- Page 1 Excellence IPC Installation guide Version 3.1.1...
-
Page 2: Important Safety Instructions
When opening the carton, please make sure that all the items listed below are present: GTIPC-A4 1. Power cord ×1 2. Antenna ×1 3. User guide ×1 4. Screw M3*6mm ×2 HDMI ×1 USB Cable ×1 i3TOUCH EXCELLENCE IPC Installation guide Version 3.1.1... -
Page 3: Connector Ports
Connector Ports Bottom Side View: GTIPC-A4: 1. PS/2 Keyboard Port x 1 2. VGA Port x 1 3. DVI Port x 1 4. HDMI Port x 1 5. Optical SPDIF Out Port x 1 6. USB 2.0 Port x 4 7. - Page 4 Side View: GTIPC-A4: SMA male connector (For Antenna) USB type A receptacles x2 1. SMA male connector X 1 2. USB type A receptacles x2 i3TOUCH EXCELLENCE IPC Installation guide Version 3.1.1...
-
Page 5: System Specifications
System Specifications GTIPC-A4: Intel CPU CORE i5-2400 3.1GHz Motherboard GTIPC-A4: System Chipset: Intel B85 Ethernet: Qualcomm Atheros AR8171 Graphic: Intel HD Graphic 4400/4600 Display Output: Supports VGA with max. Resolution up to 1920x1200 @60Hz Supports HDMI 1.4a Technology with max. Resolution up to 1920x1200 @60Hz Supports DVI with max. - Page 6 Installing the IPC module GTIPC-A4: Step.1 Insert the positioning column with display back cover in two holes with IPC. i3TOUCH EXCELLENCE IPC Installation guide Version 3.1.1...
- Page 7 Step.2 Put down the IPC.
- Page 8 Step.3 Use screw with M3*L6mm to fix the IPC on the display back cover. i3TOUCH EXCELLENCE IPC Installation guide Version 3.1.1...
- Page 9 Step.4 Put on the metal cable cover and use floating screw with M3*L6mm to fix on the back cover...
- Page 10 AUTHORISED DISTRIBUTOR WWW.I3-TECHNOLOGIES.COM INFO@I3-TECHNOLOGIES.COM...
