and TILT within the limits imposed by PAUSE. RESET FUNCTION OF THE PROJECTORS The controller MASTER 816 can send a reset signal to the DTS projectors connected to it. To enable this function press contemporarily the DELETE key and the SCANNER key until the two relative leds start flashing.
- Page 10 FUNCTION BLACK-OUT: You can activate the “BLACK-OUT”function by pushing the “DELETE” key. It is possible to selec the “MANUAL FUNCTION” in black-out too by pushing the “SCANNER” key and by selecting the projectns you want to control.
